Summary of Contents for AdirPro MC-10
- Page 1 MC-10 Machine Control DETECTOR ADIPR200-01 QUICK START GUIDE...
- Page 2 Thank you for your purchase. AdirPro is known for its quality products in the construction industry, all manufactured to the highest standards. We strive to help you complete your project in the most reliable, safe, and cost-effective manner. We deliver everything with accuracy you...
-
Page 3: Table Of Contents
Table of Contents Parts and Features Operating Instructions Technical Data Limited Warranty Disclaimer... -
Page 4: Parts And Features
Parts and Features Parts: A. Machine Control Receiver MC-10 B. Built-in rechargeable battery charger C. 12/24V Battery Cable, hard case D. Cabin Receiver with connection cable Features: • 360º Reception • Length of receiving windows 25cm • Strong clamps for connection to the machine •... - Page 5 Parts and Features...
-
Page 6: Operating Instructions
Operation Instructions Connection to the Excavator-Main Receiver: • Is Equipped with strong clamps for attachment. Switch ON: • After turning on, the Main Receiver is in coarse detecting mode. • P detecting mode. Fine/Coarse Detection: • While the Main Receiver is on, press the ON/OFF switch. The modes can be changed with the ON/OFF Switch. - Page 7 12/24V Battery Cable: • Connect the Battery Cable with socket Number 8 (or if the MC-10 is connected to Cabin Receiver with socket Number 13). • Then fix clamps on the car battery: - RED to the positive pole (+) at the battery.
-
Page 8: Technical Data
Technical Data Accuracy Fine ±2mm - ±10mm Accuracy Coarse ±5mm - ±23mm Rechargeable Batteries/ 7.2VniMh/3000mAh Charger Operating Time Charging Time Operating Temperature -20ºC - +50ºC -20ºC - +30ºC Recommended Storage Temperature Size 376×180×49mm Weight 3.1 kg... -
Page 9: Limited Warranty
Limited Warranty 1. Adir Pro (the company) warrants to the purchaser that the product will be free from defects in workmanship and materials for a period of one (1) year from the date of purchase. 2. These warranties are not assignable or transferable to any other person. - Page 10 Limited Warranty 9. We recommend that the product being returned is accompanied by the sales receipt with all relevant information regarding the purchase of the item and is returned to the Company within ten (10) days of the claim date of purchase to validate this warranty. 10.
-
