TiGHT AV MSW-H412AC-DS User Manual

4x2 18g hdmi 2.0 matrix switcher with usb-c

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

User Manual

MSW-H412AC-DS

4x2 18G HDMI 2.0 Matrix Switcher

with USB-C

Version: MSW-H412AC-DS_2021V1.0

Table of Contents

Need help?

Do you have a question about the MSW-H412AC-DS and is the answer not in the manual?

Questions and answers

Summary of Contents for TiGHT AV MSW-H412AC-DS

Page 2 4x2 18G HDMI 2.0 Matrix Switcher with USB-C Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
Page 3 4x2 18G HDMI 2.0 Matrix Switcher with USB-C SAFETY PRECAUTIONS To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. • Unpack the equipment carefully and save the original box and packing material for possible future shipment.
Page 4: Table Of Contents
4x2 18G HDMI 2.0 Matrix Switcher with USB-C Table of Contents Product Introduction ......................1 1.1 Features ......................1 1.2 Package List ......................2 1.3 Customer Service ....................2 Specification ........................3 Panel Description ......................5 Front Panel ........................ 5 Rear Panel .........................
Page 5: Product Introduction
4x2 18G HDMI 2.0 Matrix Switcher with USB-C Product Introduction Thanks for choosing the TiGHT AV 18G 4x2 HDMI Matrix Switcher. The switcher features 3 HDMI inputs, 1 USB-C input and 2 HDMI outputs. It supports HDMI 2.0b, 4Kx2K@60Hz 4:4:4, HDR 10, Dolby Vision, and HDCP2.3. In addition, the USB-C supports external 60w charging and the HDMI outputs supports 4K auto downscaling to 1080p.
Page 6: Package List
4x2 18G HDMI 2.0 Matrix Switcher with USB-C 1.2 Package List • 1 x MSW-412AC-DS • 2x Mounting Ears with 4 Mounting Screws • 1 x DC 24V5A power adapter with EU plug • 1 x IR receiver (5V) • 1 x IR Remote •...
Page 7: Specification
4x2 18G HDMI 2.0 Matrix Switcher with USB-C Specification Video Video Input (3) HDMI, (1) USB-C HDMI Input Resolution Up to 4K@60Hz 4:4:4 HDR10, Dolby Vision USB-C Input Resolution Up to 4K@60Hz 4:4:4 Video Output (2) HDMI Video Output Connector (2) Type-A female HDMI HDMI Output Resolution Up to 4K@60Hz 4:4:4 HDR10, Dolby Vision...
Page 8 4x2 18G HDMI 2.0 Matrix Switcher with USB-C General -5 - +55℃ Operation Temperature -25 - +70℃ Storage Temperature Relative Humidity 10% - 90% External Power Supply Input: AC 100-240V, 50/60Hz; Output: 24V DC 5A. Power Consumption 76w (Max) USB-C Power Charging 60w (Max) Dimension (W*H*D) 315W * 44H * 165D mm...
Page 9: Panel Description
4x2 18G HDMI 2.0 Matrix Switcher with USB-C Panel Description Front Panel CHARGING MSW-H412AC-DS ① FW: Micro USB port for firmware upgrade. IR sensor: Built-in IR sensor, receives IR signal sent from IR remote. PWR: The LED illuminates green when power is on, and it illuminates red when the unit is standby.
Page 10: Rear Panel
4x2 18G HDMI 2.0 Matrix Switcher with USB-C Rear Panel INPUTS OUTPUTS AUDIO OUTPUTS CONTROL AUDIO 1 SPDIF 1 AUDIO 2 SPDIF 2 IR EYE R S232 TCP/IP DC 24V DOWNSCALING ① INPUTS: 3 x Type-A HDMI input ports to connect HDMI source devices. 1 x USB-C input port to connect USB-C source devices.
Page 11: System Connection
18G 4x2 HDMI Matrix Switcher System Connection Usage Precaution • Make sure all components and accessories included before installation. • System should be installed in a clean environment with proper temperature and humidity. • All the power switches, plugs, sockets, and power cords should be insulated and safe.
Page 12: Front Panel Control
18G 4x2 HDMI Matrix Switcher Front Panel Control The matrix switcher can be controlled by using the buttons on the front panel. In normal working state, all buttons illuminate white with backlight, and it will illuminate blue when it is clicked. If there is no operation within 30s, the front panel enters the dormant state, and all the button backlights are off.
