Seacam Seaflash 160 Digital Update Manual

Update Guide
Seaflash 160 Digital
und 160 Offshore
You can easily update your new flash unit yourself at home. Please read the following technical
Information and safety instructions carefully in advance. Incorrect installation can cause seri-
ous damage and malfunction of the flash unit.
The SEAFLASH 160digital allows for a quick upgrade via the included S6/Micro USB adapter
and an active computer connection. You can see the current software version (e.g. v.01) on the
bottom right of the display when you switch off the device.
Visit our website www.seacam.com to find out whether new firmware is available and whether
your device needs to be upgraded.

STEP BY STEP GUIDE

Download the appropriate firmware from the SEACAM server at www.seacam.com and save
the file.
SF160vxx.bin (correct file name) xx stands for the software version.
Do not modify or open the file with any other software or program. Changes to the file lead to
an incorrect hash check of the software and a successful update cannot be performed.
1. Go to the SET menu, select Firmware Upgrade, set YES with the main knob (2) and
confirm with the push button (3).
Firmware upgrade – YES
2. The flash unit will now ask for a USB connection. Now connect a USB cable to your
computer and connect it using the supplied S6 / USB adapter with the flash unit.
Firmware
upgrade
Connect USB cable.
