Page 1 Contents BMW M The Ultimate Driving Machine THE BMW M4 COUPÉ. OWNER'S HANDBOOK. Online Edition for Part no. 01402981699 - VI/17...
Page 3 BMW M4. It also contains use‐ ful information which will help you to maintain both the operat‐ ing and road safety of your BMW M4 as well as its full resale value. If applicable, you will find updates after the editorial deadline in the appendix of the printed Owner's Handbook for the vehicle.
Page 4 © 2017 Bayerische Motoren Werke Aktiengesellschaft Munich, Germany Not to be reproduced, wholly or in part, without written permission from BMW AG, Munich. English ID5 VI/17, 07 17 490 Printed on environmentally friendly paper, bleached without chlorine, suitable for recycling.
Page 5: Table Of Contents
Engine compartment following Owner's Handbooks: Integrated Engine oil Owner's Handbook in the vehicle on the Con‐ Coolant trol Display, Online Owner's Handbook, BMW Maintenance Driver’s Guide App. Replacing parts Breakdown Assist General care...
Page 6 We recommend that you read through the first chapter to get an initial overview of the vehicle. Owner's Handbook and general information about BMW, for example on technology, are Updates after going to press available on the Internet: www.bmw.com. Updates following the copy deadline can result...
Page 7: Notes
Notes ››...‹‹ Identifies replies by the voice control In right-hand drive vehicles, some controls are system. arranged differently from those shown in the il‐ lustrations. Actions The actions to be carried out are shown as a Production date numbered list. The sequence of steps must be followed.
Page 8 Consequently, the manufacturer of your vehi‐ cle recommends having corresponding work ▷ Integrated Owner's Handbook in the vehi‐ carried out by a BMW Service Partner. If you cle. select a different specialist workshop, BMW ▷ Online Owner's Handbook. recommends that you select a workshop that ▷...
Page 9 BMW is unable to assess each individual prod‐ systems. uct of outside origin as to its suitability for use on BMW vehicles without safety risk.
Page 10 Notes Control via mobile user devices manufacturer. The vehicle owner can contact a Service Partner of the manufacturer to object Depending on the equipment, mobile end user to the data being saved and transferred to the devices connected to the vehicle, for example vehicle manufacturer.
Page 11 Notes Vehicle identification pertaining to data protection is also provided. Personal data may be used to perform online number services. Data is exchanged over a secure con‐ nection, for example with the IT systems of the vehicle manufacturer intended for this pur‐ pose.
Page 12 Online Edition for Part no. 01402981699 - VI/17...
Page 13: Overview
Overview This chapter shows you the layouts of the different buttons, switches and displays. It also gets you quickly acquainted with the various operating concepts and options. Online Edition for Part no. 01402981699 - VI/17...
Page 14: Driving Area
Overview Driving area Driving area Vehicle equipment of the selected optional equipment or the country specification, may also be described This chapter describes all standard, national here. This also applies to safety-relevant func‐ and special equipment available for the model tions and systems.
Page 15 Driving area Overview Rear fog light 124 Speed limiter 144 Light switch 120 Cruise Control on/off, inter‐ rupt 155 Lights off Cruise Control: to resume a speed Daytime driving lights 122 Side lights 120 Rocker switch for Cruise Control Instrument cluster 101 Low-beam headlights 120 10 Buttons on steering wheel, right Entertainment source, see Own‐...
Page 16 Overview Driving area Steering wheel heating 76 15 To adjust the steering wheel 76 16 To release the bonnet 221 Around the centre console Control Display 18 Park Distance Control, PDC 157 Ventilation 177 Rear-view camera 160 Hazard warning lights 237 Park Assistant 167 Surround view 160 Central locking system 52 Side View 163 Glove...
Page 17 Driving area Overview Adaptive M chassis 153 12 M double clutch transmission selector lever 95 Manual transmission selector lever 95 Servotronic 154 Around the roof lining Emergency call, SOS 237 Reading lights 124 Glass Roof, electric 63 Interior light 124 Front passenger airbag indicator lamp 128 Online Edition for Part no. 01402981699 - VI/17...
Page 18: Idrive
Overview iDrive iDrive Vehicle equipment Controls This chapter describes all standard, national Overview and special equipment available for the model series. Therefore equipment which is not in‐ stalled in your vehicle, for example on account of the selected optional equipment or the country specification, may also be described here.
Page 19 iDrive Overview "Switch off control display" Buttons on the Controller Controller with navigation system Button Function General Press once: calls up main menu. The buttons can be used to call up menus di‐ Press twice: shows all menu items of rectly.
Page 20 Overview iDrive Button Function Press once: calls up the previous screen. Press and hold: calls up the last me‐ nus used. Calls up the Options menu. ▷ Pressing. Operation using Controller Calling up the main menu Press the button. ▷ Tilting in four directions.
Page 21 iDrive Overview Selecting a menu item The arrow indicates that further screens can be called up. Highlighted menu items can be selected. Turn the Controller until the desired menu Calling up recently used menus item is highlighted. The recently used menus can be displayed. Press and hold the button.
Page 22 Overview iDrive Changing between upper/lower case, Turn the Controller until the desired set‐ numbers and characters ting is displayed. Depending on the menu, it is possible to enter upper and lower case letters, numbers and characters. Symbol Function Enter letters. Enter numbers.
Page 23 iDrive Overview Operation by touchscreen General The Control Display is equipped with a touch‐ screen. Touch the touchscreen with your fingers. Do not use any objects. Calling up the main menu A white arrow indicates that further screens Tap the symbol. can be called up.
Page 24 Overview iDrive Entering letters and numbers "Touchpad" Select the desired setting. General ▷ "Write": to enter letters and numbers. Letters and numbers can be entered using the ▷ "Map": to operate the map. Controller or the touchscreen. ▷ "Search fields": to write letters without The keyboard display changes automatically.
Page 25 iDrive Overview Defining the display selection Function Operation The display selection can be defined. To move map. Swipe in the appropriate Tilt the Controller to the right until the split direction. screen is selected. To enlarge/ Pinch together or move Press the Controller.
Page 26 Overview iDrive The settings are saved for the currently used Symbol Meaning driver profile. Sending not possible. Saving a function Contacts are being loaded. Select function via iDrive. Entertainment Press and hold the desired button until a signal sounds. Symbol Meaning Performing a function CD/DVD player.
Page 27: Voice Control System
Voice control system Overview Voice control system Vehicle equipment ›[...] Station ...‹, for example, Classic Radio station. This chapter describes all standard, national and special equipment available for the model series. Therefore equipment which is not in‐ Requirements stalled in your vehicle, for example on account On the Control Display set a language that is of the selected optional equipment or the also supported by the voice control system, so...
Page 28 Overview Voice control system control system. When doing this, list entries With the short variants of the speech dialogue, are to be spoken exactly as they are shown in the system announcements are played in the relevant list. shortened form. Via iDrive: Displaying possible commands "My Vehicle"...
Page 29 Voice control system Overview Via iDrive: "My Vehicle" "iDrive settings" "Language" "Speaking during voice output" Adjusting the volume Turn the volume knob during the spoken in‐ structions until the desired volume is obtained. ▷ The volume setting is retained even if you change the volume of other audio sources.
Page 30: General Settings
Overview General settings General settings Vehicle equipment "Time zone:" Select the desired setting. This chapter describes all standard, national The setting is saved for the currently used and special equipment available for the model driver profile. series. Therefore equipment which is not in‐ stalled in your vehicle, for example on account Setting the time of the selected optional equipment or the...
Page 31 Press the Controller. If vehicle tracking is activated, the current vehi‐ Alter the setting for month and year. cle position can be displayed in the BMW Con‐ The setting is saved for the currently used nected app or in the ConnectedDrive customer driver profile.
Page 32 Overview General settings Some of these information windows can be ac‐ The setting is saved for the currently used tivated or deactivated. driver profile. "My Vehicle" Selecting the content of the main "iDrive settings" menu "Pop-ups" The content displayed in some menu items of the main menu can be selected.
Page 33 The vehicle offers various functions which re‐ ▷ Login accounts. quire data to be transferred to BMW or a serv‐ ice provider. The transfer of data can be deac‐ It can take up to 15 minutes in total to delete tivated for some functions.
Page 34 Overview General settings Deleting data Function Connec‐ Follow the instructions on the Control Display. tion type Via iDrive: Telephoning using the hands- Bluetooth. free system. Switch on the ignition. Operating telephone functions "My Vehicle" via iDrive. "iDrive settings" Using the smartphone Office "Data privacy"...
Page 35 "My Vehicle" Compatible devices "iDrive settings" General "Mobile devices" Information about mobile devices compatible "Settings" with the vehicle is available at www.bmw.com/ "Bluetooth" bluetooth. Malfunctions may occur when using unlisted Activating/deactivating telephone devices or different software versions. functions To be able to use all supported functions of a...
