Owner’s/Installation Manual Docking Station for use with IPAD and IPAD 2 Model: MV-IPAD2 For operational or technical assistance, after reading this manual, please call us toll free at (800) 638-3600 or visit www.magnadyne.com... -
Page 2: Table Of Contents
Features ....... 2 Use this Product Safely ....2 Safety Information . -
Page 3: Docking Station Functions
1. FM Transmitter Adjustment Button: Push the (-) button to tune to a lower radio frequency, press the (+) button to tune to a higher radio frequency. 2. FM Transmitter LCD Display: Displays the audio transmission frequency. 3. Dome Light Button: Press to turn on or off the dome lights. -
Page 4: Inserting An Ipad Into The Overhead Housing
Inserting an IPAD or IPAD 2 into the Overhead Housing 1. Press the release button on the docking housing. Gently pull down the housing. 2. Slide open the docking housing access door. 3. Next rotate the housing access door until it locks in the vertical position. - Page 5 Inserting an IPAD or IPAD 2 into the Overhead Housing (continued) 3c. The IPAD 2 insert should click into place when inserted properly. Continue to Step 4 to insert IPAD 2. 4. Adjust the volume level of the IPAD to 100%. 5.
- Page 6 Inserting an IPAD or IPAD 2 into the Overhead Housing (continued) 7. Connect the IPOD dock connector. Warning: IPOD dock connector can only be inserted one way. The icon on the connector must be facing forward. Inserting the IPOD dock connector incor- rectly will damage the connector or IPAD.
-
Page 7: Removing An Ipad From The Overhead Housing
Removing an IPAD from the Overhead Housing 1. Slide open the docking housing access door. 2. Rotate the housing access door and unplug the IPOD dock connector. 3. Slide the eject button up and remove the IPAD. 4. Close the access door before pushing the housing up into the shroud assembly. -
Page 8: Adjusting The Overhead Housing
Adjusting the Viewing Position: 1. Press the release button on the docking housing. 2. Gently pull down the housing. 3. Adjust the viewing angle. Note 1: Do not force the housing past the maximum opening angle or damage will occur to the housing. Note 2: For optimum viewing performance do not rotate the screen. -
Page 9: Headphone Operation
Basic Operation and Function (continued) Playing Audio Through the Vehicle’s Radio: 1. Press the power button to turn the docking sta- tion on. 2. Press the IPAD Sleep/Wake button and select a program that will play audio. Note: Volume level of the IPAD should be at least 100%. -
Page 10: Wiring
Power Harness Wiring: The 4-wire harness provides battery and ignition (12 volts DC) as well as a chassis ground. Route the power harness to the point in the vehicle that you will make the connections. Red Wire: The red wire in the harness should be con- nected to a +12 volt power wire that is turned on and of by the position of the ignition key. -
Page 11: Installation
The MV-IPAD must be mounted using a universal shroud/bracket system (purchased separately). 1. Using the screws provided with the universal shroud/bracket system attach the MV-IPAD docking system to the universal shroud. 2. Refer to the instructions included with the shroud/ bracket system on how to mount the bracket. -
Page 12: Warranty
ONE (1) YEAR LIMITED WARRANTY Magnadyne Corporation or its authorized agents will within 1 year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of the...
