Tracker Marine
Power Bimini
OEM INSTALLATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Bimini and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lipper Power Bimini

  • Page 1 Tracker Marine Power Bimini OEM INSTALLATION MANUAL...

  • Page 2: Table Of Contents

    Notes Introduction The SureShade Power Bimini is an electric actuator-driven Bimini top powered by a 12V DC source, that can be controlled by a two-button Touch Controller or with a Bluetooth® compatible app. For information on the assembly or individual components of this product, please visit: https://support.lci1.com/marine-products/...

  • Page 3: Resources Required

    The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause death or serious personal injury and/or severe product or property damage if not performed safely and within the parameters set forth in this manual. Failure to follow instructions provided in this manual may result in death, serious personal injury and/or severe product and property damage, including voiding of the component warranty.

  • Page 4: Preparation

    Preparation Actuator Mounting Locations When installing the complete power bimini system onto the boat's railing, make sure: • The actuators are mounted square, level and plumb to one another (Fig. 1). • No actuator is mounted more than 1/4" ahead of the other (Fig. 1).
  • Page 5 Place the previously removed (step 4) QC power bimini system on top of the frame/railing so that the actuators' mounting studs align with the drilled holes in the frame/railing.
  • Page 6 11. Secure complete QC bimini system in place with 5/16" split lock washers and 5/16"-18 acorn nuts (Fig. 3A) four places. 12. Use a 9/16" wrench to tighten the acorn nuts. Fig. 3 Actuator Mounting Stud Lock Washer Acorn Touch Controller and Nose Mount Cap The Lippert Quick Connect (QC) Touch Controller is pre-wired to the system frame harnesses.

  • Page 7: Without Touch Controller

    Without Touch Controller Nose Mount Caps Install the Lippert QC Power Bimini system per steps 1-12 of the With Touch Controller section and as follows: Note: The Nose Mount Caps are part of the complete system frame, but requires attachment to the boat's railings.

  • Page 8: Operation

    Using the Touch Controller The power bimini system is designed to shut itself off when full travel has been achieved. The system will not open or close any farther once the system has achieved full travel until the opposite button has been touched.
  • Page 9 Turn on electrical power to the boat. If necessary, remove the protective boot from the bimini top. Touch and hold the controller's RAISE button (Fig. 7A) to fully extend the bimini top. Note: Do NOT fully open the QC bimini system without the canvas top installed or failure of the system will result.
  • Page 10 Fig. 9 Fig. 10 App Store ® is a trademark of Apple Inc. Android and Google Play are trademarks of Google LLC. Page 10 Rev: 01.20.22 CCD-0004551...
  • Page 11 Read the Proper Bimini Use and Care and Maintenance statements (Fig. 11A), then tap the Continue button (Fig. 11B). D. Tap OK for Bluetooth (Fig. 12A). Fig. 11 Fig. 12 Page 11 Rev: 01.20.22 CCD-0004551...
  • Page 12 Tap the Connect button (Fig. 13A). Follow the SureShade Connection Steps (Fig. 14A), then tap Continue (Fig. 14B). Fig. 13 Fig. 14 LED Blinks Turquoise Page 12 Rev: 01.20.22 CCD-0004551...
  • Page 13 G. Select the desired bimini from the Available Biminis list (Fig. 15). H. The Touch Controller will begin pairing itself with the smart device (Fig. 16). Fig. 15 Fig. 16 Page 13 Rev: 01.20.22 CCD-0004551...
  • Page 14 Tap the Pair button (Fig. 17A) to complete the connection. The controller and the paired smart device are now connected and the Raise and Lower buttons are now active (Fig. 18). Fig. 17 Fig. 18 Buttons Active Page 14 Rev: 01.20.22 CCD-0004551...
  • Page 15 Only open the bimini top indoors when testing for proper installation. Opening the bimini top outdoors subjects the system to possible strong winds that could result in severe product damage. Only open the bimini top indoors when testing product for proper operation. Tap and hold the Raise button (Fig.
  • Page 16 To disconnect and unpair the iOS smart device from the connected controller, do as follows: With the app open to the Raise and Lower button screen (Fig. 18), tap the gear icon (Fig. 18A) to access the Settings screen (Fig. 21). Tap the slider button (Fig.
  • Page 17 The Paired Shades screen (Fig. 23) will reflect the removed shade. Tap the Back arrow (Fig. 23A) to return to the Connect screen (Fig. 13). Fig. 23 Page 17 Rev: 01.20.22 CCD-0004551...
  • Page 18 If using an Android smart device, do as follows: Search the Google Play Store for the SureShade Connect app. Note: When using SureShade as the search criteria, more than one SureShade app may appear (Fig. 24). Make sure to select SureShade Connect (Fig. 24A). Install (Fig.
  • Page 19 Tap the I Accept button (Fig. 27A) to accept the License Agreement. Read the Proper Bimini Use and Care and Maintenance statements (Fig. 28A), then tap the Continue button (Fig. 28B). Fig. 27 Fig. 28 Page 19 Rev: 01.20.22 CCD-0004551...
  • Page 20 D. Tap OK (Fig. 29A) in the Permissions Request window. Tap the desired option (Fig. 30A) to grant the app access to the device's location. Note: Lippert recommends selecting the "While using the app" option. Fig. 29 Fig. 30 Page 20 Rev: 01.20.22 CCD-0004551...
  • Page 21 Tap the Connect button (Fig. 31A). G. Follow the SureShade Connection Steps (Fig. 32A), then tap Continue (Fig. 32B). Fig. 31 Fig. 32 LED Blinks Turquoise Page 21 Rev: 01.20.22 CCD-0004551...
  • Page 22 H. Select the desired bimini from the Available Biminis list (Fig. 33). The Touch Controller will begin pairing itself with the smart device. The controller and the paired smart device are now connected and the Raise and Lower buttons are now active (Fig. 34). Only open the bimini top indoors when testing for proper installation.

  • Page 23: Without Touch Controller

    To disconnect and unpair the iOS smart device from the connected controller, do as follows: With the app open to the Raise and Lower button screen (Fig. 35), tap the gear icon (Fig. 34C) to access the Settings screen (Fig. 35). Tap the slider button (Fig.

  • Page 24: Troubleshooting

    Troubleshooting What is Happening Why? What Should Be Done? No power. Turn on boat's electrical power. Top does not raise. Bad electrical harness. Contact Lippert representative. Bad actuator. Bad electrical harness. Top does not fully raise. Contact Lippert representative. Bad actuator. Bad electrical harness.

  • Page 25: Notes

    Notes Page 25 Rev: 01.20.22 CCD-0004551...
  • Page 26 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (LCI). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided.  Any unauthorized use shall void any applicable warranty.  The information contained in this manual is subject to change without notice and at the sole discretion of LCI. ...