Page 36 Overview General settings Registering the mobile device with the In such cases, the following explanations may vehicle provide assistance: Via iDrive: Why could the mobile telephone not be paired or connected? "My Vehicle" ▷ Too many Bluetooth devices are paired to "iDrive settings"...
Page 37 General settings Overview ▷ Under certain circumstances only the The snap-in adapter has its own USB port phone book entries saved in the mobile tel‐ that is automatically connected when an ephone or on the SIM card are transferred. appropriate mobile telephone is inserted. ▷...
Page 38 Overview General settings ▷ Depending on how the USB device is be‐ "Mobile devices" ing used, it may be necessary to perform "Settings" settings on the USB device, see operating "Internet hotspot" instructions of the device. Unsuitable USB devices: Connecting a device to the Internet hotspot ▷...
Page 39 For more information, see the integrated Own‐ er's Handbook, online Owner's Handbook, Activate or deactivate the function. BMW Driver’s Guide app or, if necessary, the Confirm the entry of the hotspot code or Owner's Handbook for Navigation, Entertain‐ the network name: ment, Communication.
Page 40 Overview General settings Displaying device list Via iDrive: All devices registered or connected to the ve‐ "My Vehicle" hicle are displayed in the device list. "iDrive settings" Via iDrive: "Mobile devices" "My Vehicle" Select the device. "iDrive settings" "Disconnect device" "Mobile devices"...
Page 41 The installation can Updates and related, up-to-date information be performed at a different time from that of are posted on the website at www.bmw.com/ the transfer. update. It is possible to transfer the software during a Displaying installed software version journey.
Page 42 Overview General settings The following steps are dispensed with. "OK" Wait for the update. Confirm the system restart. Restoring the software version It is possible to restore the software to the ver‐ sion prior to the last update or to its factory settings.
Page 43: Integrated Owner's Handbook In The Vehicle
Integrated Owner's Handbook in the vehicle Overview Integrated Owner's Handbook in the vehicle Vehicle equipment pictures. This is particularly useful, for exam‐ ple, if you require a description of an item of This chapter describes all standard, national equipment but do not know its name. and special equipment available for the model series.
Page 44 Overview Integrated Owner's Handbook in the vehicle Calling up when displaying a Check Press and hold required Favourites Control message button for more than 2 seconds. Directly from the Check Control message on the Control Display: Executing/Performing "Owner's Handbook" Press the appropriate button. Switching between a function and the Owner's Handbook is displayed di‐...
Page 45 Integrated Owner's Handbook in the vehicle Overview Online Edition for Part no. 01402981699 - VI/17...
Page 46 Online Edition for Part no. 01402981699 - VI/17...
Page 47: Controls
Controls The information in this chapter helps you to operate your vehicle confidently. All equipment designed to make your journey safer and more comfortable is described here. Online Edition for Part no. 01402981699 - VI/17...
Page 48: Opening And Closing
Controls Opening and closing Opening and closing Vehicle equipment WARNING If the vehicle is locked from the outside, it This chapter describes all standard, national cannot be unlocked from the inside in some and special equipment available for the model country versions.
Page 49 Opening and closing Controls Unlocking Comfort opening Press the button on the remote con‐ Keep the button on the remote control trol. pressed after unlocking. Depending on the settings, see page 59, the The windows and Glass Roof are opened for as following access points are unlocked.
Page 50 Controls Opening and closing Opening The windows and the Glass Roof are closed for as long as the button on the remote control is Press the button on the remote con‐ pressed. trol for approximately 1 second. The exterior mirrors are folded in. Replacing the battery Switching on interior light and Remove the integrated key from the re‐...
Page 51 Opening and closing Controls Additional remote controls If there is a malfunction, the vehicle can be un‐ locked and locked from the outside with the Additional remote controls are available from a integrated key, see page 51. Service Partner of the manufacturer or another qualified Service Partner or a specialist work‐...
Page 52 Controls Opening and closing Alarm system There is a risk of injury or danger to life if per‐ sons remain in the vehicle for extended peri‐ The alarm system is not switched on if the ve‐ ods and are exposed to extreme temperatures hicle is locked with the integrated key.
Page 53 Opening and closing Controls Unlocking ▷ Pull twice on door opener on door to be opened: first pull unlocks door, second pull opens door. The other doors remain locked. Comfort Access Principle This feature allows you to access the vehicle without having to operate the remote control.
Page 54 Controls Opening and closing Closing Opening Use your finger to touch area on door handle of Press the button on the boot lid. the driver or front passenger door and keep This corresponds to pressing the but‐ your finger there without gripping door handle. ton on the remote control.
Page 55 Opening and closing Controls Malfunction when you perform the foot movement, and do not touch the vehicle.◀ It may be difficult for the vehicle to detect the remote control in some conditions, including WARNING the following: Parts of the body can become trapped ▷...
Page 56 Controls Opening and closing Closing sure that the area of movement of the boot lid is free.◀ NOTE The boot lid swings rearwards and up‐ wards when opened. There is a danger of dam‐ age to property. When opening and closing, make sure that the area of movement of the boot lid is free.◀...
Page 57 Opening and closing Controls If several drivers each use their own remote ▷ Navigation. control, the vehicle will adapt to their personal ▷ settings when it is unlocked. These settings ▷ Park Distance Control PDC. are also restored if the vehicle is used in the in‐ ▷...
Page 58 Controls Opening and closing Using a guest profile Exporting driver profile With the guest profile, individual settings can Most of the settings of the currently used be performed that are not saved in any of the driver profile can be exported. three driver profiles.
Page 59 Opening and closing Controls Unlocking ▷ Online. Select the driver profile to be imported. Doors Displaying driver profiles when Via iDrive: starting "My Vehicle" The driver profiles can be shown every time "Vehicle settings" the vehicle is started so that the desired profile "Doors/Key"...
Page 60 Controls Opening and closing Alarm system Setting the last seat and mirror position General Via iDrive: The alarm system responds to the following "My Vehicle" changes when the vehicle is locked: "Driver profiles" ▷ Unauthorised opening of a door, the bon‐ Select driver profile.
Page 61 Opening and closing Controls Indicator lamp on the rear-view mirror Avoiding false alarms General The tilt alarm sensor and the interior move‐ ment detector may trigger an alarm without any unauthorised activity taking place. Possible situations for an unwanted alarm: ▷...
Page 62 Controls Opening and closing Power windows The window closes as long as the switch is held. Safety note ▷ Pull the switch past the resistance WARNING point. Parts of the body can become trapped The window closes automatically when the when the windows are operating.
Page 63 Opening and closing Controls The window is closed with a restricted make sure that the area of movement of the anti-trap mechanism. If the closing force Glass Roof is free.◀ exceeds a certain value, the closing opera‐ tion is interrupted. Overview Pull the switch past the resistance point again within approximately 4 seconds...
Page 64 Controls Opening and closing Movement is stopped by pressing switch exceeds a certain value, the closing opera‐ upwards. tion is interrupted. Comfort opening using the remote control, see page 49. Comfort closing using the remote control, see page 49. Closing using Comfort Access, see page 53. Press the switch forwards once again be‐...
Page 65 Opening and closing Controls Initialising the system Press the switch upwards and hold until the initialisation is complete: Initialisation begins within 15 seconds and is complete when the Glass Roof is fully closed. Online Edition for Part no. 01402981699 - VI/17...
Page 66: Adjusting
Controls Adjusting Adjusting Vehicle equipment WARNING If the seat backrest is angled back too This chapter describes all standard, national far, the protective effect of the seat belt will no and special equipment available for the model longer be guaranteed. There is a danger of series.
Page 67 Adjusting Controls Forward/back Seat angle Pull the lever and slide the seat in the desired Pull the lever and move the seat until the de‐ direction. sired angle is reached. After releasing the lever, sit on and get up out of the seat to make After releasing the lever, move the seat gently sure it engages properly.
Page 68 Controls Adjusting Forward/back Backrest angle Press the switch forwards or backwards. Tip the switch forwards or backwards. Height Lumbar support The curvature of the backrest can be changed in such a way that the lumbar region, the lordo‐ sis, is supported. The upper edge of the pelvis and the spinal column are supported to en‐...
Page 69 Adjusting Controls Seat heating, front WARNING The backrest can unexpectedly move Overview during the journey when it is unlocked. You could lose control of the vehicle. There is a danger of injury. Fold back and lock the backr‐ ests before every journey.◀ Manual longitudinal adjustment Comfort entry The comfort entry contains a memory function...
Page 70 Controls Adjusting Seat belts Electric longitudinal adjustment Comfort entry Number of seat belts and belt buckles The comfort entry contains a memory function For the safety of the vehicle occupants, the ve‐ for the longitudinal and backrest adjustment. hicle is equipped with four seat belts. However, they can only provide effective protection Pull the lever until it stops.
