OPERATOR'S MANUAL
AWS Airbar Systems
(Header Mount Fan)
Version: 20200325

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIRBAR and is the answer not in the manual?

Questions and answers

Summary of Contents for AWS AIRBAR

  • Page 1 OPERATOR’S MANUAL AWS Airbar Systems (Header Mount Fan) Version: 20200325...
  • Page 3: Table Of Contents

    AWS AirBar Operator’s Manual INTRODUCTION ................... 1 FOREWORD........................... 1 ITEMS INCLUDED WITH AIRBAR KITS ..................1 SERIAL NUMBER LOCATION ....................1 REPLACEMENT PARTS INFORMATION ..................1 UNAUTHORIZED MODIFICAITON ................... 2 MISUSE OF EQUIPMENT ......................2 PRODUCT DESIGN ......................... 2 OFFICIAL LANGUAGE ......................2 COMPONENT IDENTIFICATION..............
  • Page 5: Introduction

    Before you head to the field, study this manual carefully. Replace this manual immediately if it becomes lost. AWS AirBar systems are an air-assist tool to increase the productivity and efficiency of your auger or draper style combine header. This system is customized to fit your head / combine combination.
  • Page 6: Unauthorized Modificaiton

    If any person, employee, agent, dealer or distributor becomes aware of any Unauthorized Modification or Misuse of an AWS AirBar system, either past or intended, it is the responsibility of that person to ensure that TEMP Farm Equipment is notified of the occurrence promptly.
  • Page 7: Component Identification

    AWS AirBar Operator’s Manual COMPONENT IDENTIFICATION MOUNT ARM BRACKET BLOWER ASSEMBLY MANIFOLD END CAP NOZZLES MANIFOLD LOCK SLEEVE TILT ACTUATOR TRANSITION MOUNT ARM TUBE BRACKET MANIFOLD ROTARY TILT CONTROL SCREEN THROTTLE THROTTLE CONTROL /W ACTUATOR Figure 3 – Manifold Tilt Mechanism – 1 pc Reel...
  • Page 8: Safety

    AWS AirBar Operator’s Manual SAFETY SAFETY ALERT SYMBOL This symbol appears at various points in the manual together with a signal word and warning text. It means – Be alert! Your safety is involved. This symbol is used throughout the manual to...
  • Page 9: Power Unit Safety

    AWS AirBar Operator’s Manual • Never operate a system while under the influence of drugs or alcohol. These make reflexes slow and put you and others in grave danger. Always make sure you have full concentration while harvesting. • Adhere strictly to all regulations at the worksite pertaining to the operation of this equipment.
  • Page 10: Safety Decals

    AWS AirBar Operator’s Manual object. Inspect system and repair any damage before continuing. • If the equipment should start to vibrate abnormally during operation, stop the system, shut down power unit, and immediately check for the cause. Excess vibration is generally an indication of a problem.
  • Page 11: System Setup For Operation

    Secure shield safety chain to feeder house. ELECTRICAL CONNECTIONS There is a single connection to be made between the combine and AirBar system. Locate the 4-pin connector on the header harness and connect to mating connector on feeder house. WHEN DISCONNECTING THE HEADER DISCONNECTING THE PTO Disconnect telescoping PTO shaft from the feeder house shaft.
  • Page 12: Operating The System

    In most cases, shatter loss can be reduced further with the ability to set the finger reel higher than if an AirBar system is not used. When entering the crop, begin with the reel the “normal” height and begin to raise the reel until you see a decrease in performance.
  • Page 13: Nozzle Rotation Adjustment

    AWS AirBar Operator’s Manual NOZZLE ROTATION ADJUSTMENT The most important adjustment affecting the performance of your AirBar system is the position of the nozzles. The nozzles should be aimed so that the air blast contacts the head 2” – 5” behind the knife.
  • Page 14: Air Flow Adjustment

    AWS AirBar Operator’s Manual AIR FLOW ADJUSTMENT The AWS AirBar system is designed to be capable of providing excess air flow in most applications. The electric throttle control is provided to allow for optimization of the air flow regardless of harvest conditions.
  • Page 15: Lubrication

    Specification: NLGI GL-2 Grease Type: Mineral Oil, Lithium Soap Thickener Grease of this type is considered “general purpose”. It can be used on all components of the AirBar system. Notes: 1. Do not use “high-temperature” greases. Normal operating conditions of this system will not exceed the recommended temperature range of conventional grease.
  • Page 16: Nozzle Inspection

    AWS AirBar Operator’s Manual PTO SHAFT Location A – 4-6 Pumps (15 grams) Location B – 2-3 Pumps (6 grams) Location C* – 4-6 Pumps (15 grams) *Note – Pull PTO shaft apart & apply grease to inner profile. BEARINGS The (4) shaft bearings are the only grease points on the main chassis, (2) on each side.
  • Page 17: Belt / Sheave / Idler Condition

    Replace as required. BELT TENSION Proper belt tension is critical to both optimum performance and long life of your AirBar system. Loose belts will create excessive heat and ultimately fail. Belts that are too tight can lead to accelerated bearing failure.
  • Page 18: Bearing Service

    • Loosen the setscrew, then tap the collar in the direction opposite the shaft rotation. BELT SERVICE From 2021, all AWS AirBar systems are delivered with the new ServiceMaster chassis. This chassis design allows for primary belt change-out in up to 70% less time than the previous designs.
  • Page 19: Blower Inspection

    AWS AirBar Operator’s Manual BLOWER INSPECTION Remove rotary screen & inspect all impeller blades. Replace impeller if any of the fins are loose or if wear has reduced the width of the fin. Clean housing and impeller removing all debris.
  • Page 20: Fastener Torque

    AWS AirBar Operator’s Manual FASTENER TORQUE The chart below lists the proper installation torque for fasteners on AirBar systems. When bolts are to be tightened or replaced, refer to this chart to determine the proper torque (unless otherwise specified in this manual).
