- Page 1 GODIO Intelligent Remote Control Bait Boat Product Operation Instruction (Product Model: V80) FUTURE CARPING LTD...
- Page 2 If you have any questions regarding the boat, please contact our after-sale service personnel by telephone. Future Carping 01623 900 073 Thanks for your cooperation!
- Page 3 All friends and new and old customers are sincerely welcome to visit our factory, guide us and negotiate with us for common development. 2. Product introduction Parameters of V80 Bait Boat: Product model: V80 Dimension: 80cm (L) * 40cm (W) * 28cm (D) Boat...
-
Page 4: Packing List
Basic Two sets of lithium batteries (12V31AH) with 5-hour duration, or parameters two sets of lead acid batteries (12V14AH) with 1.5-hour duration High-performance high-torque ultra-silence motor Waterproof design of the whole boat Double boat body design and resistance to Class 5-6 storm Double motor driving, best operation and control performance and ability to turn around in situ Product... - Page 5 compartment is covered and it is kept waterproof. After using, open the battery cover to check if the battery compartment has any water in it, ventilate the boat in a dry place, and keep the inside of the boat body dry. 3.
- Page 6 stop operation immediately and charge the boat batteries. 8. The power indicator of the remote controller will gradually change from green to red during use. When the power of the remote controller is low, the power indicator will start to flicker and give out an alarm. Please replace the batteries of the remote controller and make sure that the boat power is turned off during replacement (For GPS automatic driving configurations, please refer to the precautions of automatic driving function).
-
Page 7: Operation Guidance
out your hook bait and towing out the fishing line, do not reverse for a long time to prevent the fishing line winding in the propeller. 12.When the boat is in the course of posting and transportation, place the lithium batteries or lead acid batteries in the designed foam packing slot and fix them. - Page 8 First open the left and right battery compartment covers with the screwdriver, take two batteries from the foam box, place them into the left and right battery compartments of the boat, connect the battery power lines at two ends respectively. Cover the left and right compartment hatches.
- Page 9 controller switch. The power indicator of the remote controller will be If a rear explosion hook hopper is required, please note that the fishing line should go through the reserved single or double line slot. Each time when the hopper door is opened, it is accompanied by flickering of the indicator.
- Page 10 The toggle switch in the upper left corner of the remote control is the front and rear lights switch of the boat, which is off when pushed upward, low brightness if it is pushed to the middle, and high brightness if it is pushed downwards.
- Page 11 stable. When 10 satellites are available, the automatic driving function can be enabled. When more than 15 satellites are available and the boat is located in an open area without any obstacles, the positioning precision can reach about 1m. （2）Every time the boat arrives at the fishing lake, please first set the origin to ensure that the boat can automatically return to the origin in case of an emergency.
- Page 12 20%, the remote controller will give out the power alarm and the red power indicator of the boat will begin to flicker. At this time, the boat may enable automatic returning function in case of lower power. You should stop using the boat immediately and charge it. （6）The remote controller should be powered by high-quality AA-sized batteries.
- Page 13 course auto-adjust function during the process of finding fish, because the automatic speed adjustment of the motor may interfere with the power supply voltage of the fish finder. 3-2 Operation introduction to GPS automatic driving 3-2-1 Operation instruction for remote controller of GPS automatic driving is as follows 3-2-2 Operation menu of GPS function is as follows...
- Page 14 Startup homepage: The startup homepage includes the satellite quantity, power of remote controller and boat power percentage. The sailing direction will be displayed in real time at the left up corner and the signal strength of the remote control will be displayed at the top right corner.
- Page 15 Homepage (hold Down key) → page at any position point (OK key) → select manual or automatic (Hold the OK key) → enable manual or automatic function The manual operation images are introduced as follows: （5）View the real-time distance of the boat from the origin. This function is operated as follows: Homepage (up key) →...
-
Page 16: Warranty Notes
the battery pack is fully charged, the charger indicator becomes green. Charging Method 1: Directly insert the output port of the charger into the boat charging port (DC charging port on the back side of the boat switch) and charge two battery packs simultaneously. -
Page 17: Common Questions And Troubleshooting
This product is damaged because it is not operated and maintained according to the operation instruction or is incorrectly operated. Any man-made damage (including damage due to the boat falling and hard collision), or any damage due to disassembly and refitting of the repairers not assigned by us. - Page 18 Troubleshooting method: Check the power of the remote controller, replace the batteries, hold the antenna of the remote controller high to the sky, move the remote controller to the boat, and check and replace the antenna. 4. The tail hopper door cannot be opened. Reasons: (1) The electromagnet line falls off (2) The electromagnet is damaged (3) The main control board is damaged.
- Page 19 A user can select to install the following accessories according to personal preferences. 1. GPS automatic driving function 2. Godio Fishing finder (Used on mobile phone or tablet PC) For installation of above configurations, please contact the customer service personnel. For any upgraded configuration selected by the customers, the factory will provide free installation services to the customers.
-
Page 20: Contact Information
4. When any product is repaired, make sure that the information filled in this card is consistent with the information on the purchased product, and post the card to us together with the product. For contact information and address, refer to the following part. IX.
