LumiSource 31105 Assembly Instructions

Dahlia Chair
Part # QK-DAHLIA XX
A
B
www.LumiSource.com
Assembly Instructions
Instrucciones De Asamblea
Instructions d'Assemblée
D
C

Instructions

1. Place Dahlia seat (A) upside
down.
2. Place metal legs (B) over
molded pegs on seat underside.
Align metal holes with peg holes.
3. Place collar (C) over exposed
peg.
4. Place screw (D) through collar (C)
then attach metal legs (B) to seat
bottom using screws.

Part List

1 Dahlia Seat (A)
1 Metal Legs (B)
4 Collars (C)
4 Screws (D)
031105
