Triumph 45-6736W Assembly Instructions Manual
  1. Manuals
  2. Brands
  3. Triumph Manuals
  4. Play Sets & Playground Equipment
  5. 45-6736W
  6. Assembly instructions manual
Triumph 45-6736W Assembly Instructions Manual

Triumph 45-6736W Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
W e strive to ensure that our produc t s are of the highest quality
and free of manufacturing defec t s or missing p ar t s. Howeve r , if
you have any problems with your new product,
DO NOT RETURN IT T O THE S T OR E
F AX: 1-866-873-3535
gameroom@escaladesports.com
Please have your model number when inquiring about parts.
When con t ac ting Escalade S por t s please provide your model numbe r , date code (i f
appli cable ), and pa rt nu mbe r i f reque sting a repla c e men t pa rt. The s e nu mbe rs a re
lo c a ted on the p rodu ct, pa ckaging , and in thi s owne rs manual .
Y our Model Number :
2-45-6736F-
Date Code:
Purchase Date:
PLEASE RETAIN THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE
please contact us toll free @:
1-88 8 - 9 9 6 - 2 7 2 9
Or w r i t e t o :
Escalade Sport s
Customer Service Departmen t
P .O. B o x 88 9
Evan sville I N 4770 6
45-6736W/F
-HL
1
,

Advertisement

loading
Need help?

Need help?

Do you have a question about the 45-6736W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Triumph 45-6736W

Summary of Contents for Triumph 45-6736W

  • Page 1 ), and pa rt nu mbe r i f reque sting a repla c e men t pa rt. The s e nu mbe rs a re lo c a ted on the p rodu ct, pa ckaging , and in thi s owne rs manual . 45-6736W/F Y our Model Number :...
  • Page 2 IMPORTANT! READ EACH STEP IN THIS MANUAL BEFORE YOU BEGIN THE ASSEMBLY. TWO ADULTS ARE REQUIRED TO ASSEMBLE THIS 4-IN-1 AIRZONE SWIVEL TABLE SOCCER, BILLIARDS, AIR HOCKEY, TABLE TENNIS PLUS BONUS AIRZONE SOCCER GAME Tools Required: Allen Wrench (Included) Phillips Screwdriver Furniture Polish and Cloth Assembly Tips Make sure you understand the following tips before you begin to assemble your hockey table.

  • Page 3: Hardware Identifier

    HARDWARE IDENTIFIER (To Scale) H1 = 8 pcs H2 = 8 pcs H3 = 8 pcs H4 = 8 pcs 4 mm x 22 mm 4.5 mm x 10 mm M4 Nylock Nut 6 mm x 40 mm Flat Washer Allen Head Bolt Phillips Head Bolt H5 = 24 pcs...
  • Page 4 IDENTIFIER (Not to Scale) PARTS P1 - Main Cabinet P2 - Leg Top P3 -Right Leg P4 - Left Leg (1 pc) End Apron (2 pcs) (2 pcs) (2 pcs) P5 - Side Leg Panel P6 - End Leg Panel P7 - Center Frame Support P8 - Top Side End Panel (2 pcs) (2 pcs)
  • Page 5 P21 - Billiard Playfield P22 - Corner Pocket P23 - Side Pocket P24- Removable Bushing Cap with Push Lock (1 pc) Shield Shield (2 pcs) (4 pcs) (8 pcs) A2 - Table Tennis Paddle A3 - Table Tennis Ball A4- Table Tennis Net Post A5 - Cue Stick (2 pcs) (2 pcs)

