SideArm
Instructions Manual
The SideArm sends out a continuous infrared beam that is reflected back by the
presence in front of the urinal or water closet.
SideArm for Urinal
Collar
Gasket
Battery
Compartment
Wrench
Collar Wrench
SideArm for Water Closet
4 "C" Alkaline Batteries
Advertisement
Summary of Contents for DELANY SideArm
- Page 1 SideArm Instructions Manual The SideArm sends out a continuous infrared beam that is reflected back by the presence in front of the urinal or water closet. SideArm for Urinal SideArm for Water Closet Battery Compartment Wrench Collar Gasket 4 “C” Alkaline Batteries...
- Page 2 User-In-View LED (Green) 3. Using the allen-key, close and secure the battery compartment. Install Battery Compartment The last 3 turns of the locking screw will activate the SideArm's electronics, so that it is ready to go. Object Lock Sensor Note: The range on the sensor is factory pre-set. For special circumstances, it can be adjusted.
- Page 3 VISUAL INDICATOR GUIDE User-Detection L.E.D. : This green flashing light will flash 3 times when an object comes in front during operation. (It flashes continuously during the 7 minute start sequence. Object Lock Sensor Low Battery Indicator L.E.D. This is a yellow light that flashes to indicate that the 4 "C"...
- Page 4 Remove dirt or debris,consult valve manufacturer’ s functioning properly directions Replace batteries. Dead batteries Valve does not flush even after Object Lock Sensor has been adjusted Delany Products www.delanyproducts.com (434) 296-0166 1565 Avon Street, Charlottesville, VA 22902 (434) 296 0166 1565 Avon Street, Charlottesville, VA 22902...
