Summary of Contents for Northern Industrial Tools 426282
- Page 1 36" METAL BENDER OWNER’S MANUAL WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #426282...
-
Page 2: Intended Use
INTENDED USE Heavy-duty metal bender easily bends up to 12-gauge sheet metal. Quickly adjusts for different sheet metal thickness. TECHNICAL SPECIFICATIONS & PACKING LIST Item Description Metal Bender 36" Stand Included Maximum Thickness 12 gauge Minimum Bend Angle 0° Maximum Bend Angle 120°... -
Page 3: Safety Warnings And Cautions
understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. SAFETY WARNINGS & CAUTIONS WARNING: When using tools, machines or equipment, basic safety precautions should always be followed to reduce the risk of fire and personal injury. -
Page 4: Personal Safety
• CHECK FOR DAMAGED PARTS. Before using a tool, any part that appears damaged should be carefully checked to determine if it operates properly and performs its intended function. Check for alignment, binding of moving parts, any broken parts or mounting fixtures, or any other condition that may affect its performance. -
Page 5: Operation
• Put the Bender and Stand where it will be mounted to the floor and mark the mounting holes. • Drill holes in the floor. Secure the Bender with bolts, lock washers and nuts (not included). WARNING: Before drilling the mounting holes, make sure that there is no electrical conduit or water pipes. -
Page 6: Diagram & Parts List
• Cleaning. Only use soap and a damp cloth to clean your tools. Many household cleaners are harmful to plastics and other insulation. Never let liquid get inside a tool. • Always use caution when moving or handling the Metal Bender. •... -
Page 7: Warranty
Part No. Description Part No. Description Handle cover Bolt M16X35 Left crank handle Upper press plate Washer Bending leaf Left eccentric bushing Leg for stand Nut M16 Level plate for stand Connecting shaft Frame Bolt M12X12 Turning shaft Lock nut M20 Right eccentric bushing Square steel holder Right crank handle...