  • Page 6: Parts Required

    PARTS REQUIRED: 1 pc - P21 Billiard Playfield 1 pc - P1 Main Cabinet 2 pcs - H11 Plastic Pivot Bolt Step 1 Please inspect the main cabinet and playing surfaces before putting the game together. Remove all the contents from inside the carton and verify that you have all listed parts as shown on the parts list. NOTE: Parts are packed inside and under the table cabinet.
  • Page 7 PARTS REQUIRED: 12 pcs - H8 3.5 x 14mm Phillips Round Head Screw 4 pcs - P22 Cornet Pocket Shield 16 pcs - H12 3.5 x 28mm Phillips Round Head Screw 2 pcs - P23 Side Pocket Shield Step 2 Before Starting Step 2, Double Check That All Loose Table Components and Packing Materials Are Removed From The Main Table Cabinet.
  • Page 8 PARTS REQUIRED: 2 pcs - P2 Leg Top End Apron 2 pcs - P3 Right Leg 2 pcs - P4 Left Leg 4 pcs - P20 Lock / Latch 8 pcs - H1 4 x 22mm Phillips Head Bolt 8 pcs - H2 4.5 x 10mm Flat Washer 8 pcs - H4 6 x 40mm Allen Head Bolt 8 pcs - H5 6.5 x 16mm Flat Washer 8 pcs - H3 M4 Nylock Nut...
  • Page 9 PARTS REQUIRED: 2 pcs - P9 Ball Storage Board-Lower 2 pcs - P10 Goal Box 4 pcs - P12 Leg Leveler 18 pcs - H6 4 x 40mm Phillips Round Head Screw Step 6 Note : Predrilled holes Screw the Ball Storage Board-Lower P9 to the Leg Top End Apron P2 using screws H6 into predrilled holes.
  • Page 10 PARTS REQUIRED: 2 pcs - P5 Side Leg Panel 2 pcs - P7 Center Frame Support 8 pcs - H6 4 x 40mm Phillips Round Head Screw 2 pcs - P6 End Leg Panel 16 pcs - H5 6.5 x 16mm Flat Washer 16 pcs - H7 6 x 25mm Allen Head Bolt Step 8 With the help of another adult, attach the Side Leg Aprons P5...
  • Page 11 Step 10 Install the Main Cabinet P1 by sliding the Plastic Pivot Bolts H11 into the 2 slots on each Leg Top End Apron P2. Make sure the plastic pivot bolts H11 rests in the slots on each end of the Leg Top End Apron P2. Note: Make sure all 4 lock / latches are in “unlocked”...
  • Page 12 PARTS REQUIRED: 2 pcs - P8 Top Side End Panel 2 pcs - P13 Manual Scorer 1 pc - A14 A/C Adapter 12 pcs - H9 3.5 x 35 mm Phillips Flat Head Screw 4 pcs - H10 3.5 x 25 mm Phillips Flat Head Screw Step 11 Attach Top Side End Panels P8 to the assembled leg pedestals by aligning the holes in the Top Side...
  • Page 13 PARTS REQUIRED: 2 pcs - 1 pc - 1 pc - White 3-player Rod Assembly White 5-player Rod Assembly White 2-player Rod Assembly 2 pcs - 1 pc - 1 pc - Red 3-player Rod Assembly Red 5-player Rod Assembly Red 2-player Rod Assembly 8 pcs - Removable Bushing Cap with Pusk Lock...
  • Page 14 PARTS REQUIRED: 1 pc - 2 pcs - 1 pc - Table Tennis Net Table Tennis Net Post Table Tennis Board Step 14 (Rotate Table To Play Billiards) To swivel table, first - remove all 8 pcs Removable Bushing Caps A16. Second - remove and stow all Player Rods as per Diagram below.
  • Page 15 AIR POWERED HOCKEY: 1.This game is designed to be played with two (2) players, one at each end. Plug in A/C Adapter. 2.Play begins when the puck is placed on the playing surface. Players must hit the puck with the hand-held pushers and attempt to shoot into the opponent’s goal.
  • Page 16 Female Bushing Replacement In the remote chance that the female rod bushing may need to be replaced , please follow these replacement directions. 1. Call our Customer Service Department at 1-888 on the front of your assembly manual and request the bushing replacement. 2.
  • Page 17 Congratulations! You have now assembled your Swivel Table. Please note the Care and Use instructions below to ensure many years of trouble free use of your Swivel Table. CARE AND USE OF YOUR SWIVEL TABLE . 1 Use only a suitable 120v AC household outlet, and insure the cord is not a trip hazard. For long life and best play from your air hockey table, apply spray furniture polish to clean cloth and wipe down the playfield with air motor running to make the pucks slide faster before first play and frequently thereafter.

  • Page 18: 90-Day Limited Warranty

    90 DAY LIMITED WARRANTY This consumer warranty extends to the original consumer purchase of any ESCALADESPORTS Product (hereinafter referred as the "Product"). WARRANTY DURATION: This Product is warranted to the original consumer purchase of a pe- riod of 90 days from the original purchase. WARRANTY COVERAGE: ESCALADE SPORTS warrants to the original Consumer Purchaser that any Product of its manufacture is free from defects in material and workmanship when used for the intended purpose under normal use and conditions.

This manual is also suitable for:

45-6736f
