Guide Gear 712140 Instructions For Assembly And Use

Aluminum carrier

Advertisement

Quick Links

Guide Gear
Congratulations on your
purchase.
Guide Gear
Take your game to the next level with field-tested
products for a confident,
competitive edge that strikes the perfect balance between performance and value.
INSTRUCTIONS FOR ASSEMBLY AND USE OF
Guide Gear
ITEM# 712140 -
ALUMINUM CARRIER
For assistance with your Guide Gear product, please contact the Sportsman's Guide customer service
at 1-800-888-5222 7:30am – 6:00pm CST Mon-Fri or go to
http://www.sportsmansguide.com/customerservice/contactus
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 712140 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Guide Gear 712140

  • Page 1 INSTRUCTIONS FOR ASSEMBLY AND USE OF Guide Gear ITEM# 712140 - ALUMINUM CARRIER For assistance with your Guide Gear product, please contact the Sportsman’s Guide customer service at 1-800-888-5222 7:30am – 6:00pm CST Mon-Fri or go to http://www.sportsmansguide.com/customerservice/contactus...
  • Page 2 WARNING Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. INTENDED USE This cargo carrier fits in a 2in. receiver and can carry up to a 500-lb. load. It is ideal for use as a mobility carrier, a transporter for lawn equipment or to provide additional cargo space.
  • Page 3 sure the load is centered on the carrier. • Use the aluminum cargo carrier on flat and level surfaces capable of supporting the aluminum cargo carrier and its maximum load. Pulling or pushing a load on a slanted or uneven surface can result in loss of control. •...
  • Page 4 STEP 2 2. Place the bottom bracket (1#) on the bottom of the carrier frame (5#) and position the square hole. The M10*45mm ring screw (4#) is then passed through the bottom bracket (1#) and the carrier frame (5#) and the U clamp (2#). The M10 lock nut (3#) is finally tightened.
  • Page 5 STEP 4 4. The Z type rotating mechanism (10#) is set on the bottom bracket (1#) square tube, the position of the two circular holes is aligned, and then the M16 x 80mm hexagon bolt (11#) passes through the Z rotary mechanism (10#) and the bottom bracket (1#) near the carrier rack's round hole, and then uses the M16 lock nut (12#) to tighten.
  • Page 6 STEP 6 Folding steps. See FIG 6. FIG. 6...
  • Page 7 Diagram & Parts List ITEM # Description the bottom bracket U clamp M10 lock nut M10×45mm ring screw Carrier frame The spoon shaped fixed plate M10×25mm button socket cap screw M10×20mm ring screw 10 flat washer Z type rotating mechanism M16×85mm hexagon bolt M16 lock nut 3.8 split pin...
