- Page 1 Smart Door Systems Installation www.sds-tech.com...
- Page 2 Cylinder installation and test Ensure locking system in “unlock” position. Insert cylinder (B direction) with slot “C” vertical. Slot part of the cylinder should be positioned on the interior apartment side. Tighten the cylinder screw “A”. Cylinder face should be at least 4 mm inside from the interior door surface ”D”.
- Page 3 Turn carefully the unit and slide the plastic on the cylinder body. Carefully ensure that the metal arm will enter correctly to the vertical cylinder slot. Keep the unit tight as in picture and mark location of the 4 screws – A,B,C,D. Screw 4 “self drilled”...
- Page 4 1. Insert plastic part A and calibrate handle center to be in the center of hole B. 2. Mark location of holes: A,B,C,D,E. 3. If wooden door – drill only E = 10mm 4. IF Steel door : E=10-12 mm, pass to the exterior side (see next page) A,B,C,D = 2.5mm The best for steel door is to use “self drill...
- Page 5 - 10 - 12 mm hole pass from the opposite side. - 3.5mm hole from shablone for RFID Unit. – 10mm exact hole for proximity module. On the same horizontal line with hole A.
