Assembly Instructions with DryAir (Twin Version)
ONE NUT ASSEMBLY
The DryAir Unit has been assembled except for attaching the base assembly to the Dryer Unit
Assembly with 1 screw through the base.
3
NOTE: The height of the DryAir
Box can be adjusted using the
Allen keys and nuts, sliding along
the support column.
The DryAir Box should have
a column bracket and 2 x "T" slot
slides attached to it.
2
Cart with
Support shelf for twin
AquaCare machine
Attach control knob to
front of DryAir Unit
Insert the Socket
Head Bolt and Metal
Washer through the
hole underneath
Metal Base
Assembly (1).
Air
Advertisement
Summary of Contents for AquaCare DryAir
- Page 1 Cart with Assembly Instructions with DryAir (Twin Version) ONE NUT ASSEMBLY The DryAir Unit has been assembled except for attaching the base assembly to the Dryer Unit Assembly with 1 screw through the base. Support shelf for twin AquaCare machine...
- Page 2 Cart with Parts List Illustration Metal Base Assembly Profile View Column Support DryAir Box with Bracket T-Slot Nut x 2 Support Shelf For Twin AquaCare Machine Filter with Bracket Fixing Components Socket Head Screw Metal Washer 4mm & 6mm Allen Keys...
