Getting Started Contents GETTING STARTED Symbols used in this guide Symbols & legends used on the kryo·connect Notices Introduction Connections and Indicators Minimum System Requirements Network: Client PC: Administrator's PC Connecting to the network Preparing for Configuration Starting kryo-connect Configurator software On a PC running Windows 32 On a PC running Linux Running kryo-connect Configurator...
Getting Started Getting Started Symbols used in this guide Failure to follow these instructions could result in personal injury. Failure to follow these instructions could result in damage to your equipment or system. Symbols & legends used on the kryo·connect Read the manual as failure to follow these instructions could result in personal injury.
Getting Started Notices This product and the information, reports and e-mail messages provided by the unit must not be used in safety critical applications. The kryo·connect is intended for information purposes only and must not be the sole means of monitoring alarm and fault conditions.
Getting Started The actual operation of the software depends upon the application that has been loaded into the unit. This is identified by the label on the end of the unit. Once the unit is connected to your network and accessible through your web browser, you will be able to access the online manual from the unit's home page.
Getting Started Minimum System Requirements Before trying to install the kryo·connect you must ensure that your network and client PCs meet the minimum system requirements. Network: • 10 BaseT ethernet. Category 5e cable recommended as minimum. • Free RJ45 Socket on hub or router located within 100m (330 feet) of the unit.
PC with an Ethernet connection you must use a crossover patch cable. These cables are available from Planer plc. • Connect one end of the appropriate cable to the unit and the other end to the network hub or PC as shown below taking care not to touch the pins of the connectors.
Getting Started Should you need to create a longer cable for your installation, the connection details are given in the section Ethernet Cables. Check that the voltage rating of the kryo-connect power supply matches your mains power outlets. If not, contact your supplier and do not continue with the installation.
Getting Started kryo-connect Configurator is a Java ™ application and is provided on the kryo-connect Configuration CD along with the Java Runtime Environment (JRE). For the best results when using this software, ensure that any kryo-connect units are located within the same network segment as the Administrator’s PC. Note that this software may not be able to address units if a firewall or router needs to be traversed.
Getting Started Running kryo-connect Configurator • In the Device serial number field enter the serial number of the device you need to configure. The serial number is on the label on the end face of the unit. Network settings should only be configured by the network administrator familiar with the network to which the kryo- connect is being connected.
Getting Started Note that the configuration is only temporary and will be lost if the system is reset. • If a connection failed page appears, check the serial number you used for the configuration. Click Exit on the kryo-connect Configurato and then repeat the process from the start.
Getting Started Configuration Details As you follow the instructions in this guide you should also complete the details of your kryo-connect in the table below. Serial number IP Address Network Mask Default Gateway DNS Server URL to access the kryo-connect...
Getting Started Ethernet Cables Should you need to create your own ethernet cables, details of the pinouts are shown below. Colours shown are to the EIA/TIA 568A colour scheme. All connectors are shown with the clip downwards. Standard Patch Cable Colour White/Green White/Green...
Getting Started RS232 / RS485 Connections The kryo-connect is provided with a 9 way D-Type plug that can be configured for both RS232 and RS485 interfaces. The actual configuration is determined by dip-switches inside the unit and is normally factory configured.
Your Licence and this Licence Agreement are automatically terminated with immediate effect if you contravene any of the above conditions (i) to (vi); this termination shall be without prejudice to any criminal, civil, or other remedy available to Planer plc.
In such event you agree that you will destroy the Software and all copies in any form, without delay, and that you will provide Planer plc with a written statement confirming destruction thereof. Termination shall be without prejudice to any action by Planer plc.
Page 19
License and refund the fee paid by Licensee, if any, as the Licensee's sole and exclusive remedy. Planer plc will not under any circumstances be liable to you or any other user for any damages, including loss of profits, lost data, or any other incidental or consequential losses or damages, arising out of the use or inability to use the Software.
Getting Started Specifications kryo·connect DC power inlet 5 V ± 0.25V 300 mA Interfaces RS232/RS485 - 9 way D Type plug - pinout as DTE for RS232 10 Base T Ethernet - RJ 45 shielded Internet SMTP e-mail client FTP server Telnet client/server HTTP v1.0 web server TCP-IP/UDP/ICMP...
Page 21
Getting Started This page left deliberately blank.
Page 22
Getting Started This page left deliberately blank.
