2665 Series Operation Manual
EZT-2665-8000/6
A B – D
PPENDIX ATA
Note, the printer output configuration is set to 9600 baud, 8 data bits, 1 stop bit and no parity.
A A
PPLIED COUSTIC
The AAE string has 76 characters including carriage return and line feed when not
in GPS mode.
i,t,hhmmss,xxxxx.x,yyyyy.y,zzzzz.z,rrrr.r,bbb.b,dd.d,ccc.c,RRR.R,ppp.p,SSSCL
Description
Beacon identification (1 to 3)
Data type: Unsmoothed (1), Smoothed (3)
Hour
Minute
Second
X (or Eastings)
Y (or Northings)
Z (Depth)
Slant range
Bearing to target
Depression angle
Compass
Roll
Pitch
Status (see overleaf)
Carriage return (CR)
Line Feed (LF)
All ranges and positions are in metres and angles are in degrees.
Note fields are comma separated. Leading 0's (except time) and empty fields are
space filled. When in GPS mode, the X, Y and Z fields automatically expand to
take the full GPS data value.
__________________________________________________________________________________________________________
O
UTPUT FORMATS
E
NGINEERING
(AAE) D
ATA STRING
Page 43 of 64
String code
i
t
h
m
s
x
y
z
r
b
d
c
R
p
S
C
L
