Summary of Contents for Discovery Kids WOODEN WORK BENCH
- Page 1 AGES instruction manual IMPORTANT: Please read all instructions and warnings in this manual prior to using your work bench.
- Page 2 Introduction Congratulations on your purchase of the Discovery Kids™ Work Bench. Carefully remove everything from the box before assembling. You will need a Phillips screwdriver and the provided 5/32” allen wrench to assemble this product. Not for children under 3 years old. Adult assembly required.
- Page 3 Contents You should have all of the parts shown in the picture below. Each part is labeled with a letter. The number to the right of the letter indicates the quantity of that part. X (10) B (2) Note: The drawing is not to scale. T (9) Q (13) Y (10)
- Page 4 Assembly Assemble the work bench on a flat surface if possible. Use a mat to protect your floor. Seek help if needed. Attach both sides (C-1 & C-2) to one end (B) using screws (X) and bolts (Y). Slide the shelf (A) into the inside slots then attach the other end (B). Side (C-2) should be facing the front.
- Page 5 Assembly Attach the upper sides (K-1) (K-2) using screws (I) and bolts (J). You may need to nudge the legs so that the screw holes align. Slide the back piece (L) down into the slot on the inside of the upper sides. Attach the supports (N-1) (N-2) using screws (I) and bolts (J).
- Page 6 Assembly Attach the long piece (R) to the short piece (S) using a screw (T). Slide the assembled piece into the back slots.
- Page 7 Assembly Attach the tool shelf (U) using screws (Q). Make sure the recessed holes face up. Attach the back panel (V) using screws (T). Make sure the recessed holes face out.
- Page 8 Assembly Attach the vise (W) using screws (Q). Now that the work bench is assembled, fully tighten all screws. It’s time to play. Try using the hammer to push a nail into the boards. Attach boards using the screwdriver, screws, connectors, and nuts. Use the vise to hold pieces in place while you play. Pretend you are cutting through the boards with the saw.