Page 71 Adjusting Controls route the lap section of the belt across the ab‐ qualified Service Partner or a specialist work‐ domen. shop.◀ Do not modify seat belts, belt buckles, belt Correct seat belt use tensioners, belt retractors and belt anchor points and ensure that they are kept clean. A ▷...
Page 72 Controls Adjusting Insert the seat belt tongue in the belt ▷ Green: seat belt fastened on the corre‐ buckle. The seat belt buckle must be heard sponding rear seat. to engage. ▷ Red: seat belt not fastened on the corre‐ sponding rear seat.
Page 73 Adjusting Controls ▷ Before a journey, fit the removed head re‐ ▷ Exterior mirror position. straints on all occupied seats. ▷ Height of the Head-Up Display. ▷ Adjust the head restraint so its centre sup‐ General ports the back of the head at as close to eye level as possible.
Page 74 Controls Adjusting Safety note Press the button. LED in button is WARNING illuminated. Objects reflected in the mirror are closer Press the desired button 1 or 2 while the than they appear. The distance to road users LED is lit. LED is extinguished. behind the vehicle could be incorrectly estima‐...
Page 75 Adjusting Controls Folding in and out Deactivating NOTE Push switch to the front passenger's mirror position. Due to the vehicle's width, it could sus‐ tain damage in car washes. There is a danger of damage to property. Before washing, fold Rear-view mirror, automatic-dim the mirrors in manually or with the button.◀...
Page 76 Controls Adjusting WARNING If steering wheel lock is activated, the ve‐ hicle cannot be steered. There is a danger of accidents. Switch on the ignition prior to mov‐ ing the vehicle.◀ Adjusting Fold the lever downwards. Move the steering wheel to the preferred height and angle to suit your seated posi‐...
Page 77: Carrying Children Safely
Carrying children safely Controls Carrying children safely Vehicle equipment of the selected optional equipment or the country specification, may also be described This chapter describes all standard, national here. This also applies to safety-relevant func‐ and special equipment available for the model tions and systems.
Page 78 Controls Carrying children safely Group Weight of Approxi‐ Front pas‐ Front pas‐ Rear seats, Rear seat, child mate age senger seat, senger seat, outer – b) middle airbag ON airbag OFF – a) 22 – 36 kg 7 years or U, L more U: suitable for child restraint systems in the Universal category that have been approved for use...
Page 79 Carrying children safely Controls WARNING other qualified Service Partner or a specialist workshop and renewed if necessary.◀ If the seat adjustment or child seat instal‐ lation is incorrect, the child restraint system WARNING may have limited stability or may not be stable If the seat adjustment or child seat instal‐...
Page 80 Controls Carrying children safely Before fitting a child restraint on the front pas‐ NEVER use a rearward facing child restraint on senger seat, make sure that the front and side a seat protected by an ACTIVE AIRBAG in airbags on the passenger side are disabled. front of it, DEATH or SERIOUS INJURY to the CHILD can occur.
Page 81 Carrying children safely Controls Group Weight of child Approximate Class/category Front Front Rear Rear – a) pas‐ pas‐ seats, seat, senger senger outer middle seat, seat, airbag airbag Up to 10 kg Approximately E - ISO/R1 9 months Up to 13 kg Approximately E - ISO/R1 18 months...
Page 82 Controls Carrying children safely NOTE The mounting points for the upper re‐ taining straps of child restraint systems are only intended for these retaining straps. The mounting points can be damaged if other ob‐ jects are attached. There is a danger of dam‐ age to property.
Page 83 Serv‐ ice Partner of the manufacturer or another qualified Service Partner or a specialist work‐ shop. ▷ BMW Baby Seat Group 0+ ▷ BMW Junior Seat Group 1 ▷ BMW Junior Seat Group 2/3 ▷...
Page 84 Controls Carrying children safely Mounting point Hook for the upper retaining strap Attaching the upper retaining strap to the mounting point Fold up the fastening point cover. Guide the upper retaining strap over the head restraint. Attach the hook of the retaining strap to the mounting point.
Page 85: Driving
Driving Controls Driving Vehicle equipment To save battery power when the engine is off, switch off the ignition and any unnecessary This chapter describes all standard, national power consumers. and special equipment available for the model series. Therefore equipment which is not in‐ Ignition off stalled in your vehicle, for example on account M double clutch transmission: press the start/...
Page 86 Controls Driving Radio ready state less. In enclosed spaces, the exhaust fumes can also build up outside the vehicle. There is General a danger of fatal injury. Keep the exhaust pipe clear and ensure sufficient ventilation.◀ In the radio ready state, individual current con‐ sumers remain ready for operation.
Page 87 Driving Controls The starting process is activated automatically Press the start/stop button. for a short time and stops as soon as the en‐ The engine is switched off. gine starts. The radio ready state is switched on. Apply the parking brake. Stopping the engine Manual gearbox Safety notes...
Page 88 Controls Driving Engine start ▷ Gearbox in neutral and clutch pedal not pressed. For driving off, the engine automatically starts ▷ Driver's seat belt buckled or driver door under the following conditions: closed. ▷ M double clutch transmission: by releasing The air flow rate of the air conditioning system the brake pedal.
Page 89 Driving Controls ▷ Low brake vacuum, for example because ▷ LED is extinguished: Auto Start Stop func‐ the brake pedal has been pressed a num‐ tion is activated. ber of times in succession. Parking the vehicle during automatic Preventing automatic engine stop engine stop with M double clutch transmission With automatic engine stop, the vehicle can be...
Page 90 Controls Driving Parking brake Pull up the lever a bit, press the button and guide the lever down. Safety note WARNING Turn indicators, high-beam An unsecured vehicle can start moving headlights, headlight flasher and rolling away. There is a danger of acci‐ dents.
Page 91 Driving Controls Indicating a turn briefly are in contact with the windscreen when switching on.◀ Press the lever as far as the resistance point and hold it there for as long as you wish to indi‐ NOTE cate a turn. If the wipers are frozen to the wind‐...
Page 92 Controls Driving Switching off and flick-wiping Activating/deactivating Press the lever down. Press the lever upwards from the home posi‐ tion once, arrow 1. ▷ Switching off: press lever downwards until Wiping is started. the home position is reached. ▷ Flick-wiping: press lever downwards from The LED in the wiper lever is illuminated.
Page 93 Driving Controls Safety notes ity of the washer fluid freezing. Use anti-freeze if required.◀ WARNING NOTE If the wipers start moving when they are folded away from the windscreen, parts of the If the washer fluid reservoir is empty, the body may become trapped or the vehicle may washer pump cannot operate as intended.
Page 94 Controls Driving Lift wipers completely away from the wind‐ WARNING screen. Washer fluid can ignite on contact with hot parts of the engine, and catch fire. There is a danger of injury or damage to property. Only top up washer fluid when the engine has cooled down.
Page 95 Driving Controls Manual gearbox during a gear shift for a harmonious and dy‐ namic gear change. Safety notes Reverse gear WARNING Engage this position only when the vehicle is An unsecured vehicle can start moving stationary. and rolling away. There is a danger of acci‐ To overcome the resistance, move the shift dents.
Page 96 Controls Driving Safety note The engaged selector lever position is shown in the instrument cluster and on the selector WARNING lever. An unsecured vehicle can start moving After a selector lever position has been en‐ and rolling away. There is a danger of acci‐ gaged, the vehicle can roll away when the dents.
Page 97 Driving Controls lever position, and the display in the selector tween forward and reverse gear without apply‐ lever flashes. ing the brakes. In these cases, refer to the display in the in‐ N Neutral, idling strument cluster. In selector lever position N, the vehicle can roll, D Drive mode for example in car washes, see page 244.
Page 98 Controls Driving Displays in the instrument cluster Using the shift paddles on the steering wheel Drive mode ▷ Engaged gear together with a D, arrow 1. ▷ Selected drive programme, Drivelogic, see page 98, arrow 2. Sequential mode ▷ Engaged gear, arrow 1. ▷...
Page 99 Driving Controls Selecting drive programme using M Drive and react actively if necessary. Adjust button in centre console the driving style and react if necessary.◀ Display in the instrument cluster Selected drive programme cor‐ responds to the number of illu‐ minated fields.
Page 100 Controls Driving Using the Cruise Control, change the en‐ ▷ "Efficient": efficient, comfortable. Mini‐ gine speed when driving off by 500 rpm. mised consumption Release brake, vehicle accelerates. Con‐ Ideal, for example, in city traffic or on snow. tinue to press accelerator pedal. Selecting a channel Upshifting happens automatically as long as the accelerator pedal is fully pressed.
Page 101: Displays
Displays Controls Displays Vehicle equipment of the selected optional equipment or the country specification, may also be described This chapter describes all standard, national here. This also applies to safety-relevant func‐ and special equipment available for the model tions and systems. Comply with the relevant series.
