1218CT Fuel Management System Translator Kit
Installation, Operation, and Maintenance Instructions
The 1218CT Fuel Management System Translator Kit is designed as an add-on to the 1218C Electronic Tank Gauge (also
referred to as the 1218C Console), providing an interface between the 1218C Console and any fuel management system
(FMS) that utilizes TLS protocol. This kit will include all electrical components and housings required to power the 1218CT
Communication Module using the same power source already installed for the 1218C Console. The 1218CT is capable of
receiving commands from any FMS communicating with TLS protocol and responding with live or historic data from the
1218C Console in real time.
Failure to follow any or all of the warnings and instructions in this document could result in a hazardous liquid spill,
!
which could result in property damage, environmental contamination, fire, explosion, serious injury or death.
Contents
Specifications ......................................................................................................................................................... 2
Installation ............................................................................................................................................................. 4
Operation ............................................................................................................................................................... 9
Maintenance ........................................................................................................................................................ 11
Appendix A .......................................................................................................................................................... 12
Morrison Bros. Co. - Dubuque, IA - 800-553-4840
1218CT0112 PP
1
rev 04-14-2022
Advertisement
Summary of Contents for Morrison Bros. co. 1218CT
- Page 1 Installation, Operation, and Maintenance Instructions The 1218CT Fuel Management System Translator Kit is designed as an add-on to the 1218C Electronic Tank Gauge (also referred to as the 1218C Console), providing an interface between the 1218C Console and any fuel management system (FMS) that utilizes TLS protocol.
-
Page 2: Specifications
The 1218CT Fuel Management System Translator Kit contains two modules, the 1218CT Communication Module and the 1218CT Power Converter Module, along with assembly components to be used for installation. Both modules are intended to be installed in an indoor or outdoor non-hazardous location. - Page 3 Maximum wiring distance between the 1218CT Communication Module and the 1218C Console is 1,000 ft. Note: Shielded ethernet cable is required (not supplied) for wiring between the 1218CT and 1218C Console. Maximum wiring distance between the 1218CT Communication Module and the FMS is 50 ft.
-
Page 4: Installation
This module should be installed in one of the 1/2-inch conduit openings, shown in Figure 2. IMPORTANT NOTE: Only the 1218CT power and communications conductors are to be routed through the module. Use a junction tee above the module to divert all other conductors (i.e., AC... - Page 5 Wiring Steps Note: For steps 1-12 please refer to the Power Converter Module wiring diagram shown in Figure 3. 1. On the 1218C Console’s interface board, locate the board’s input power connecter and disconnect the mains line/hot wire (black) from the left-most position of the connector. 2.
- Page 6 16. Lead the stripped end of the ethernet cable through the opening in the bottom of the 1218CT Power Converter Module, continue leading only the blue and green twisted pairs through the bottom of the 1218C console, while...
- Page 7 Communication Module Mounting 1. Mount the enclosure to a stable vertical surface in a non-hazardous location using the mounting flanges of the enclosure. Do not make additional holes in the enclosure. 2. Morrison has provided two openings on the sides of the NEMA 4X enclosure for connection and wiring. To ensure the enclosure maintains its NEMA 4X rating, only use Thomas &...
- Page 8 Description J2 Pin Assignments Figure 10: 1218CT Communication Module Board Postion Description Color 6. Once the ethernet wire is routed through the conduit leading to the Communication Module, carefully strip this Ground Data + (A) Green end of the et hernet cable approximately 4 inches, ensuring none of the twisted pair conductors are damaged in this Data ‐ (B)
- Page 9 1218 Console No configuration of the 1218C Console is required. Note: The 1218CT cannot be used with MODBUS or remote console devices. Fuel Management System The fuel management system communication requires no configuration set up from the Communication Module. For further configuration and setup instructions please refer to the fuel management system manual.
-
Page 10: Operation
• In the event of malfunction, remove from service immediately and contact Morrison Bros. Customer Service. The 1218CT allows a Fuel Management System to query the 1218C Electronic Tank Gauge for current inventory. Inventory changes are not reported to the FMS in real-time and must never be relied upon to prevent a tank overfill. -
Page 11: Maintenance
Maintenance WARNINGS • Any modification of this unit beyond what is outlined in this instruction will void product warranty. • For your safety, it is important to follow local, state, federal and/or OSHA rules that apply to working inside, above, or around the storage tank and piping area. - Page 12 Note: The 1218CT Communication Module will keep this log stored in its own internal memory created from data sent over from the 1218C, storing up to 100 alarm reports. When these reports are pulled by the FMS, the 1218CT Communi- cation Module will automatically clear the log of alarm reports.