Page 13: Preset Save/Recall Function
18G 4x2 HDMI Matrix Switcher Preset Save/Recall Function PRESET button can save the current video and audio routing and audio settings or load a saved layout preset. ⚫ Save the current video and audio routing and audio settings to a preset Example: Save the current layout to preset 2.
Page 14: Gui Control
18G 4x2 HDMI Matrix Switcher GUI Control The switcher features a Web UI for configuration and control. The default IP settings are: IP Address: 192.168.0.178 Subnet Mask: 255.255.255.0 Type 192.168.0.178 in the web browser, it will enter the below log-in webpage: Username: admin Password: admin Type the user name and password, and then click Login to enter Web UI.
Page 15: Av Routing
18G 4x2 HDMI Matrix Switcher AV Routing ⚫ Video Routing Use the 4x2 button grid on the page to set which inputs are directed to which outputs. For example, clicking the button on the Input 1 row and Output 1 column, directs input1 to output 1.
Page 16 18G 4x2 HDMI Matrix Switcher ⚫ Audio Routing Use the drop-list to select to de-embed audio from input or output source. Audio Follow Video: The audio source is always de-embedded from the video input to the corresponding audio output. Example: Video input 1 is routed to video output 2 then the audio de- embedded from video input 1 is routed to audio output 2.
Page 17: I/O Configuration
18G 4x2 HDMI Matrix Switcher I/O Configuration ⚫ EDID Settings Drop-down the EDID list to select EDID for input ports. How to upload user-defined EDID: 1) Prepare the EDID file (.bin) on the control PC. 2) Select Browse and then select the EDID file (.bin) accordingly. 3) Click Upload file.
Page 18 18G 4x2 HDMI Matrix Switcher ⚫ HDCP Input Settings: HDCP Advertising ON/OFF. When ON the input presents itself as HDCP compatible. When OFF the input presents itself as non-HDCP compatible (to use in applications with for eg. Apple devices to prevent HDCP encryption for content that doesn´t require encryption) ⚫...
Page 19: Device Settings
18G 4x2 HDMI Matrix Switcher Device Settings ⚫ Device Settings 1) Display the model’s name, mac address, serial number, firmware version. 2) Firmware Update: Updates the MCU firmware. 3) Factory Reset: Reset the unit to factory. 4) Reboot Unit: Reboots the unit. ⚫...
Page 20 18G 4x2 HDMI Matrix Switcher ⚫ Input Name, Output Name, Audio Output Name, User-defined EDID Name, User-defined RS232 Name. User-defined interface naming or identification naming.
Page 21: Cec
18G 4x2 HDMI Matrix Switcher If the input source devices and local HDMI output devices support CEC, they can be controlled via the following CEC interface. ⚫ Input CEC Select one or several HDMI input source devices to be controlled, and then press function buttons.
Page 22: Control
18G 4x2 HDMI Matrix Switcher Control ⚫ RS232 1) ASCII or HEX command format can be selected. 2) Baud Rate: Supports 2400, 4800, 9600, 19200, 38400, 57600 or 115200. 3) Command Ending: NULL, CR, LF or CR+LF can be chosen. 4) User-defined Command: Type the command in this box to control the third- party device which is connected to the RS232 port of the switcher.
Page 23: Ir Control
18G 4x2 HDMI Matrix Switcher IR Control ①. Enter/exit standby mode. ①. Blinking red when a button is pressed. ②. Video source selection buttons. ③. Output channel selection buttons. ④. Menu buttons: ⚫ ALL: Select all inputs or all outputs. ⚫...
Page 24: Device Control
Command Protocol 8.3.1 Device Settings Command & Feedback Command Description Example poweron Exit standby mode poweron ok poweroff Exit standby mode poweroff ok 4x2 18g matrix switcher! msw-h412ac-ds! firmware:1.0.0! Query system status and port poweron! getstatus status. fplock:on! setbaudrate:6! ip:192.168.0.178! set,1,1!