Page 102 Controls Displays If applicable, the text message shown in the other qualified Service Partner or a specialist Control Display is accompanied by an addi‐ workshop. tional acoustic signal. Parking brake Indicator and warning lamps The parking brake is engaged. General Releasing the parking brake, see page 90.
Page 103 Displays Controls Dynamic Stability Control DSC Reduce your speed and carefully stop the ve‐ hicle. Avoid violent or sudden braking and If the indicator lamp is flashing: DSC is steering manoeuvres. regulating the acceleration and braking Runflat indicator, see page 133. forces.
Page 104 Controls Displays Emissions High-beam assistance, see page 123. Engine function malfunctioning. Cruise Control Have the vehicle checked by a Service Partner of the manufacturer or another The system is switched on. The speed qualified Service Partner or a specialist work‐ set using the controls on the steering shop.
Page 105 Service Partner or cally hidden after approximately 20 seconds. a specialist workshop. These Check Control messages remain saved ▷ "BMW Roadside Assistance" and can be displayed again. Contact breakdown assistance. Displaying Check Control messages Messages displayed at the end of...
Page 106 Controls Displays Engine oil temperature Outside temperature ▷ Cold engine: the pointer is WARNING located at a low temperature Even at temperatures above value. Drive with moderate +3 ℃/+37 ℉, there may be an increased risk of engine speed and vehicle black ice, for example on bridges or on shaded speed.
Page 107 Displays Controls Digital speedometer Range Display Display The current speed is shown in If the remaining range is low: the instrument cluster. ▷ A Check Control message is briefly displayed. ▷ The on-board computer shows the remaining range. ▷ If a dynamic driving style is adopted, for ex‐ Activating display ample fast cornering, engine function is not "My Vehicle"...
Page 108 Controls Displays Showing fuel consumption history The current fuel consumption display is active. The average fuel consumption can be shown Display of the driving dynamic sys‐ in the set time span. tems, see page 108. "My Vehicle" The bar gauge for the current fuel consump‐ "Technology in action"...
Page 109 Displays Controls Display Symbols Description M engine dynamics control, see Detailed information on service page 100. requirements More detailed information on the scope of Adaptive M suspension, see maintenance can be displayed on the Control page 153. Display. Via iDrive: Servotronic, see page 154.
Page 110 Controls Displays Symbols Select the desired setting. Confirm. Symbols Description The entered date is saved. Green: maintenance has been Automatic Service notification carried out on time. Data on the service status or on statutory in‐ Yellow: maintenance has been spections for the vehicle is transmitted to the carried out with a delay.
Page 111 Displays Controls Speed Limit Info with Safety note overtaking restriction display WARNING The system does not release you from Speed Limit Info your personal responsibility to assess the visi‐ bility conditions and traffic situation correctly. Principle There is a danger of accidents. Adapt your Speed Limit Info shows the currently detected driving style to the traffic conditions.
Page 112 Controls Displays Display ▷ When the windscreen in front of the rear- view mirror is covered with condensation, The following appears in the instrument clus‐ dirt, stickers, etc. ter: ▷ Possible incorrect detection by the cam‐ Speed Limit Info era. ▷...
Page 113 Displays Controls Activating the list and entering a Calling up information on the setting information display Turn the knurled wheel on the right-hand side Press the button on the turn indicator lever. of the steering wheel to activate the corre‐ Information is displayed on the information dis‐...
Page 114 Controls Displays Resetting average values Via iDrive: "My Vehicle" "iDrive settings" "Displays" "Instrument cluster" Select required information. Display in the information display The information from the on- Press and hold the button on the turn indicator board computer is displayed in lever.
Page 115 Displays Controls Sport displays General Two kinds of on-board computer are available General on the Control Display: On the Control Display the current values for ▷ "On-board computer": average values performance and torque are shown if the vehi‐ such as the consumption are displayed. cle is appropriately equipped.
Page 116 Controls Displays Activating/deactivating the speed Switching on/off warning "My Vehicle" Via iDrive: "iDrive settings" "My Vehicle" "Displays" "Vehicle settings" "Head-up display" "Speed warning" "Head-up display" "Speed warning" Display Press the Controller. Standard view Setting the current speed as the The following information is displayed in the speed warning Head-Up Display: Via iDrive:...
Page 117 Displays Controls Selecting displays in the Head-Up Turn the Controller until the desired height Display is obtained. Via iDrive: Press the Controller. The setting is saved for the currently used pro‐ "My Vehicle" file. "iDrive settings" The height of the Head-Up Display can also be "Displays"...
Page 118 Controls Displays Special windscreen Shift Lights on the Head-Up Display The windscreen constitutes part of the sys‐ Switching on tem. Shift Lights are only displayed on the Head-Up The shape of the windscreen enables a sharp Display in M view, see page 116. image to be projected.
Page 119 Displays Controls Calling up the vehicle status Via iDrive: "My Vehicle" "Vehicle status" Overview of the information ▷ "Flat Tyre Monitor": status of the run‐ flat indicator, see page 133. ▷ "Tyre Pressure Monitor": status of the Tyre Pressure Monitor, see page 130. ▷...
Page 120: Lights
Controls Lights Lights Vehicle equipment Symbol Function This chapter describes all standard, national Low-beam headlights. and special equipment available for the model series. Therefore equipment which is not in‐ stalled in your vehicle, for example on account Instrument lighting. of the selected optional equipment or the country specification, may also be described here.
Page 121 Lights Controls Switching on Headlight courtesy delay feature General If the high-beam headlights are activated with radio ready state switched off, the low-beam headlights remain on for a certain amount of time. Setting the duration Via iDrive: With radio ready state switched off, push the "My Vehicle"...
Page 122 Controls Lights General The indicator lamp in the instrument cluster is illuminated if the low-beam headlights are The beams from the headlights follow the road switched on. ahead on in response to the steering angle and other parameters. System limits So as not to dazzle oncoming vehicles, the The automatic driving lights control is no sub‐...
Page 123 Lights Controls High-beam assistance The indicator lamp in the instrument cluster is illuminated if the low-beam headlights switched on. Principle The high-beam assistance detects other road The system will switch automatically between users early on and activates or deactivates the low-beam and high-beam headlights.
Page 124 Controls Lights Fog lights Instrument lighting Rear fog light Operating requirements The brightness can only be adjusted when the Operating requirements side lights or the low-beam headlights are Before the rear fog light is switched on, the switched on. low-beam headlights must be switched on. Adjusting Switching on/off The brightness can be set using...
Page 125 Lights Controls Switching the reading lights on/off Press the button. Depending on the equipment version, there are reading lights located at the front and in the rear beside the interior light. Ambient lighting General Depending on the equipment, the lighting for some of the interior lights can be set.
Page 126: Safety
Controls Safety Safety Vehicle equipment of the selected optional equipment or the country specification, may also be described This chapter describes all standard, national here. This also applies to safety-relevant func‐ and special equipment available for the model tions and systems. Comply with the relevant series.
Page 127 Safety Controls Notes on achieving optimum airbag ▷ Do not modify individual components of effectiveness the system or its wiring in any way. This also applies to the covers of the steering WARNING wheel, the dashboard and seats. If the seat position is wrong or the de‐ ▷...
Page 128 Controls Safety Airbag system malfunction passenger airbags so that they are triggered as intended in the event of an accident. ▷ Warning light does not illuminate after the ignition is switched on. The airbag condition is displayed on the front passenger airbag indicator lamp, see ▷...
Page 129 Safety Controls ▷ When front passenger air‐ paired or removed and disposed of by a Serv‐ bags are deactivated, the in‐ ice Partner of the manufacturer or another dicator lamp remains illumi‐ qualified Service Partner or a specialist work‐ nated. shop.◀...
Page 130 Controls Safety The system has been triggered or is faulty. Via iDrive: Immediately have the system checked by a "My Vehicle" Service Partner of the manufacturer or another "Vehicle status" qualified Service Partner or a specialist work‐ "Tyre Pressure Monitor" shop.
Page 131 Safety Controls Reset the tyre inflation pressure: "Perform Symbol Possible cause reset". The System has detected a wheel Drive off. change, but no reset has been run. The wheels are shown grey and the following No reset has been performed on to appears on the display: "Resetting Tyre the system.
Page 132 Controls Safety If there is a significant loss of tyre System limits inflation pressure Temperature Message The tyre inflation pressure depends on the temperature of the tyre. A yellow warning lamp is illuminated in the instrument cluster. The tyre inflation pressure increases as the tyre temperature increases, for example during In addition, a symbol with the affected tyre is driving or due to exposure to sunlight.
Page 133 Safety Controls Runflat indicator RPA Performing initialisation On initialisation, the current tyre pressures are Principle saved as a reference for detection of a flat tyre. The initialisation is started by confirming the The system identifies a loss of tyre inflation correct tyre inflation pressures.
