9004/9007 HID Low Beam Kit (35W or 55W)
TOOLS NEEDED: None
R R E E A A D D F F I I R R S S T T : :
Most 9004/9007 kits are relatively easy to install. Usually removal of
the headlight isn't necessary. If removal of the headlight assembly is necessary
please refer to your vehicle's owners manual for instructions. Note: We are using
a 1997 Jeep Cherokee for our install.
DIFFICULTY: Easy
D D D D M M
TUNING.COM
Professional Install
Remove the OEM bulb from the headlight
housing. To do so, remove the bulb locking
ring by twisting it counter clockwise, which
will release the bulb from the housing.
Remove the bulb locking ring on the low
beam by simultaneously unclipping and
pulling the connector away from the bulb.
1
2
PAGE 1/3
Advertisement
Table of Contents
Summary of Contents for DDM 9004
- Page 1 R R E E A A D D F F I I R R S S T T : : Most 9004/9007 kits are relatively easy to install. Usually removal of the headlight isn’t necessary. If removal of the headlight assembly is necessary please refer to your vehicle’s owners manual for instructions.
- Page 2 DDM INSTALL GUIDE - 9004/9007 HID Low Beam Kit (35W or 55W) Pictured is the bulb unclipped from the stock power supply. Next, plug in the adapter cables (blue plug) Into your OEM low beam power supply. Pictured is your new HID wiring so far.
- Page 3 DDM INSTALL GUIDE - 9004/9007 HID Low Beam Kit (35W or 55W) Reinstall your bulb locking ring with the new HID bulb in place. To do so simply make sure it is flush with the base of the bulb and turn clockwise.
