2019-4019
2019-11-01
A maximum of 283,900 L of water can be treated with ECOLAB Aqua Balance Pure Comfort
Maximum output of hypochlorous acid equivalent to 2.268 kg of free available chlorine per day.
For swimming pools, a range of 1.0 - 3.0 ppm of free available chlorine must be maintained. For
spas, a range of 3.0 - 5.0 ppm of free available chlorine must be maintained.
WARNING: Operating the ECOLAB Aqua Balance Pure Comfort, Model 5.0, without water
flow through the cell can cause a buildup of flammable gases which can result in
NOTICE TO USER: This pest control product is to be used only in accordance with the directions
on the label. It is an offence under the Pest Control Products Act, to use this product in a way
that is inconsistent with the directions on the label.
ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa System,
CHLORINE GENERATOR CONTROLS BACTERIA AND ALGAE
in Swimming Pool (and Spa) Waters
Mineral Pool & Spa System, Model 5.0
KEEP OUT OF REACH OF CHILDREN
READ THE LABEL AND OPERATING MANUAL BEFORE USING
REGISTRATION NO. 29220 PEST CONTROL PRODUCTS ACT
Ecolab Inc., 1 Ecolab Place, St. Paul, MN 55102
Model 5.0
COMMERCIAL
FIRE OR EXPLOSION.
1-800-352-3526
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ecolab 5.0
Summary of Contents for Ecolab 5.0
- Page 1 Swimming Pool (and Spa) Waters COMMERCIAL A maximum of 283,900 L of water can be treated with ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa System, Model 5.0 Maximum output of hypochlorous acid equivalent to 2.268 kg of free available chlorine per day.
- Page 2 REGISTRATION NO. 29220 PEST CONTROL PRODUCTS ACT This electrode must only be used on this model of chlorine generating device. READ THE LABEL AND REFER TO OWNER'S MANUAL OF THE ECOLAB Aqua Balance Pure Comfort System, Model 5.0, BEFORE USING.
- Page 3 ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa System USER’S GUIDE MODEL 5.0...
-
Page 4: Table Of Contents
TABLE OF CONTENTS INTRODUCTION……………………………………………………………….4 WARRANTY INFORMATION…………………………………………………5 SAFETY INFORMATION……………………………………………………6-7 PREPARING YOUR WATER BEFORE INSTALLATION……………….8-9 SALT CHART FOR CORRECT MAINTENANCE…………………………10 TOOLS AND PARTS REQUIRED FOR INSTALLATION………………..11 INSTALLING YOUR SYSTEM – PLUMBING………….……………….12-13 ELECTRICAL………….………………14 SPECIFICATIONS AND FUSE SIZING……………………………………..15 STARTING THE SYSTEM………………………………………………….…15 GENERAL OPERATION………………………………………………………16 MAINTENANCE AND CLEANING………………………………………..…17... - Page 5 For swimming pools, a range of 1.0 - 3.0 ppm of free available chlorine must be maintained. For spas, a range of 3.0 - 5.0 ppm of free available chlorine must be maintained. KEEP OUT OF REACH OF CHILDREN READ THE LABEL AND OPERATING MANUAL BEFORE USING REGISTRATION NO.
-
Page 6: Introduction
This electrode must only be used on this model of chlorine generating device. READ THE LABEL AND REFER TO OWNER'S MANUAL OF THE ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa Saline System, Model 5.0, BEFORE USING. ECOLAB Inc., 1 Ecolab Place, St. Paul, MN 55102 Ecolab Inc.. -
Page 7: Warranty Information
ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa ® Model 5.0 shall at it’s sole discretion elect to repair or replace the defective component and return it to the customer, freight pre-paid. ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa ®... -
Page 8: Safety Information
• Modifying your ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa ® Model 5.0 system in anyway may cause bodily injury and will void your warranty. • Warning: To reduce the risk of injury, do not allow children to operate this device. - Page 9 • When replacing the cell, only use replacement cells having a label that clearly states that it is a replacement cell for the chlorine generating device ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa Saline Chlorination System, Model 5.0, REGISTRATION NUMBER 29220, PEST CONTROL PRODUCTS ACT.
-
Page 10: Preparing Your Water Before Installation
In order for your ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa ® Model 5.0 system to operate correctly, sodium chloride (salt) must be added directly to the pool at least 24 hours before the installation of the equipment. - Page 11 Swimming pool Salt level 4,000 – 5,000 ppm 4,000 – 5,000 ppm NOTE: Low salt levels will cause a reduction in chlorine production and will damage the device. High salt levels will increase the possibility of corrosion on pool equipment. NOTE: If too much salt has been added, dilute with fresh water.
-
Page 12: Salt Chart For Correct Maintenance
The following is a chart to determine the amount of salt required to raise a pool or spa to 5000 ppm SALT CHART FOR CORRECT MAINTENANCE ppm Salt Levels Number of KG of Salt to Be Added ppm Salt Pool and or spa Volume (litres) 1,000 100,000 200,000... -
Page 13: Tools And Parts Required For Installation
TOOLS AND PARTS REQUIRED FOR INSTALLATION Your ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa ® Model 5.0 system will include an installation kit comprising of the following items: Description Strainer clear bowl with 20 mesh PVC ball valve Sch. 40 PVC male adaptor Sch. -
Page 14: Installing Your System - Plumbing
ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa ® Model 5.0 system requires a minimum of 75 Lpm of flow through the cell to produce the rated amount of chlorine. Be sure that if you use the pressure drop plumbing method [1] you have sufficient pressure drop across your filter to adequately flow 75 Lpm through the cell. - Page 15 PRESSURE-DROP PLUMBING METHOD [1] ECOLAB Aqua ECOLAB Aqua Balance BYPASS MANIFOLD PLUMBING METHOD [2] ECOLAB Aqua ECOLAB Aqua Balance Pure...
-
Page 16: Electrical
• Model 5.0 operates at 110 – 120v. A power cord will be supplied out of the power box. Plug this into any standard 110 – 120v outlet. As above, the cord labeled ORP must be plugged into a controller, or a 120v outlet. -
Page 17: Starting The System
ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa ® Model 5.0 system has been successfully wired and plumbed, it is ready for use. • Make sure that the valves to and from the cell are in the open position. -
Page 18: General Operation
ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa ® Model 5.0 cell is critical. Whether you plumbed your system in using the pressure drop or bypass method, please ensure that you have at least 75 Lpm through the cell to achieve the rated chlorine production. -
Page 19: Maintenance And Cleaning
• Remember, the titanium plates that make up the cell are the most expensive part of the ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa ® Model 5.0 system and are going to need to be replaced roughly every 15,000 hours of operating time. By ensuring that salt is... - Page 20 “life”, thus saving you money… ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa ® Model 5.0 offers a wide range of other products that can help you maintain salt levels in your pool, including conductivity controllers and saturated salt feeders for those pools that lose large amounts of water.