Page 134 Controls Safety Measure ▷ Front-end collision with light braking func‐ tion, see page 135. Reduce your speed and carefully stop the vehicle. Avoid violent or sudden braking ▷ Person warning, see page 138. and steering manoeuvres. Safety notes Determine which wheel is damaged. To do this, check the air pressure in all four tyres, WARNING for example using the tyre inflation pres‐...
Page 135 Safety Controls Intelligent Safety button The system is controlled by a camera in the area of the rear-view mirror. The front-end collision warning is also avail‐ Camera able if the Cruise Control is disabled. When deliberately approaching a vehicle, the front-end collision warning and braking inter‐...
Page 136 Controls Safety Camera WARNING Displays and warnings do not relieve you of personal responsibility. System limitations can mean that warnings or system responses are not issued or are issued too late, incor‐ rectly, or without justification. There is a dan‐ ger of accidents.
Page 137 Safety Controls Warning with braking function The vehicle can be braked at low speed until it comes to a stop. Display Manual gearbox: when the vehicle is braked to If there is a risk of collision with a detected ve‐ a stop, the engine may shut off.
Page 138 Controls Safety ▷ On sharp bends. Persons are taken into account if they are loca‐ ted within the detection range of the system. ▷ When Driving Stability Control Systems are limited or deactivated, for example DSC Detection range OFF. ▷ If the field of view of the camera in the mir‐...
Page 139 Safety Controls Switching on/off tion and intervene actively if the situation war‐ rants it.◀ Switching on automatically WARNING The system is automatically activated at the Due to system limitations, there may be start of each journey. malfunctions of individual functions when tow starting/towing with activated Intelligent Safety Switching off Systems.
Page 140 Controls Safety The detection of objects can be restricted. ▷ During the camera calibration process im‐ Take into account the detection range limits mediately after vehicle delivery. and the functional restrictions. ▷ When there is sustained glare effect due to oncoming light, for example the sun is low System limits in the sky.
Page 141 Safety Controls Switching on/off WARNING Displays and warnings do not relieve you Press the button. of personal responsibility. System limitations can mean that warnings or system responses ▷ On: LED is illuminated. are not issued or are issued too late, incor‐ ▷...
Page 142 Controls Safety Functional restrictions General The function may be restricted in the following situations, for example: ▷ In thick fog, wet conditions or snow. ▷ With missing, worn, poorly visible, merg‐ ing/separating or ambiguous boundary lines, for example in areas where there are road works.
Page 143 Safety Controls Display ger of accidents. Adapt your driving style to the traffic conditions. Observe the traffic situa‐ Light in the exterior mirror housing tion and intervene actively if the situation war‐ rants it.◀ Overview Button in the vehicle Advance warning The dimmed light in the exterior mirror housing indicates when vehicles are in the blind spot or are approaching from the rear.
Page 144 Controls Safety Functional restrictions Overview The function may be restricted in the following Buttons on the steering wheel situations: ▷ If the speed of the approaching vehicle is Button Function very much higher than that of your own speed. Switches system on/off, see page ▷...
Page 145 Safety Controls Change speed limit Acoustic warning ▷ If you unintentionally exceed the set speed limit, you will hear an acoustic warning af‐ ter approximately 5 seconds. ▷ If the speed limit is reduced to below the driven speed during the journey, the warn‐ ing sounds after approximately 30 sec‐...
Page 146 Controls Safety General tigue might not be detected, or may not be de‐ tected in good time. There is a danger of acci‐ dents. Make sure that the driver is rested and alert. Adapt your driving style to the traffic con‐ ditions.◀...
Page 147 Safety Controls ▷ In active driving situations, for example fre‐ When driving in critical situations, the following quent lane changes. individual functions become active as required: ▷ In poor road conditions. ▷ The front seat belts are automatically pre- tensioned. ▷...
Page 148 Controls Safety At a standstill After the vehicle has come to a halt, the brake is released automatically. Online Edition for Part no. 01402981699 - VI/17...
Page 149: Driving Stability Control Systems
Driving Stability Control Systems Controls Driving Stability Control Systems Vehicle equipment M Drive This chapter describes all standard, national Principle and special equipment available for the model Individual settings can be made in two preset series. Therefore equipment which is not in‐ configurations for the vehicle.
Page 150 Controls Driving Stability Control Systems Configuring M Drive M Drive setting using buttons The preset configurations can be individually With activated M Drive individual settings out‐ set. side of the M Drive can also be changed, for example, using buttons in the centre console. On the Control Display: That deactivates the M Drive.
Page 151 Driving Stability Control Systems Controls Safety notes Deactivating DSC: DSC OFF WARNING General The system does not release you from Driving stability during acceleration and cor‐ your personal responsibility to assess the traf‐ nering is restricted if DSC is deactivated. fic situation correctly.
Page 152 Controls Driving Stability Control Systems Safety note Deactivating MDM Press the corresponding button 1 or button 2 WARNING on the steering wheel again. With activated M Dynamic Mode stabilis‐ M Dynamic Mode and the settings selected ing engagements are only carried out to a re‐ under M Drive are deactivated.
Page 153 Driving Stability Control Systems Controls Adaptive M suspension Using the button Principle The system reduces unwanted vehicle move‐ ments when a dynamic driving style is used or when driving on uneven roads. Depending on the road condition and the driv‐ ing style, this enhances driving dynamics and driving comfort.
Page 154 Controls Driving Stability Control Systems Servotronic Using the button Principle Servotronic is a speed-dependent power steering system. The system provides more steering force as‐ sistance at lower speeds than at higher speeds. This makes it easier to park, for exam‐ ple, and provides a more direct steering feel when driving at higher speeds.
Page 155: Driving Comfort
Driving comfort Controls Driving comfort Vehicle equipment WARNING Using the system in the following situa‐ This chapter describes all standard, national tions may increase the risk of an accident, and special equipment available for the model for example: series. Therefore equipment which is not in‐ ▷...
Page 156 Controls Driving comfort Switching the Cruise Control on/off Setting the speed and interrupting Holding or setting the speed Switching on Press the button on the steering wheel. The speedometer marker is set to the current speed. Cruise Control can be used. Dynamic Stability Control DSC is switched on, if necessary.
Page 157 Driving comfort Controls ▷ Each time the rocker switch is pressed be‐ shows whether the system is switched on. yond the resistance point, the desired speed is increased or decreased to the Desired speed and saved speed next multiple of 10 km/h on the speedome‐ ▷...
Page 158 Controls Driving comfort General Overview The ultrasonic sensors for measuring the dis‐ With front PDC: button in vehicle tances are located in the bumpers. The range is approximately 2 m, 6 ft depending on the obstacle and environment. An acoustic warning is only issued in the following situations: ▷...
Page 159 Driving comfort Controls With front PDC: switching on/off Visual warning manually Press the Park Assistant button. ▷ On: LED is illuminated. ▷ Off: LED is extinguished. Warning Acoustic signals The approach of the vehicle to an object is An intermittent sound indicates that the vehi‐ shown on the Control Display.
Page 160 Controls Driving comfort ▷ If persons are wearing certain types of ▷ Due to dense exhaust gases. clothing, for example a coat. ▷ Due to other ultrasonic sources, for exam‐ ▷ If there is external disruption to the ultra‐ ple sweeping machines, steam-jet cleaners sound, for example by passing vehicles or or neon lights.
Page 161 Driving comfort Controls cidents. Adapt your driving style to the traffic The image from the rear-view camera is dis‐ conditions. Additionally, look directly to check played if the system was switched on using the the traffic situation and the area around the ve‐ iDrive.
Page 162 Controls Driving comfort "Parking guidance lines" The turning circle lines show the course of the smallest possible turning circle on a level road Driving path lines and turning circle lines surface. are shown. Once the steering wheel has been turned be‐ ▷...
Page 163 Driving comfort Controls Turn the steering wheel so that the driving The objects shown on the Control Display may lane line covers the corresponding turning be closer than they appear. Do not estimate circle line. the distance to objects based on the display. Side View Principle Side View provides you with an advance view...
Page 164 Controls Driving comfort Cameras Artificial lines on the lower screen edge show the position of the vehicle front. Two cameras integrated into the bumpers pro‐ vide detection. Brightness Both camera lenses are located at the side of With Side View switched on: the bumper.
Page 165 Driving comfort Controls General Cameras The two cameras in the exterior mirrors and the rear-view camera are used to view the area around the vehicle. The range at the sides and rear is at least 2 m, approximately 7 ft. In this way, obstacles up to the height of the exterior mirror are detected early.
Page 166 Controls Driving comfort Switching on/off manually Contrast With Top View switched on: Press the Park Assistant button. If necessary, tilt the Controller to the left. ▷ On: LED is illuminated. Select the symbol. ▷ Off: LED is extinguished. Turn the Controller until the desired set‐ Top View is shown.
