Installation and User Manual

Electronic Lock Cylinder IF15x

Table of Contents

Need help?

Do you have a question about the IF15x and is the answer not in the manual?

Questions and answers

Summary of Contents for Interflex IF15x

Page 1 Installation and User Manual Electronic Lock Cylinder IF15x...
Page 2 Nonetheless, errors cannot be excluded completely. Interflex Datensysteme GmbH & Co. KG assumes no responsibility for the information in this manual, which is subject to change without prior notice. Interflex Datensysteme GmbH & Co. KG does not enter into any commitment. Copyright © 2011 Printed on: 21.07.2011 Interflex Datensysteme GmbH &...
Page 3: Table Of Contents
Table of Contents Contents Introduction Short Description ..........................1 Scope of Delivery ........................... 2 Technical Data ..........................4 Installation/Dismantling Installation of the Cylinder Body ..................... 7 Installation of the Knob Module (with Disassembly Card).............. 7 Disassembly of the Knob Module (with Disassembly Card) ............8 Operation Short-Time Release ........................
Page 5: Introduction
Introduction Easy-to-install, highly flexible and yet safe – these are outstanding features of this state-of- the-art electronic locking cylinder. With the IF15x series, you have purchased a cost-effective and integratable solution. Electronic identification media such as e. g. badges or easy-to-handle key tags are used as "keys".
Page 6: Scope Of Delivery
Introduction Scope of Delivery Scope of Delivery IF151 Mechanical knob Cylinder body Knob module Two batteries Fixing screw...
Page 7 Introduction Scope of Delivery IF152 Knob module Cylinder body Knob module Four batteries: Fixing screw...
Page 8: Technical Data
Introduction Scope of Delivery IF153 Half cylinder body Knob module Two batteries Fixing screw Technical Data Dimensions (in mm) Cylinder Dimensions of the cylinder for Euro profile locks according to DIN 18254 Electronic knob 40 × 41 Mechanical knob (only 29,5 ×...
Page 9 Introduction Power supply Batteries Two lithium batteries per electronic knob, type CR2, 3 V Battery life 10,000 actuations (approx.) at 20 °C, depending on the reader type. Storage life Four years (approx.) Open when battery is Possible at any time - external power source required (low-power empty adapter).
Page 11: Installation/Dismantling
H A P T E R Installation/Dismantling Please note:  The cylinder is delivered fully preassembled.  On delivery, the knob module is in the factory state and must be programmed before initial operation/installation. In this regard, see the Service Device instructions for use. ...
Page 12: Disassembly Of The Knob Module (With Disassembly Card)
Installation/Dismantling Step 4: Reset disassembly mode, i.e. hold the disassembly card or an authorized credential in front of the knob module. Disassembly of the Knob Module (with Disassembly Card) Step 1:"Wake up" the knob module by turning it on (if necessary). Step 2: Hold the disassembly card in front of the knob module.
Page 13: Operation
H A P T E R Operation  For operation, appropriate credentials are required (transponder card, key or key tag).  The cylinder is delivered fully preassembled.  On delivery, the knob module is in the factory state and must be programmed before initial operation/installation.
Page 14 Operation Signal sequence: 1 × (green) + 1 × ..(three seconds) ..1 × (green) + 1 × Warning: The locking cylinder is now permanently engaged, and the door can be opened and closed without a credential. To remove the toggle function, repeat the procedure. See also Visual/Audible Signals ...................
Page 15: Batteries
H A P T E R Batteries Battery Warning Summary Using visual and acoustic signals, the lock cylinder indicates that new batteries must be used. You can recognize how urgently the batteries must be replaced with the following signals: Warning level 1 (only visible for administrators) Time interval 1 ...
Page 16 Batteries Warning level 1 Warning level 1 is a very early warning level for administrators (such as the caretaker). For these persons the service flag should be set on their credentials. Credentials with the service flag set are otherwise the same as normal credentials; the owners of these credentials will, however, receive an early warning that the batteries are low (warning level 1) and can react accordingly.
Page 17: Low-Power Adapter
Batteries Warning level 3 The following features are characteristic of warning level 3:  Red LED lights up 1 time (longer than in warning level 2).  Long continuous tone.  The lock cylinder then performs the desired action. It thus reacts after a time delay. Time interval 1 ...
Page 18: Battery Change
Batteries If necessary, align the contacts more accurately (when the adapter is inserted), i.e. grip the knob module and turn the adapter slightly. Battery Change Important materials  Knob module  New batteries  Battery exchange card  Time card. Procedure: Step 1: "Wake up"...
Page 19 Batteries Step 4: Replace the batteries: (if the polarity is incorrect, there is no signal) Step 5 (for current firmware version no longer necessary): Repeat steps 1 and 2: Step 6: Push in the locking pins and reattach the knob module cover: Ensure that the locking pins engage correctly with the cover.
Page 21: Visual/Audible Signals
H A P T E R Visual/Audible Signals Legend : High tone (long, short) : Deep tone (long, short) : LED lights up : LED flashes Idle mode In idle mode the lock cylinder does not provide audible or visual signals (exception see below) Wake up and read mode Meaning...
Page 22 Visual/Audible Signals Meaning Acoustic signal Visual signal Time not set (Red) Door initialization not set (Red) Facility data not set (Red) Battery warning Command execution only after signal Meaning Acoustic signal Visual signal Battery warning, warning – (Red) level 1 (only for credentials with the service flag set) Battery warning, warning...
Page 23 Manipulation mode in idle every second – mode enabled Reset (Green > red) Please contact your Interflex system consultant if the following signals occur: Meaning Acoustic signal Fault while access external EEPROM (such as ee-read without Powerup()) Coupling error RTC fault (clock quartz defective?)
Page 25 Index standard opening • 7 standard release • 7 acoustic signal • 15 technical data • 4 toggle • 7 battery • 9 change • 12 low battery alarm • 9 wake up • 5, 6, 12, 15 low battery warning levels • 9 battery exchange card •...
