ASSEMBLY AND USE MANUAL

ALUMINIUM TOWER ALU -50

DACAME, S.L.

Ctra. Santa Bárbara-La Senia, Km. 4,6

43515 La Galera (TARRAGONA) Esp.

Telf: +34 977 71 70 04

Fax: +34 977 71 93 89

E-mail: dacame@dacame.com - www.dacame.com

Table of Contents

Need help?

Do you have a question about the ALU-50 and is the answer not in the manual?

Questions and answers

Summary of Contents for DACAME ALU-50

Page 1 ASSEMBLY AND USE MANUAL ALUMINIUM TOWER ALU -50 DACAME, S.L. Ctra. Santa Bárbara-La Senia, Km. 4,6 43515 La Galera (TARRAGONA) Esp. Telf: +34 977 71 70 04 Fax: +34 977 71 93 89 E-mail: dacame@dacame.com - www.dacame.com...
Page 2 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110...
Page 3: Table Of Contents
ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 INDICE 1 INTRODUCTION ......... .. 4 2 GENERAL INFORMATION .
Page 4: Introduction
ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 INTRODUCTION The range of aluminum towers "ALU-50" are in accordance with the UNE-EN 1004: 2006 standard ‘Access towers and mobile work towers built with prefabricated elements. Materials, measurements, design loads and safety requirements.
Page 5: Identification Of Elements And Configurations
TOWER ALUMINIUM “ALU 50” versión 091110 IDENTIFICATION OF ELEMENTS AND CONFIGURATIONS In the “ALU-50” system, there are 2 series of towers: 1. 075 series 2. 135 series The 075 series is characterized by being made up of 750 mm wide...
Page 6 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 SERIE 075 MODEL 7502 7503 7504 PLATFORM 3,37 3,84 HEIGHT (m) TOWER TOTAL 4,37 4,84 HEIGHT (m) WORKING HEIGHT 5,37 5,84...
Page 7 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 ELEMENTS FOR THE SERIE 750 COD.ELEM. 512007594 510075139 511075139 510075185 511075185 DIMENSIONS 750x1392 750x1856 750x945 Frame 3 FRAME 3 Frame 4 Frame4 ledger and NAME Ledgers and Guardrail LEDGERS Ledger ladder ladder WEIGHT(Kg)
Page 8 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 SERIE 1350 MODEL 13503 13505 13508 13512 PLATFORM 3,37 7,55 HEIGHT (m) TOTAL TOWER 4,37 8,55 HEIGHT(m) WORKING 5,47 9,55 HEIGHT (m)
Page 9 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 ELEMENTS FOR THE SERIE 1350: COD.ELEM. 510135139 511135139 510135185 511135185 510135232 511135232 DIMENSIONS 1350x1392 1350x1856 1350x2320 FRAME WITH FRAME 4 FRAME WITH fRAME 3 FRAME 4 FRAME 5 NAME 3 LEDGERS LEDGERS 5 LEDGERS LEDGERS...
Page 10: Assembly And Disassembly
091110 ASSEMBLY AND DISASSEMBLY The number of people necessary to carry out the assembly and disassembly of the aluminum tower "ALU-50", in any of its variants, is a minimum of 2 people.. 6.1 PREVIOUS CONSIDERATIONS Sufficient resistance of the ground on which the tower will sit must be ensured.
Page 11: Assembly Series 750 (Model 7504)
ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 6.2 ASSEMBLY SERIE 750 (MODEL 7504) STEP 1: Insert the adjustable wheels inside the frames. STEP 2: Attach 2 horizontal bars. One bar on the lower horizontal cross member of the frames, and the other on the vertical upright The LEDGERS are characterized by having a green locking latch.
Page 12 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 Attach the other ends that are free of the horizontal edgers to the other frame, which must be with a ladder. Previously to this frame the wheels will have been introducedas. The brakes should be applied to the wheels to prevent them from sliding...
Page 13 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 STEP 5: The next level of frames will be mounted, securing them with pins to prevent accidental disassembly. Next, the next level of diagonals will be mounted, in the same way as step 4.
Page 14 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 Next, the railing frames will be assembled, securing them by means of the pins to avoid their accidental disassembly. Mount the horizontal bars at 1 m and 0.5 m from the platform level, to complete the side protection.
Page 15: Assembly 1350 Series (Model 13512)
ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 6.3 ASSEMBLY SERIE 1350 (MODEL 13512) STEP 1: Insert the adjustable wheels inside the frames. STEP 2: Attach 2 horizontal bars. One bar on the lower horizontal cross member of the frames, and the other on the vertical upright...
Page 16 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 STEP 3: Attach the other ends that are free of the horizontal bars to the other frame, which must be with a ladder. Previously to this frame the wheels will have been inserted.
Page 17 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 STEP 5: The next level of frames will be mounted, securing them with the pins to prevent accidental disassembly. Next, the next level of diagonals will be mounted, in the same way as step The telescopic stabilizers will be mounted, verifying that they are well secured on the uprights of the frames.
Page 18 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 STEP 6: The next level of frames will be mounted, with its corresponding level of diagonals. The frame with ladder on the lower frame without ladder, and vice versa. The lateral protection on the platform will be enabled by mounting 4 horizontal bars.
Page 19 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 STEP 7: The lower platform of step 6 will be repositioned, on the last level of frames, and then we will mount a last level of frames and diagonals.
Page 20 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 PASO 8: The upper level of platforms will be mounted on the last level of frames, consisting of a platform with a hatch and a fixed platform. The lateral protection will be completed, by means of the 4 horizontal bars and the deployable skirting board.
Page 21: 6.4 Disassembly
ADDITIONAL INFORMATION ON STABILITY AND USE For any configuration not included in this manual, consult the manufacturer. The “ALU-50” towers should not be used when the wind exceeds 50 km / h. The towers must be vacated and dismantled when wind conditions exceed this value.
Page 22: Frequent Risks And Preventive Measures In The Use Of Scaffold
The changes of position of the tower will be carried out having previously unlocked the braking devices of the 4 wheels and pushing it evenly from the frame. The “ALU-50” system towers are not designed to be raised or suspended.
Page 23 TOWER ALUMINIUM “ALU 50” versión 091110 7. MAINTENANCE Keeping the components of the "ALU-50" tower in perfect condition guarantees greater durability, as well as a lower risk of accidents due to possible damage. The material is protected against corrosion, but exposure to highly corrosive environments, strong blows, misuse, accumulated dirt, etc., can...
Page 24 ASSEMBLY AND USE MANUAL TOWER ALUMINIUM “ALU 50” versión 091110 DACAME, S.L. Ctra. Santa Bárbara-La Senia km 4,6 43515 La Galera (TARRAGONA) Telf: 977 71 70 04 Fax: 977 71 93 89 E-mail: dacame@dacame.com - www.dacame.com DISTRIBUITOR:...
