Summary of Contents for Discovery Adventures DS990
- Page 1 User manual DS990...
- Page 3 GPS player and player user manual...
- Page 5 Structure 1. OK button 9. USB Port 2.Menu button 10. Second lens 3.Up button 11. GPS port 4. Down button 12. Speaker 5.Mode button 13.Main lens 6.ON/OFF 14. LCD screen 7.Reset hole 15. Work indicate light 8.Micro SD Card Slot...
- Page 6 Function 1. On/Off A. Power On In the off state, long press ON/OFF button. DVR enters into video mode and start recording automatically. Or DVR is connected with car charger in the off state to enter video mode and start recording automatically. When unplug the charger, DVR will automatically save the current file and shut down in 5 seconds delay.
- Page 7 2. Battery Charging In the charge state, battery icon will flash, stop to flash after full charged. 3. Video Press ON/OFF button to power on DVR and enter into video state automatically. Press OK button to stop recording and save the current file, then DVR goes into standby mode. In standby mode, press OK button to restart recording, press again to stop recording.
- Page 8 5. Playback and Delete In video standby mode, short press Mode button twice to enter into playback mode. Press Up/Down button to select the file. OK button is used for play or pause. If you want to delete files, press Menu button to be in Delete menu.
- Page 9 8. Switch Lens In video/standby mode, press ON/OFF button to switch lens. 9. Park Monitoring Function In Settings menu, turn on park monitoring function with screen appears P icon (Turn off park monitoring function, P icon will disappear). Turn off camera, if camera detects vibration and moving object, it will recording automatically and shutdown after 10 seconds.
- Page 10 11. GPS Function A. Insert G-MOUSE into camera. B. GPS signal will display ‘X’ icon on the screen upper middle, it indicate camera not received signal successfully. When ‘X’ icon disappeared, it indicate camera locate GPS successfully. C. Please use professional players to play video, current driving pace and coordinate Will display on the player.
-
Page 11: Menu Setting
Menu Setting MODE Category Sub-Category Remarks 1080FHD 1920x1080 720P 1280x720 Single Lens WVGA 848x480 Resolution Factory default: 1080FHD 640x480 Video 1080P 1440*1080 Dual Lens 720P 1280*720 Dual Lens Recording On/Off Loop Recording Off /3mins/5mins/10mins Factory default: 3mins... - Page 12 MODE Category Sub-Category Remarks Time-lapse Record Off/100MS/200MS/500MS Off/On Factory default: +2.0,+5/3,+4/3,+1.0,+2/3,+1/3,+0.0, -1/3,-2/3,- Exposure Factory default: +0.0 1.0,-4/3,-5/3,-2.0 Video Motion Detection Off/On Factory default: Off Audio Off/On Factory default: On Date Stamp Off/On Factory default: On G-sensor Off/High/Medium/Low Factory default: Medium Off/On...
- Page 13 MODE Category Sub-Category Remarks The first words is Chinese character in Chinese Adjust license plate number License Plate language. The first words is English letters at way please refer to next page. Video other languages. Parking Monitor Off/On Factory default: Off Capture Mode Single/2sec/5sec/10sec Factory default: Single...
- Page 14 MODE Category Sub-Category Remarks Factory default: Color Color Color/Black & White/Sepia Auto/100/200/400 Factory default: Auto +0.0,-1/3,-2/3,-1.0,-4/3,-5/3,- Exposure Factory default: +0.0 2.0,+2.0,+5/3,+4/3,+1.0,+2/3,+1/3 Anti-shake Off/On Factory default: Off Quick Review Off/2seconds/5seconds Factory default: Off Date Stamp Off, Date, Date/Time Factory default: Date/Time Delete Delete current/Delete all Lock Current/Unlock Current/Lock A ll/Unlock...
- Page 15 Category Sub-Category Remarks Date/time MM/DD/YY,DD/MM/YY,YY/MM/DD Factory default: Off Auto Power Off Off/3mins/5mins/10mins Factory default: Off Beep Sound Off/On English/German/French/Spanish/Portuguese/Italy/traditional Chinese, Language simplified Chinese/Japanese/Russian Frequency 50Hz/60Hz Off/GMT-12:00/GMT-11:00/GMT-10:00/GMT-09:00/GMT-08:00/GMT-07:00/ GMT-06:00/GMT-05:00/GMT-04:30/GMT-04:00/GMT-03:30/GMT-03:00/ GMT-02:00/GMT-01:00/GMT+00:00/GMT+01:00/GMT+02:00/GMT+03:00/ GMT+08:00 GMT+03:30/GMT+04:00/GMT+04:30/GMT+05:00/GMT+05:30/ GMT+05:45/GMT+06:00/GMT+06:30/GMT+07:00/GMT+08:00/ GMT+09:00/GMT+09:30/GMT+10:00/GMT+11:00/GMT+12:00/GMT+13:00...
- Page 16 Category Sub-Category Remarks Format Micro SD Card Screen Saver Off/30sec/1min/2mins Factory default: 1min Delay Shutdown Off/5s/10s/30s Factory default: 5s Default Setting Cancel/OK Version Current version Adjust plate number ways: At plate number adjust interface (The first words is Chinese character in Chinese language.
- Page 17 14. Computer connection Video and Photo Download 1. When USB cable connects to your computer and DVR, red indicator light will be steady on. The screen pops up categories- Mass Storage and PC Camera. 2. If select Mass Storage and DVR screen changes to be blue. The Micro SD card disk will be recognized by computer.
-
Page 18: Specification
Specification Note: Specification may change due to upgrades. Please take the objects as standards. Screen 3.0 inch TFT LCD screen (960*240) Photo Format Pixel 3.0 MP Dual Lens Support Lens 120 degree wide angle lens Motion Detection Support Minimal Illumination 1LUX Loop Recording Off/3mins/5mins/10mins... - Page 19 USB Port USB2.0 Power Port USB 5V Frequency 50HZ/60HZ Mic/Speaker Support English/Français/Español/ Português/Deutsch Language /Italiano/Chinese/Русский/ Japanese/ Accessories The following accessories are for reference only. Please take object as standard. Supplier reserves the rights to change without prior notice.
- Page 20 www.bar-brands.com...