Page 167 Driving comfort Controls Park Assistant NOTE The Park Assistant may steer across Principle kerb or up onto kerbs. There is a danger of damage to property. Observe the traffic situa‐ tion and intervene actively if the situation war‐ rants it.◀ In addition, the safety notes for the Park Dis‐...
Page 168 Controls Driving comfort Display on the Control Display ▷ Do not cover the sensors, for example with stickers. System is activated/deactivated ▷ Keep the sensors clean and unobstructed. Symbol Meaning For measuring parking spaces ▷ The vehicle must be driving forwards in a Grey: system not available.
Page 169 Driving comfort Controls Parking with the Park Assistant ▷ At speeds over approximately 10 km/h, ap‐ proximately 6 mph. Driving into a parking space ▷ On snow-covered or slippery road surfa‐ ces, if necessary. Press the Park Assistant button or ▷...
Page 170 Controls Driving comfort System limits ▷ In certain weather conditions, for example high humidity, wet conditions, snowfall, ex‐ Safety note treme heat or strong wind. ▷ For the trailer drawbars and tow hitches of WARNING other vehicles. The system may respond not at all, too ▷...
Page 171: Air Conditioning
Air conditioning Controls Air conditioning Vehicle equipment Interior air quality This chapter describes all standard, national An emissions-tested interior and the installa‐ and special equipment available for the model tion of microfilters and a climate-control sys‐ series. Therefore equipment which is not in‐ tem with functions for controlling the tempera‐...
Page 172 Controls Air conditioning Air conditioning functions in detail Switching on/off Press the button. Switches system on/off The cooling function is switched on or off. Switching on Press any button, with the following excep‐ Depending on weather conditions, the wind‐ tions: screen and side windows may mist over for a short time when the engine is started.
Page 173 Air conditioning Controls ▷ LED off: ambient air is constantly entering ▷ Windows. the car. ▷ Upper body area. ▷ LED on, recirculated-air mode: the ambient ▷ Windows, upper body area and footwell. air supply is permanently shut off. ▷ Footwell.
Page 174 Controls Air conditioning Automatic air conditioning with extended functionality Seat heating, left 69 AUC/recirculated-air mode Temperature, left 10 Air distribution, right AUTO program 11 Air flow, AUTO intensity Display 12 Air distribution, left Maximum cooling effect 13 Rear window heating Temperature, right 14 Interior temperature sensor —...
Page 175 Air conditioning Controls Adjusting General The function is available above an outside tem‐ Turn the wheel to select the de‐ perature of approximately 0 ℃/32 ℉ And with sired temperature. the engine running. Switching on/off The automatic air conditioning regulates to Press the button.
Page 176 Controls Air conditioning Adjusting the air flow manually Press left or right side of button: re‐ duce or increase intensity. Principle The selected intensity is shown on the display The air flow for air conditioning can be set for automatic air conditioning. manually.
Page 177 Air conditioning Controls Ventilation Defrosting windows and removing condensation Ventilation at front Principle Ice and condensation are quickly removed from the windscreen and the front side win‐ dows. Switching on/off Press the button. The LED is illuminated when the sys‐ tem is switched on.
Page 178 Controls Air conditioning Ventilation in rear passenger ▷ Direct operation or preselected switch-on compartment time: does not depend on the outside tem‐ perature. ▷ Battery is sufficiently charged. The vehicle battery is discharged when the independent ventilation is switched on. As a result, the maximum activation time is re‐...
Page 179 Air conditioning Controls Activate required switch-on time. Symbol on the automatic air conditioning system is illuminated when the switch-on time is active. Symbol on the automatic air conditioning system flashes when the system has cut in. The system switches on within the next 24 hours only.
Page 180: Interior Equipment
Controls Interior equipment Interior equipment Vehicle equipment Emptying Lift out the insert. This chapter describes all standard, national and special equipment available for the model Lighter series. Therefore equipment which is not in‐ WARNING stalled in your vehicle, for example on account of the selected optional equipment or the Contacting the hot heating element or country specification, may also be described...
Page 181 Interior equipment Controls Power sockets Front centre console General Cigarette lighter socket can be used as a socket for electrical devices when the engine is running or the ignition is switched on. The total load of all sockets must not exceed 140 watt at 12 volt.
Page 182 Controls Interior equipment General Safety notes Comply with the notes on connecting mobile WARNING devices to the USB interface in the chapter on Risk of trapping when folding down the USB connections, see page 37. rear backrest. There is a danger of injury or damage to property.
Page 183 Interior equipment Controls Folding rear backrest down from the boot Pull the corresponding lever in the boot to unlock the rear backrest. The unlocked rear backrest moves slightly to the front. Fold the rear backrest forward. Folding back the rear backrest Fold the rear backrest back into seat position and engage.
Page 184: Storage Compartments
Controls Storage compartments Storage compartments Vehicle equipment ▷ Without smoker's package: front storage compartment, in front of cupholders, see This chapter describes all standard, national page 185. and special equipment available for the model ▷ Storage compartment in the front centre series.
Page 185 Storage compartments Controls Front storage compartment Closing Fold the cover up. Locking The glove box can be locked with an integrated key. This means it is not possible to access the glove box. After the glove box has been locked, the re‐ mote control without the integrated key can be handed over, for example, at a hotel.
Page 186 Controls Storage compartments Sliding Fittings for front cupholders The centre armrest can be slid in the longitudi‐ With the fitting, the cupholders can be used as nal direction and engages in the end positions. an extra storage compartment. To do this, put the fittings into the cupholder.
Page 187 Storage compartments Controls Storage compartments in the Storage compartment under the boot floor boot For the storage compartment under the boot floor, do not exceed a maximum permitted load Storage compartment of 20 kg, approximately 44 lb. There is a storage compartment on the left. There is a storage compartment on the right.
Page 188 Online Edition for Part no. 01402981699 - VI/17...
Page 189: Driving Hints
Driving hints The chapter provides you with information that you may require in particular driving situations or operating modes. Online Edition for Part no. 01402981699 - VI/17...
Page 190: Bmw M4 Technology
Driving hints BMW M4 Technology BMW M4 Technology Vehicle equipment M compound brakes This chapter describes all standard, national The high performance brake system has venti‐ and special equipment available for the model lated compound brake discs. series. Therefore equipment which is not in‐...
Page 191 BMW M4 Technology Driving hints Also follow the information on this under vehi‐ cle washing, see page 244, and safe braking, see page 194. Drivetrain In this vehicle, particular attention is paid to the direct connection from the engine to the drive‐...
Page 192: Driving Precautions
Driving hints Driving precautions Driving precautions Vehicle equipment At 2000 km, 1200 miles Have maintenance conduct a drive-in service. This chapter describes all standard, national and special equipment available for the model From 2000 km, approximately series. Therefore equipment which is not in‐ 1200 miles to 5000 km, approximately stalled in your vehicle, for example on account 3100 miles...
Page 193 Driving precautions Driving hints General driving information Radio signals WARNING Closing the boot lid Certain vehicle functions may be affec‐ ted by interference from high-frequency radio Safety note signals. Such signals originate from various WARNING transmission systems, for example, from air traffic beacons or relay stations for mobile tele‐...
Page 194 Driving hints Driving precautions Wet roads ▷ Drive through water at no faster than 5 km/h, approximately 3 mph. In damp weather, if road grit has been spread or there is heavy rain, apply the brakes lightly Safety note every few kilometres/miles. NOTE In doing so, do not obstruct other road users.
Page 195 Driving precautions Driving hints Corrosion of the brake disc a specialist workshop. Do not drive at high speed until the damage has been repaired.◀ Corrosion of the brake discs and contamina‐ tion of the brake pads increase in the following circumstances: ▷...
Page 196: Loads
Driving hints Loads Loads Vehicle equipment objects or devices connected by cable to the vehicle are secured in place in the interior.◀ This chapter describes all standard, national WARNING and special equipment available for the model series. Therefore equipment which is not in‐ Incorrectly stowed objects can slip or be stalled in your vehicle, for example on account thrown into the interior, for example in an acci‐...
Page 197 Loads Driving hints Lashing eyes in the boot Safety note WARNING When driving with a roof load, for exam‐ ple with a roof rack, the higher centre of gravity can mean that driving safety is no longer guar‐ anteed in critical driving situations. There is a danger of accident or damage to property.
Page 198 Driving hints Loads ▷ Place heavy items of luggage at the bot‐ tom. ▷ Securely fasten the luggage, for example with tensioning straps. ▷ Do not allow objects to protrude into the swing range of the boot lid. ▷ Drive cautiously and avoid sudden acceler‐ ation, braking or cornering.
Page 199: Saving Fuel
Saving fuel Driving hints Saving fuel Vehicle equipment Closing windows and the Glass Roof This chapter describes all standard, national and special equipment available for the model An opened Glass Roof or opened window in‐ series. Therefore equipment which is not in‐ creases the drag and thus reduces the range.
