Summary of Contents for Harman Soundcraft ViSi
- Page 1 User Guide...
- Page 2 All rights reserved. Parts of the design of this product may be protected by worldwide patents. Soundcraft is a trading division of Harman International Industries Ltd. Information in this manual is subject to change without notice and does not represent a commitment on the part of the vendor. Soundcraft shall not be liable for any loss or damage whatsoever arising from the use of information or any error contained in this manual.
-
Page 3: Table Of Contents
Gate and Compressor Graph input Level Meter PROCESSING PAGES - MISC. (Si only) Meter displays Gain/Trim and 48v control Indicators METERS PAGE (Si only) The Meters page Meters Page Navigation Feature ViSi REMOTE V2.1.X NOTES Notes regarding off-line operation Trouble-shooting Soundcraft ViSi Remote User Guide 0614... -
Page 4: About Visi Remote
ABOUT ViSi REMOTE Soundcraft ViSi Remote is an iOS® application that allows remote control of Soundcraft Si Expression, Si Performer, Si Compact, and Vi Series mixing consoles wirelessly from your iPad device. Operation is easy thanks to Soundcraft’s FaderGlow™ graphics that closely represent the console. -
Page 5: Setting Up
NOTE: Significant traffic or interference in the Wi-Fi domain may cause sluggish or unreliable operation; if you experience such problems we recommend you seek specialist advice from a Wi-Fi IT professional. Soundcraft ViSi Remote User Guide 0614... -
Page 6: Setting Ip Addresses
In order to utilise ViSi Remote’s global and per channel metering, your chosen router must have UDP enabled within the control panel. Please refer to the user guide of your chosen router for instructions on how to enable UDP . Soundcraft ViSi Remote User Guide 0614... -
Page 7: Ipad Settings For Visi Remote
HiQnet devices connected to the router. The valid HiQnet range is 1-65535. Please see: ‘Setting HiQnet device address’ for notes on the rules governing HiQnet addressing. Soundcraft ViSi Remote User Guide 0614... -
Page 8: Setting Hiqnet Device Address
• [ ] button: refreshes the devices list of consoles. NOTE: any consoles manually removed from the devices list with the Edit button but which are still discoverable on the network will reappear automatically. Soundcraft ViSi Remote User Guide 0614... -
Page 9: About View
In this example, the currently connected router is ‘Koko 2.4G’ About view [i] The ‘ A bout’ view is opened with the [i] button on the devices view. It provides non-editable information about the current version of ViSi Remote. Soundcraft ViSi Remote User Guide 0614... -
Page 10: Main Fader Page (Si)
VCAS: displays the VCA masters for editing from the app. Note: VCA assignments are not currently available on the app and must be setup from the console. Note: Si Expression and Compact do not have an option for VCA’s. Soundcraft ViSi Remote User Guide 0614... -
Page 11: Info View
The GEQ can be swiped to scroll though the available bands; the last viewed page will be remembered for the current bus, and will be returned to the next time the GEQ is opened. Soundcraft ViSi Remote User Guide 0614... - Page 12 Soundcraft Vi1, if a VCA master is assigned to the hot channel the scroll keys will scroll through VCA1-8. NOTE: When in CONTRIB mode, the hot channel assignment is disabled. Soundcraft ViSi Remote User Guide 0614...
-
Page 13: Main Fader Page (Vi)
This is ideal for use with an IE system during soundcheck, allowing the engineer to solo a channel and listen to its incoming source during the mic setup. Soundcraft ViSi Remote User Guide 0614... -
Page 14: Processing Pages (Si Only)
PROCESSING PAGES (Si only) Swipe Up to access the above page of controls Swipe Left to edit the Swipe Right to edit the previous channel next channel Swipe Down to access the below page of controls Soundcraft ViSi Remote User Guide 0614... -
Page 15: Processing Pages - Eq (Si Only)
Simply tap the parameters and the wheel will appear. While still pressing the screen, gesture around the wheel clockwise or counter-clockwise to increase/decrease the value. Soundcraft ViSi Remote User Guide 0614... -
Page 16: Processing Pages - Dynamics (Si Only)
Note: As the compressor is after the noise gate in the signal path, when the Gate is shut incoming signal to the compressor will be reduced by the gates depth setting. Keep in mind this signal path when observing the bouncing ball meters. Soundcraft ViSi Remote User Guide 0614... -
Page 17: Processing Pages - Misc (Si Only)
Note: Although clipping the Post-processing meter would not result in audible clipping (thanks to 40-bit floating point DSP), it is best to keep this signal under control to achieve the best gain structure for mixing. Soundcraft ViSi Remote User Guide 0614... -
Page 18: Gain/Trim And 48V Control
It is not possible to turn these functions on or off using the indicators. Turning LCR or isolate on or off must be done on the console during setup. Soundcraft ViSi Remote User Guide 0614... -
Page 19: Meters Page (Si Only)
Main Fader Page channels and busses. Simply tap a segment of 8 channels on the meter bridge to jump straight to the fader bay page for that selection of channels. Soundcraft ViSi Remote User Guide 0614... -
Page 20: Visi Remote V2.1.X Notes
If using DHCP , double check that all devices on the network are set for DHCP as the method to resolve the IP address and that your router is set as a DHCP server. Soundcraft ViSi Remote User Guide 0614... - Page 21 The ViSi Remote graphics are rotated by 90 degrees on the iPad screen. You are running an old version of ViSi Remote with iOS 6.0. Upgrade ViSi Remote to V2.1.x or later. iPad and iOS are trademarks of Apple Inc. Soundcraft ViSi Remote User Guide 0614...
- Page 22 Soundcraft ViSi Remote User Guide 0614...
- Page 23 Soundcraft ViSi Remote User Guide 0614...
- Page 24 ® HARMAN Soundcraft Harman International Industries Ltd. Cranborne House Cranborne Road Potters Bar Hertfordshire EN6 3JN United Kingdom +44 (0)1707 665000 www.soundcraft.com...
