User Manual
For Windows and Macintosh OS
Artisul LCD Sketch-Pad | Model: D16 Pro

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D16 Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for ARTISUL D16 Pro

  • Page 1 User Manual For Windows and Macintosh OS Artisul LCD Sketch-Pad | Model: D16 Pro...
  • Page 2 Precautions 1. Please read this manual carefully before using, and keep it well for future reference. 2. Before cleaning the display please unplug the USB cable and wipe with a soft damp cloth, do not use any kind of detergents. 3.

  • Page 3: Table Of Contents

    Contents 1. Product Overview .......................... 1 1.1 Display Introduction ......................1 1.2 Product and Accessories ..................... 1 1.3 Setting up Display ........................ 3 1.4 Driver Installation ........................ 4 1.5 Pen Nib Replacement ......................4 2. Product Basic Operation........................ 5 2.1 Using the Pen ........................5 2.2 Using the Display .........................

  • Page 4: Product Overview

    1.1 Display Introduction ® Thanks for choosing Artisul D16 Pro LCD sketch-pad. This is a new generation of portable desktop-level professional drawing display, which can greatly improve your work efficiency of painting and creation, and full of fun. You can freely painting and writing, depicting different lines and colors, just as the pen writes on the paper, which brings you a real shock experience.
  • Page 5 1.2.3 Display Stand (Optional) We designed this stand specially for your Artisul display, you can adjust the angle of the display according to your usage habit, and make you feel more comfortable in painting and creating.

  • Page 6: Setting Up Display

    1.2.4 Other Accessories Stylus Pen Pen Bag Pen Nibs Pen Nib Clip USB Y-Cable 2 in 1 Cable AC Adapter Cleaning Cloth Glove Stand (Optional) Quick Start Guide 1.3 Setting up Display 1. Open up the stand, and then put the display on the stand.. 2.

  • Page 7: Driver Installation

    2. Before installing, please close all graphics software and anti-virus software to avoid unnecessary mistake. 3. Before installing, you need to connect your Artisul product to the computer. 1.5 Pen Nib Replacement The nib will be wear out after using for long time, then you need to replace a new...

  • Page 8: Product Basic Operation

    2. Product Basic Operation 2.1 Using the Pen 2.1.1 Hold the pen Hold the pen as you hold a normal pen or pencil. Adjust your grip so that you can toggle the side switch easily with your thumb or forefinger. Be careful not to accidentally press the switch while drawing or positioning with the pen.
  • Page 9 2.1.3 Click Use the pen tip to tap on the screen once to produce a click. Tap to highlight or select an item on the screen and double-click to open it. 2.1.4 Move Select the object, then slide the pen tip across the screen to move it.

  • Page 10: Using The Display

    2.1.5 Use the side buttons The side buttons of the pen can be set to two different customizable functions. You can use the buttons whenever the pen tip is within 10mm of the display active area. You do not have to touch the pen tip to the display in order to use the switch. 2.2 Using the Display 2.2.1 Power Button You need to turn on the power button before using the display.
  • Page 11 2.2.3 Dial LED Indicator The LED indicator of the dial supports monochromatic, polychromatic, and off modes. To customize the LED indicator: 1. When you press key 8, the indicator will switch between the three modes. 2. When the indicator is in monochromatic or polychromatic mode, press and hold key 8, and press key 6 or 7 to adjust the indicator brightness.

  • Page 12: Function Setting

    2.Device connected: has been recognized by your computer successfully already. 3.2 Working Area Setting 3.2.1 Using Multiple Monitors When the Artisul Display and other monitors are used in the same system, the movement of the screen cursor on the standard display depends on the system configuration.
  • Page 13 3.2.2 Working Area Setting Define the display area that will be mapped to the screen area. 1. Full Area: the entire active area of the Display. This is the default setting. 2. Same Ratio with LCD. 3. Customized Area: 1.> Enter coordinate values. Or 2>. Drag the corners of the foreground graphic to select the screen area.

  • Page 14: Press Keys Function Setting

    3.2.3 Rotate Working Area By changing the direction of the display to adapt to the left and right hand operation. We provide four directions of choice. 3.3 Press Keys Function Setting Default Setting: Place the cursor on the button or click the button icon to see the default values for the press keys Customizable Press Keys: Select the function to be achieved on the pop-up dialog box, then click APPLY or OK to take effect.

  • Page 15: Dial Setting

    3.4 Dial Setting Enable dial Press the dial and three groups of functions appear at the bottom of the screen, which can be switched by clicking the dial.
  • Page 16 Factory setting: Canvas Zoom in/out, Brush Zoom in/out , Scroll up/down 0 left rotate → Ctrl + = (Canvas Zoom out) 0 left rotate → Ctrl + - (Canvas Zoom in) 1 left rotate → ] (Brush Zoom out) 1 left rotate → [ (Brush Zoom in) 2 left rotate →...

  • Page 17: Pen Button Setting

    Windows Radial Dial Controller offers users creative shortcuts and is compatible with Windows Radial Controller Protocol. While Windows Radial features will be activated once you select “Enable Windows Radial” via the driver. Long press the key on the centre of the Dial Controller to call up a tool menu, users can use Dial Controller to adjust the brush size, pick the color and scroll through the pages, etc.s Please Note:...

  • Page 18: Pressure Sensitivity Setting

    3.6 Pressure Sensitivity Setting The pressure sensitivity will be changed by dragging the slider up and down, the smaller the value, the more sensitive the pressure.

  • Page 19: Pen Pressure Testing

    3.7 Pen Pressure Testing You can gradually apply pressure to the stylus on the screen to test the pressure level. 3.8 Enable the Windows Ink feature Microsoft Windows provides extensive support for pen input. Pen features are supported in such as Microsoft Office、Windows Journal、Adobe Photoshop CC、 SketchBook 6 and so on.

  • Page 20: Calibration

    3.9 Calibration Screen Calibration: Click the red point of the cross center appearing on the screen to complete the calibration. Restore Factory Settings: Click "Restore Default" to restore to the factory settings. Cancel Calibration: Click"Cancel calibration”or press ESC on the keyboard to cancel the calibration.

  • Page 21: Data Export And Import

    3.10 Data Export and Import The driver supports exporting and importing your customized configuration data of the product, which is convenient for you to use different software and avoid the trouble of repeated settings.

  • Page 22: Specifications

    4. Specifications ITEM D16 Pro Panel Size 15.6 inch Resolution 1920 x 1080 (16:9) LCD Type IPS LCD Active Area 344.16 x 193.59 mm Contrast Ratio 1000:1 Brightness 220 cd/m Screen Response Time 25 ms 89°/89°(H)/89°/89°(V) View Angle (Typ.)(CR＞10) 90% Adobe RGB...

  • Page 23: Trouble Shooting

    Dimension 437.8 x 251.2 x 11.5mm Net Weight 1.3 Kg (without stand) Adjustable Stand 45°, 41.5°, 37°, 22.5°, 19.5°, 14.5° OS Support Windows 7 or later, macOS 10.12 or later 5. Trouble Shooting 5.1 Possible Breakdowns Related to DISPLAY Abnormal Phenomena Possible Solutions ...

  • Page 24: Possible Breakdowns Related To Functions

    10mm There is a deviation between Try calibration the tip and the cursor 6. After-service Contact If you have any questions, please feel free to contact us at: Website: www.artisul.com Email: service@artisul.com...