Page 200 The fuel supply is interrupted in overrun mode. by a BMW Service Partner. Please also see the BMW Maintenance Sys‐ Switch off the engine if tem, see page 229. stopping for a relatively long...
Page 201 Saving fuel Driving hints Online Edition for Part no. 01402981699 - VI/17...
Page 202 Online Edition for Part no. 01402981699 - VI/17...
Page 203: Mobility
Mobility To assist you in preserving your vehicle's mobility, this section contains important information on operating fluids, wheels and tyres, maintenance and breakdown assistance. Online Edition for Part no. 01402981699 - VI/17...
Page 204: Refuelling
Mobility Refuelling Refuelling Vehicle equipment Fuel tank cap This chapter describes all standard, national Opening and special equipment available for the model Briefly press the rear edge of the fuel filler series. Therefore equipment which is not in‐ flap. stalled in your vehicle, for example on account of the selected optional equipment or the country specification, may also be described here.
Page 205 Refuelling Mobility Closing the environment. There is a danger of damage to property. Avoid overfilling.◀ WARNING The retaining strap of the fuel tank cap may become trapped and crushed when turn‐ ing the cap to close it. It will then not be possi‐ ble to close the cap properly.
Page 206: Fuel
Mobility Fuel Fuel Vehicle equipment danger of damage to property. Do not use the following fuel or additives with petrol engines: This chapter describes all standard, national ▷ Leaded petrol. and special equipment available for the model ▷ Metallic additives, for example manganese series.
Page 207: Wheels And Tyres
Wheels and tyres Mobility Wheels and tyres Vehicle equipment ▷ A driving distance of max. 2 km, 1.25 miles has not been exceeded. This chapter describes all standard, national ▷ If the vehicle has not moved again for at and special equipment available for the model least 2 hours after a journey.
Page 208 Mobility Wheels and tyres Winter tyres If the tyre's speed code cannot be found, then the tyre inflation pressure for the correspond‐ The tyre tread depth should not be less than ing tyre size applies. 4 mm, 0.16 in, otherwise the vehicle's suitabil‐ More information regarding wheels and tyres ity for winter use is restricted.
Page 209 Wheels and tyres Mobility ▷ Incorrect tyre storage. Designation Date of manufacture DOT … 2117 21st week of 2017 Safety notes WARNING If the tyres are damaged, the tyre infla‐ Replacement of wheels and tion pressure may be reduced which in turn tyres could cause you to lose control of the vehicle.
Page 210 Mobility Wheels and tyres Recommended makes of tyre maximum permitted speed in the driver's field of view. The indicating label is available from a Service Partner of the manufacturer or another qualified Service Partner or a specialist work‐ shop. If winter tyres are fitted, observe and do not ex‐ ceed the respectively permitted maximum speed.
Page 211 Wheels and tyres Mobility ▷ Have all vehicle occupants get out of the Therefore, after they have been used on a rac‐ vehicle and guide them out of the danger ing track, check the sport tyres against the le‐ area, for example behind the crash barrier. gal regulations for use on public roads, for ex‐...
Page 212 Mobility Wheels and tyres Mobility System Sealant container Principle With the Mobility System, minor tyre damage can be quickly sealed, to allow you to drive on. For this purpose, liquid sealant is pumped into the tyres which encloses the damage from the inside when it hardens.
Page 213 Wheels and tyres Mobility ▷ Have all vehicle occupants get out of the Remove the connecting hose entirely from vehicle and guide them out of the danger the compressor housing. Do not kink the area, for example behind the crash barrier. hose.
Page 214 Mobility Wheels and tyres container onto the tyre valve of the faulty If it does not reach a tyre inflation pressure of wheel. 2 bar: Switch off compressor. Unplug the connector from the socket in the vehicle interior. Unscrew the filler hose from the tyre valve. Drive forwards and backwards by 10 m, ap‐...
Page 215 Wheels and tyres Mobility Correcting the tyre inflation pressure Observe the snow chain manufacturer's in‐ structions. Stop in a suitable area. Do not initialise the runflat indicator RPA with Screw the connecting hose of the com‐ snow chains fitted, as it may give incorrect pressor directly onto the tyre valve.
Page 216 There is a danger of injury. Do not jacked. lift another vehicle or other items with the The jack of your BMW is maintenance-free. jack.◀ Please observe the information marked on the WARNING jack.◀...
Page 217 Wheels and tyres Mobility On a slight downhill slope After unscrewing the wheel stud, remove the adapter again. Screwing on Place the adapter on the wheel stud. If necessary, turn the adapter until it fits on the wheel stud. Screw on the wheel stud. The tightening torque is 140 Nm.
Page 218 Mobility Wheels and tyres Jack mounting points when using the jack, and do not change this position.◀ Use one hand to secure the jack, arrow 1, and your other hand to grip the jack crank, arrow 2. The jacking points are located in the marked positions.
Page 219 Wheels and tyres Mobility Make sure that the base of the jack has Turn the jack crank anticlockwise to retract been extended vertically. the jack and lower the vehicle. Remove the jack and stow it securely. After changing the wheel Tighten the wheel studs crosswise.
Page 220: Engine Compartment
Mobility Engine compartment Engine compartment Vehicle equipment of the selected optional equipment or the country specification, may also be described This chapter describes all standard, national here. This also applies to safety-relevant func‐ and special equipment available for the model tions and systems.
Page 221 Engine compartment Mobility Bonnet age to property. Before opening the bonnet, make sure that the wipers with wiper blades fitted are in contact with the windscreen.◀ Safety notes WARNING NOTE Incorrectly performed work in the engine When closing, the bonnet must lock into compartment can damage components and place on both sides.
Page 222 Mobility Engine compartment The bonnet must engage into place on both sides. Online Edition for Part no. 01402981699 - VI/17...
Page 223: Engine Oil
Engine oil Mobility Engine oil Vehicle equipment NOTE Too much engine oil can damage the en‐ This chapter describes all standard, national gine or the catalytic converter. There is a dan‐ and special equipment available for the model ger of damage to property. Do not top up with series.
Page 224 Mobility Engine oil Displaying the engine oil level Carrying out a detailed measurement Via iDrive: Via iDrive: "My Vehicle" "My Vehicle" "Vehicle status" "Vehicle status" "Engine oil level" "Engine oil level" The engine oil level is displayed. "Measure engine oil level" "Start measurement"...
Page 225 Open the bonnet, see page 221. can be used for topping up: Turn the cap anticlockwise. Oil specification BMW Longlife-01. BMW Longlife-01 FE. BMW Longlife-04. BMW Longlife-12 FE. Information on suitable oil specifications and viscosities of engine oils can be obtained from Add engine oil.
Page 226 Mobility Engine oil SAE 5W-30, SAE 0W-40 or SAE 5W-40 may also be used. Information on suitable oil specifications and viscosities of engine oils can be obtained from a Service Partner of the manufacturer or an‐ other qualified Service Partner or a specialist workshop.
Page 227: Coolant
Coolant Mobility Coolant Vehicle equipment clothing, skin or eyes, and do not swallow them. Only use suitable additives.◀ This chapter describes all standard, national and special equipment available for the model series. Therefore equipment which is not in‐ Coolant level stalled in your vehicle, for example on account of the selected optional equipment or the Checking...
Page 228 Mobility Coolant allow the pressure to escape before open‐ ing it fully. If necessary, slowly top up to the correct level; do not overfill. Tighten cap. Have the cause of coolant loss rectified as soon as possible. Disposal When disposing of coolant and coolant additives, comply with the relevant en‐...
Page 229: Maintenance
Therefore hand the service advisor the remote control with which the vehicle was driven most BMW Maintenance System recently. The Maintenance System indicates what Periods out of use maintenance measures are required, thus pro‐...
Page 230 If an entry is made in the electronic service his‐ tory of the vehicle, service-relevant data is diagnosis, OBD saved both in the vehicle and on the central IT systems of BMW AG, Munich. Safety note The data entered in the electronic service his‐ NOTE...
Page 231 Maintenance Mobility Recycling The manufacturer of your vehicle recommends handing the vehicle in at a take-back point nominated by the manufacturer at the end of its life cycle. The regulations concerning the returning of end-of-life vehicles may vary from country to country. Additional information is available from a Service Partner of the manu‐...
Page 232: Replacing Parts
Mobility Replacing parts Replacing parts Vehicle equipment Replacing the wiper blades To replace the wiper blades, place the wip‐ This chapter describes all standard, national ers in the fold-out position, see page 93. and special equipment available for the model Fold out wiper arm and hold firm.
Page 233 Replacing parts Mobility Headlight glass qualified Service Partner or a specialist work‐ shop. During cool or humid weather, the exterior Comply with the safety notes, see page 233. lights can mist over on the inside. When driving with the lights switched on, the condensation Light-emitting diodes, LEDs disappears after a short time.
