Summary of Contents for Josef Kihlberg Royal Viking
- Page 1 Royal Viking Installation and Maintenance Manual...
-
Page 2: Table Of Contents
Technical facts What comes with the stove? Royal Viking dimensions and installation 6 About Royal Viking 7 Here's how your Royal Viking works Installation and mounting Replaceable parts Here’s how to replace vermiculite and smoke shelf Maintenance and sweeping How to use the stove correctly... - Page 3 This manual contains instructions on how to install your oven as well as maintenance advice and tips on the best way to light the fire. Don’t hesitate to contact us if you have any further questions about using a fire or about your Royal Viking. Warm regards,...
-
Page 4: Technical Facts
Heating surface (approx. m²) 30-80 The manual contains instructions on how to mount and Weight (kg) install Royal Viking. To ensure the function and safety Size (HxWxD mm) 1,670x560x560 of the stove, we recommend that installation be carried Fireplace dimensions (HxWxD mm) 300x290x320 out by a professional. -
Page 5: What Comes With The Stove
WHAT IS INCLUDED WITH THE STOVE? Make sure all parts are included in the package. 1. Installati on manual 3. Ash pan Guide to installati on and maintenance of your stove. Collects ashes left aft er burning. 2. Glove 4. CE mark Made of fl ameproof material. -
Page 6: Royal Viking Dimensions And Installation
ROYAL VIKING ROYAL VIKING DIMENSIONS AND INSTALLATION Here are the most important dimensions required for proper installation and optimal operation. All measurements are indicated in millimetres. Installation distance Please consider the safety installation distance. The lowest possible ceiling height is 2,200mm for a safe distance. -
Page 7: About Royal Viking
General consumption. The wood is burned when the supply The Royal Viking is made of heavy castings and the of secondary air flows through the holes of the rear fireplace is lined with vermiculite internally. Externally, vermiculite plates and is distributed across the glass. -
Page 8: Here's How Your Royal Viking Works
Convection air Primary air is supplied when the rotary damper is open on In addition to radiating heat, the Royal Viking is also the ash door and the fireplace door is left half-open during equipped with convection technology. This means that the ignition phase. -
Page 9: Installation And Mounting
INSTALLATION AND MOUNTING The stove meets the requirements for connecti on to a A fl ue with narrow bends and horizontal draught reduces chimney designed for 350°C smoke temperature. the draft in the chimney. The maximum horizontal fl ue is 500 mm, provided that the verti cal fl ue length is at least The external diameter of the connectors is 125mm. -
Page 10: Replaceable Parts
REPLACEABLE PARTS The Royal Viking is built to be used for decades to come, but do not forget to replace wear details when needed. Keep an eye on the vermiculite plates, grates and seals and replace them when they become worn. -
Page 11: Smoke Shelf
HERE’S HOW TO REPLACE THE VERMICULITE, SMOKE SHELF AND GRATES Removal of worn components All components are loose. The vermiculite is removed by lift ing up the smoke baffl e. Then lift up the side vermiculite and angle it into the fi replace to lift it out. It doesn't matt er which side is removed fi rst. -
Page 12: Maintenance And Sweeping
First fi re This should be done when the stove is cold. A new Royal Viking should be lit carefully on the fi rst few occasions. This makes the heat-resistant colour more Ash should regularly be removed from the grate. -
Page 13: Problem Solving
FIRE-LIGHTING PROBLEMS AND SOLUTIONS Poor draft • The connection to the chimneystack has not been properly sealed. Ask the chimney sweep to check the connection between the stove and the chimney is completely sealed. • The flue pipe is clogged. Clean the flue pipe and combustion chamber. •... -
Page 14: Warranty Certificate
ROYAL VIKING WARRANTY CERTIFICATE WARRANTY TERMS Josef Davidssons Eftr AB is responsible for ensuring that the products are not defective in way that can be attributed to manufacturing or storage at the factory. The warranty is valid from the date of delivery to the customer. - Page 15 NB1015 Royal Viking DoP Nr. JD_1850_220401 EN 13240:2001/A2:2004 www.josefdavidssons.se/prestandadeklaration SWE / EN / DE PRODUKT / PRODUCT / PRODUKT Produkttyp / Product type / Produkttyp Kamin / Wood burning stove / Holzofen Typbeteckning / Product name / Produkt name Royal Viking Avsedd användning / Intended use / Verwendung...
- Page 16 Jättevägen 1, 333 75 Reftele, Sweden Royal Viking – Maintenance manual - No 1 www.josefdavidssons.se 2022-04-06...