Page 25 18G 4x2 HDMI Matrix Switcher set,2,2! hdmisyncon,1! hdmisyncoff,2! downscaleon,1! downscaleoff,2! audiofollowon! seta,1:2! seta,2:2! analogdelay,1:200! analogdelay,2:200! spdifmute,1! spdifunmute,2! mute,1! unmute,2! lovol,1:25! lovol,2:50! in 1 2 3 4 link n n n n out 1 2 link n n edid,1:1 internal! edid,2:1 internal! edid,3:1 internal! edid,4:1 internal! out 1 follow display!
Page 26: Av Routing
18G 4x2 HDMI Matrix Switcher setipstatic Set IP mode to Static setipstatic ok setipdhcp Set IP mode to DHCP setipdhcp ok getip Query IP of the device ip:192.168.1.10 8.3.2 AV Routing Command & Feedback Command Description Example Switch video input [x] to output x = 1 - 4 1 - input 1 2 - input 2...
Page 27: Audio Settings
18G 4x2 HDMI Matrix Switcher audiofollowon! seta,1:2! Query audio switching status. getseta seta,2:1! 8.3.3 Audio Settings Command & Feedback Example Command Function y = 0 - 2 0 - all audio outputs 1 - audio output 1 2 - audio output 2 lovolinc:y lovolinc:y lovol,y:z ok lovoldec:y...
Page 28: Hdcp Management
18G 4x2 HDMI Matrix Switcher Deactivate Audio Follow Video audiofollowoff ok audiofollowoff 8.3.4 HDCP Management Command & Command Description Feedback Example Enable HDCP advertising (HDCP compatibility mode) on input [x] x = 0 - 4 0 - all inputs hdcpadvertisingon,x ok hdcpadvertisingon,x 1 - input 1 2 - input 2...
Page 29: Edid Management
18G 4x2 HDMI Matrix Switcher 8.3.5 EDID Management Command & Feedback Command Description Example resetedid Reset to the default EDID resetedid ok Upload user-defined EDID xx = 00 - 04 00 - all inputs 01 - input 1 02 - input 2 03 - input 3 setuseredid:xx 04 - input 4...
Page 30: Function Settings
18G 4x2 HDMI Matrix Switcher Z€癤奬 0mU!\0\0 1 - output 1 2 - output 2 \0\0\0 \0M94G676L141I \0\0\0 黒 0DELL S2817Q \0\0\0 齖 0 K ?\0 ;馯 a`_^] # ?\0\0m \0 \0\0< \0` g 豜?x?? t\00 騪 Z€癤奬 0mU!\0\0 Ml€爌 p>€0 :\0mU!\0\0 V^\0 牋?P0 5\0mU!\0\0 \0\0\0\0\0\0\0\0\0\0\0\0\0\0...
Page 31 18G 4x2 HDMI Matrix Switcher downscaleon,1! Query the downscaling status of the getdownscale downscaleoff,2! HDMI output ports Turns off the charging on the USB-C setusbcpoweroff setusbcpoweroff ok input Turns on the charging on the USB-C setusbcpoweron ok setusbcpoweron input Query the charging status for the usbcpoweron! getusbcpower USB-C port...
Page 32 18G 4x2 HDMI Matrix Switcher bb, cc, dd are all hexadecimal data; x represents the input port, the input is 1-4, y represents the output port 1-2 (HDMI:01- FF represents all; bb: Represents device type (TV :40,20,80, Disc player 04,08, etc.); Example：...
Page 33 18G 4x2 HDMI Matrix Switcher dd: represents the specific data under the function (for example, 41, represents the volume of the remote control code plus). This can send two or three groups of combined data, or it can not send up to 9 groups according to the instructions.
Page 34 18G 4x2 HDMI Matrix Switcher Automatically send the hex command zzzz on the local RS232 using the specified baud rate x when entering poweron status. x = 1 - 7 1 - 2400 sendhexpowon,x:zzzz ok 2 - 4800 sendhexpowon,x:zzzz 3 - 9600 4 - 19200 5 - 38400 6 - 57600...
Page 35: Firmware Upgrade
18G 4x2 HDMI Matrix Switcher Firmware Upgrade MCU upgrade by USB Please follow the steps as below to upgrade firmware by the FW port on the front panel: 1) Prepare the latest upgrade file (.APP) and rename it as “08010000.APP” on PC. 2) Power off the switcher and connect the FW port of switcher to the PC with USB cable.
Page 36: Gui Upgrade
18G 4x2 HDMI Matrix Switcher GUI Upgrade Please visit web server at the device IP-address and port number 100 for GUI online upgrade. Example using the default IP-address: http://192.168.0.178:100. Type the username and password (the same as the GUI log-in, modified password will be available only after rebooting) to login the configuration interface.
