REVISION 1.0
Before using the TSU, carefully read all the technical and safety
documentation included in this manual. Pay special attention to the
information in order to know and understand the operation and the
conditions of use of the TSU. All of the information is aimed at improving
user safety and avoiding possible failures from the incorrect use of the
TSU.
EL-51A-RTD
RTD
(RESISTANCE TEMPERATURE DETECTOR)
TEMPERATURE
SENSING
UNIT
Manual
Ref. # MN-04017
Polyurethane Machinery Corp.
Corporate: 1 Komo Dr, Lakewood, NJ 08701
Manufacturing: 2 Komo Dr, Lakewood, NJ
08701
Phone: 732-415-4400
Fax: 732-364-4025
URL:
http://www.polymac-usa.com
Advertisement
Summary of Contents for PMC EL-51A-RTD
- Page 1 EL-51A-RTD (RESISTANCE TEMPERATURE DETECTOR) TEMPERATURE SENSING UNIT Manual Ref. # MN-04017 Polyurethane Machinery Corp. Corporate: 1 Komo Dr, Lakewood, NJ 08701 Manufacturing: 2 Komo Dr, Lakewood, NJ REVISION 1.0 08701 Phone: 732-415-4400 Fax: 732-364-4025 URL: http://www.polymac-usa.com Before using the TSU, carefully read all the technical and safety documentation included in this manual.
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARRANTY ..........................1 SAFETY AND HANDLING ...................... 3 CHARACTERISTICS ......................5 TECHNICAL SPECIFICATIONS ..................... 5 DESCRIPTION ........................6 INSTALLATION ........................7 PART IDENTIFICATION ......................8 MANUAL REVISIONS ......................9... -
Page 3: Warranty
PMC manufactured accessories delivered with the equipment (hereinafter “Product”) against defects in material or workmanship of the Product (hereinafter “Defect” or “Defective”) for a period of one (1) year from the date of first purchase as shown on the original PMC invoice (hereinafter “Warranty Period”). - Page 4 No Rights Implied: Nothing in the sale, lease or rental of any Product by PMC shall be construed to grant any right, interest or license in or under any patent, trademark, copyright, trade secret or other proprietary right or material owned by anyone;...
-
Page 5: Safety And Handling
Keep this Operations Manual for future consultation of useful information at all times. If you lose this manual, ask for a new copy from your PMC Distributor or go online and visit our web site at www.polymac-usa.com. - Page 6 The TSU has been designed and built for the application of polyurea chemical systems, polyurethane foam chemical systems, and some two-component epoxy systems. Always use liquids and solvents that are compatible with the unit. If in doubt, consult your PMC Distributor.
-
Page 7: Characteristics
CHARACTERISTICS Accurate and precise Compact design Easy to install Low maintenance TECHNICAL SPECIFICATIONS RTD Element _____________________________________________ 1000Ω Thin Film IEC Class ____________________________________________________________ B Accuracy _______________________________________________ ±[0.3+0.005 |t|] Temperature Range __________________________________________ -50 to 300 Temperature Coefficient _____________________________________ 0.00385 Ω/Ω/ Inlet Fitting (“A”... -
Page 8: Description
DESCRIPTION A. RTD Connector B. Flexible Metal Conduit C. “A” Side Inlet Fitting D. “A” Side Outlet Fitting E. Sensing Wire F. “R” Side Inlet Fitting G. TSU Body H. “R” Side Outlet Fitting I. Air Inlet Fitting J. Air Outlet Fitting... -
Page 9: Installation
INSTALLATION CAUTION! Connecting the TSU between the first and second section of Heated Hose results in the TSU sensing the material temperature exiting the Heater and not the inside of the Heated Hose near the Spray Gun. CAUTION! To protect the TSU sensor, pay special attention not to kink or excessively bend the Heated Hoses. -
Page 10: Part Identification
PART IDENTIFICATION EL-51A-RTD ITEM PART NUMBER DESCRIPTION EL-00051A-9 TSU BLOCK WITH AIR EL-00051A-4 1/4 X #5 JIC MALE FTG EL-00051A-6 1/4 X #6 JIC MALE FTG EL-00051A-3 1/8 X #4 JIC FEM SWIVEL FTG EL-00051A-7 1/4 X #5 JIC FEMALE SWIVEL FTG... -
Page 11: Manual Revisions
MANUAL REVISIONS Revision Date Changes Approved 01-SEP-2015 Initial release of EL-51A Manual Vadams...
