Wide Conversion Lens System
LN-11S1A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LN-11S1A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Marantz LN-11S1A

  • Page 1 Wide Conversion Lens System LN-11S1A...
  • Page 2 Keep these instructions. Heed all warnings. U.S. Responsible Party: Marantz America, Inc. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth.
  • Page 3 Marantz. como referencia cuando tenga que hacer uso del seguro o se ponga en contacto con Marantz. IMPORTANT When seeking warranty service, it is the responsibility of IMPORTANTE the consumer to establish proof and date of purchase.
  • Page 4 - Do not remove the cover from the equipment. English - Do not insert anything into the equipment through the The LN-11S1A is in conformity with the ventilation holes. EMC directive and low-voltage directive. - Do not handle the mains cord with wet hands.

  • Page 5: Table Of Contents

    A Marantz ceiling mount kit, MOUNT20, is required If you look into the lens during projection, light will if you will be using a Marantz VP11 or VP15 series enter your eyes, possibly resulting in eye pain and/ projector suspended from the ceiling. Be sure to or problems of vision.

  • Page 6: Before Use

    BEFORE USE CHECKING THE UNIT AND SUPPLIED ACCESSORIES Before use, check that the main unit and supplied accessories given below are assembled. • Anamorphic lens x 1 • AC power cord (for U.S.A.) x 1 • AC power cord (for Europe) x 1 •...

  • Page 7: Basic Operation

    Figure 1 Note: TURNING THE POWER OFF Do not move the LN-11S1A lens slider by hand. If To turn the unit’s power off, unplug the plug of the the lens slider was moved by hands, it might cause AC/DC adapter from the DC jack. The unit’s power failure.

  • Page 8: Concerning Connectors And Cables

    The operating range for a remote controller and this unit is shown in the figure below. TRIGGER CONNECTOR The +12 TRIGGER IN/OUT jacks on the LN-11S1A are used to input/output signals that move the anamorphic lens into the operating position and return it to standby position.

  • Page 9: Advanced Operation

    In addition, there is a possibility that the projected image may stick out beyond the left and right screen borders when using the LN-11S1A with a screen you already own. In this case, be sure to change the projector’s zoom setting or its installation location. For details on the projector’s installation location, refer to the user’s guide included with your projector.

  • Page 10: Setup Procedure

    SETUP SETUP PROCEDURE Install the LN-11S1A according to the procedure outlined in the flowchart below. Start Mounting on the floor? EXT10 Assemble the EXT10. needed? (Page. 6) Prepare the LN-11S1A. (Page. 7) Assemble the MOUNT20. (Page. 7) Mount the LN-11S1A.

  • Page 11: Preparing The Ln-11S1A

    Figure 8: Secure the projector to the base plate using the MOUNT20 and LN-11S1A Mounting plates specified screws, and secure the lens slider with anamorphic lens attached to the base plate. Secure the lens slider to the base plate using the supplied machine screws (M3 x 8) in 6 locations.
  • Page 12 Plate #3 Plate #1 Figure 12 Caution: The Projector together with the mounting brackets weighs 59 pounds (26.7kg). Tighten all the recently install hardware and proceed to install the LN-11S1A. Titing Capability Titing Capability Figure 14 Figure 13 Figure 15...

  • Page 13: Mounting The Ln-11S1A (On The Ceiling)

    MOUNTING THE LN-11S1A (ON THE CEILING) Mount the assembled LN-11S1A and MOUNT20 to the projector. Refer to Figure 16. Note: Plate #4 supplied with the MOUNT20 is located in a separate shipping carton from the projector or LN-11S1A. Spread a soft cloth on a stable, horizontal...

  • Page 14: Mounting The Ln-11S1A (On The Floor)

    Figure 23 Figure 24 Figure 25 CONNECTING THE LN-11S1A Connect the LN-11S1A to a power supply and the projector. Install the AC/DC adapter and attach the AC cable to the AC/DC adapter. Refer to Figure 26. During use, always use the supplied AC/DC adapter.

  • Page 15: Adjusting The Ln-11S1A Lens

    You can easily align lens centers between lens, refer to “BASIC OPERATION” on page 3. your projector and LN-11S1A and adjust the tilt of LN-11S1A as well, if you mark a Before starting LN-11S1A lens adjustment, certain position at your screen as a guide to projector installation and initial settings align.

  • Page 16: Troubleshooting

    Immediately unplug the AC/DC adapter from the power outlet and contact the store where you purchased the product, your nearest Marantz Consumer Marketing sales office, a Customer Consultation Center, or Marantz Service Center.

  • Page 17: Specifications & Dimensions

    SPECIFICATIONS & DIMENSIONS MAIN UNIT Terminals Trigger input 3.5 mm diameter monaural mini-jack Input resistance, approx 20k Ohms ... 1 system Trigger output 3.5 mm diameter monaural mini-jack Direct connection to trigger input ... 1 system (Max. 350 mA) Power supply 5 V DC input (special AC/DC adapter) Maximum External Dimensions Width: 14-5/16 inches (363 mm)
  • Page 18 You can find your nearest authorized distributor or dealer on our website. is a registered trademark. Printed in Japan 07/2008 541110132008M sgn-g...