Page 234 Mobility Replacing parts Safety notes More information regarding the battery can be obtained from a Service Partner of the manu‐ NOTE facturer or another qualified Service Partner or Incompatible external battery chargers a specialist workshop. can damage the vehicle. There is a danger of damage to property.
Page 235 Replacing parts Mobility Disposing of the old battery Removing the cover Undo the three screws of the cover, ar‐ Dispose of old batteries at a Service row 1, with the on-board tool. Partner of the manufacturer or another qualified Service Partner or a specialist workshop or hand them into an authorised col‐...
Page 236 Mobility Replacing parts Inside the boot Fold up boot floor. Details of the fuse assignment are on a sepa‐ rate leaflet. Online Edition for Part no. 01402981699 - VI/17...
Page 237: Breakdown Assist
Briefly press the cover flap to open it. Press the SOS button in an emergency only. Press the SOS button until the LED on the Even if no emergency call through BMW is button is illuminated green. possible, in some cases an emergency call may still be established to a public emergency ▷...
Page 238 ▷ Activated ConnectedDrive contract, equip‐ ment with intelligent emergency call or When an emergency call is sent via BMW, BMW ConnectedDrive services. data is sent to the emergency call centre in order to decide what rescue measures are ▷...
Page 239 Breakdown Assist Mobility Starting assistance Certain functions within the vehicle may be re‐ stored to a drivable condition. General If this is not possible, further measures will be initiated, for example Mobile Service will be in‐ If the vehicle battery is discharged, the engine formed.
Page 240 Tow-starting and towing away Open the cover of the BMW jump-starting connection. Safety note Connect a terminal clamp on the positive/+ jump lead to the positive terminal of the...
Page 241 Breakdown Assist Mobility Manual gearbox NOTE The vehicle can become damaged when Towing or pushing the vehicle raising and securing it. A broken-down vehicle can be towed or There is a danger of damage to property. pushed. ▷ Raise the vehicle with suitable equipment. Roll or push, see page 95, the vehicle.
Page 242 Mobility Breakdown Assist NOTE ▷ Tow bar clearance may be restricted when cornering. The vehicle can become damaged when raising and securing it. ▷ The tow bar will generate lateral forces if it is attached offset. There is a danger of damage to property. ▷...
Page 243 Breakdown Assist Mobility Safety note page 239. Only tow-start when the engine is cold if your vehicle has a catalytic converter. NOTE Switching on the hazard warning lights, If the towing eye is not used as intended, please observe country-specific regula‐ the vehicle or towing eye may be damaged.
Page 244: General Care
Mobility General care General care Vehicle equipment ▷ Minimum distance to the Glass Roof: 80 cm, approximately 31.5 in. This chapter describes all standard, national and special equipment available for the model Automatic car washes series. Therefore equipment which is not in‐ stalled in your vehicle, for example on account Safety notes of the selected optional equipment or the...
Page 245 Drivelogic Care products Safety note General NOTE BMW recommends using care and cleaning Selector lever position P is automatically products from BMW. Suitable care products engaged when the ignition is switched off. are available from a Service Partner of the There is a danger of damage to property.
Page 246 Mobility General care able abrasion and causing the leather surface brake discs and brake pads, and protects them to become prematurely brittle. against corrosion. In order to protect against discolouration, for Chrome surfaces example from clothing, clean and care for the leather approximately every two months.
Page 247 General care Mobility Sensors/camera lenses Do not soak the roof lining. Clean sensors or camera lenses using a cloth Seat belts moistened with a small amount of a glass cleaner. WARNING Chemical cleaners can cause irreparable Displays/screens/protective sleeve of damage to the fabric of the seat belts. The pro‐ the Head-Up Displays tective effect of the seat belts will be lost.
Page 248 Online Edition for Part no. 01402981699 - VI/17...
Page 249: Reference
Reference The section contains the technical data and the alphabetical index that will enable you to find the information you need as quickly as possible. Online Edition for Part no. 01402981699 - VI/17...
Page 250: Technical Data
The heights specified do not take into account add-on parts such as a roof aerial, roof railing BMW M4 Coupé Width with mirrors 2014 Width without mirrors 1870...
Page 251 Technical data Reference BMW M4 CS Width with mirrors 2014 Width without mirrors 1870 Height 1392 Length 4672 Wheelbase 2812 Smallest turning circle dia. m (ft) 12.2 (40.1) Weights BMW M4 Coupé Kerb weight, ready for road, with 75 kg, 165 lb, load,...
Page 252 Reference Technical data BMW M4 CS Rear axle load limit kg (lb) 1130 (2491) Roof load kg (lb) 75 (165) Filling capacities Litres/imp. gal Note Fuel tank, approximately. Fuel grade, see page M4 Coupé 60.0/13.2 M4 CS 60.0/13.2 Online Edition for Part no. 01402981699 - VI/17...
Page 253: Appendix
Appendix Reference Appendix Here is where any updates to the Owner's Handbook for the vehicle are listed. Updates after going to press Updates have been made to these chapters of the printed Owner's Handbook following the copy deadline. ▷ Safety: front-end collision warning with City light braking function, see page 135.
Page 254: Everything From A To Z
Anti-trap mechanism, win‐ tion Adaptive Headlights dows Average speed Adaptive M suspension App, BMW Driver’s Guide Axle load limit Additives, oil Apps, see Owner's Handbook Axle loads, weight Adjusting headlights for Navigation, Entertain‐ After washing the vehi‐...
Page 255 BMW Maintenance Sys‐ Call up seat adjustment Check Control Camera-based assistance Checking oil level electroni‐ BMW M Technology systems, see Intelligent cally BMW Services, see Owner's Safety Child's seats Handbook for Navigation, Camera lenses, care Children, carrying Entertainment, Communica‐ Camera, rear-view cam‐...
Page 256 Defrosting, see Defrosting Driver profiles, import pro‐ Electronic Stability Pro‐ windows 173, file gramme, ESP, see DSC Defrosting windows 173, Driver’s Guide app, see BMW e-mail, see Owner's Defrost, see Defrosting win‐ Driver’s Guide app Handbook for Navigation, dows Driving area Entertainment, Communica‐...
Page 257 Ground clearance gramme, see DSC Foot brake Exhaust system Foot mats, care Expanding the boot Front airbags Extended BMW Online Serv‐ Front-end collision with light Handbrake, see Parking ices, see Owner's Handbook braking function brake for Navigation, Entertain‐ Front head restraints...
Page 258 Reference Everything from A to Z Hazard warning lights Identification number, see Ve‐ Integrated Owner's Head airbags hicle identification num‐ Handbook in vehicle Head Light Intelligent emergency Headlight cleaning system, iDrive call see Wiper system Ignition off Intelligent Safety Headlight courtesy delay fea‐ Ignition on Intended use ture...
Page 259 Everything from A to Z Reference Lane Change Warning Maintenance System Menus Lane Departure Warning Messages Language, on the Control Make-up mirror Messages, see Check Con‐ Display Malfunction displays, see trol Launch Control Check Control Microfilter 173, Laying up out of use Manual air distribu‐...
Page 260 Reference Everything from A to Z Notes, see Owner's Outside temperature warn‐ Pressure warning RPA, Handbook for Navigation, tyres Entertainment, Communica‐ Overheating of the engine, Preventing Auto Start tion see Coolant tempera‐ Stop ture Profiles, see Driver pro‐ files Protection function, Glass OBD, see On-board diagno‐...
Page 261 Everything from A to Z Reference Remote control for audio, see Retreaded tyres Seat, see Memory func‐ Owner's Handbook for Navi‐ Reuse tion gation, Entertainment, Com‐ Reversing light Securing a transported munication Revolution counter load Remote control, integrated Right-hand traffic, light set‐ Selection list in the instru‐...
Page 262 Handbook for Naviga‐ own safety Transported load, stowing tion, Entertainment, Com‐ Technical data and securing munication Technology, BMW M Tread, tyres Status Control Display, Telephone, see Owner's Trip computer tyres Handbook for Navigation, Trip distance recorder Online Edition for Part no. 01402981699 - VI/17...
Page 263 Everything from A to Z Reference Triple turn signal Vehicle care Wheel replacement Turn indicator rear, replacing Vehicle equipment Wheels, everything about the lamps Vehicle identification num‐ wheels and tyres Turn indicators, operation Wheels, runflat indicator Turning circle Vehicle paintwork Turning circle lines, rear-view Vehicle position, vehicle posi‐...
Page 265 BMW M The Ultimate Driving Machine *BL2981699004* Online Edition for Part no. 01402981699 - VI/17...

BMW M4 COUPE Owner's Handbook Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BMW M4 COUPE

Summary of Contents for BMW M4 COUPE

Table of Contents
