Link Closed Caption Decoder PDC-888 Specifications

LINK ELECTRONICS, INC.
CLOSED CAPTION DECODER PAL & NTSC, CV, CAV, & Y/C
MODEL PDC-888
FEATURES
Field 1 & Field 2
Captions
Text
XDS
EIA-608 Extended Character Set
All video Channels Power Line by-pass
The PDC-888 is a high performance Closed Cap-
tion Decoder for the NTSC/PAL system. It is capa-
ble of displaying captions for CV, CAV and Y/C as
required by EIA-608. This includes the codes
specified by the FCC Report and Order on General
Docket No. 91-1 and EIA-608 recommended prac-
tices for Captions, Text and XDS.
Nine standard data channels are supported by the
PDC-888: Caption channels 1 through 4 (CC1-
CC4), Text modes 1 through 4 (T1 through T4), and
Extended Data Services (XDS).
operational modes are selectable from four front
panel switches.
The component inputs accept RGB or YUV. All
connectors use BNC except the S-Video connector
The caption data is keyed into all component
channels. Packaged in LINK's standard 1 RU 800
Series chassis, the PDC-888 is both rugged and
reliable.
PROFESSIONAL SERIES--
stand-alone system products--by
LINK
ELECTRONICS, INC. g 2137 Rust Avenue g Cape Girardeau, MO 63703-7668
The PDC-888 automatically detects PAL or NTSC
The AC line voltage selects between 96 to 245
volts.
Designed with the professional user in mind, the
PDC-888 processes Composite video, Component
video and S-Video. All video inputs including CV,
CAV and Y/C have AC power by-pass in the event
power line failure. Component video is internally
terminated. S-Video is standard levels, using a 4-
pin Mini-Din connector for ease of operation. A
complementary differential input amplifier assures
The various
high common mode rejection while its phase-linear
keyer cleanly inserts decoded characters into the
video image. Differential gain and phase are well
within 0.1% and 0.1° respectively.
In addition, the PDC-888 is backed by a standard
10-year warranty. High performance, flexibility, and
economy are equally represented in the PDC-888
Closed Caption Decoder.
LINK
Phone 573 334 4433 g
PAL/NTSC Auto Detect
S-Video I/O
Composite Video I/O
Component Video I/O
Standard Rack Mountable
120/240 AC Line Voltage Detect
FAX 573 334 9255
CLOSED CAPTION SERIES
MADE IN THE USA
