- Page 1 INSTRUCTION BOOK FOR ROOTS BLOWER R TYPE FU-TSU MACHINERY CO., LTD. Address:No.5,Lane 345,Nanshang Road, Guishan Dist.,Taoyuan City 333,Taiwan TEL: +886-3-3527766 FAX: +886-3-3226176 Http: www.fu-tsu.com.tw E-mail: futsu.blower@msa.hinet.net...
- Page 2 PREFACE The operation manual provides explanations of the structure, action and andling of TAIKO ROTARY BLOWER in order that the blower will satisfy the blower will satisfy the user by functioning without trouble for long owing to the latest technic which gives birth to this machine. Naturally, the performance and life, as well as causes of troubles, depe and on the design, materials and the manufacturing technic themselves, while the importance of daily handling and maintenance...
-
Page 3: Table Of Contents
CONTENTS Chapter 1 Structure and function of parts 1-1 General 1-2 Structure 1-2-1 Impeller 1-2-2 Pilot gear 1-2-3 Bearings 1-2-4 Shaft sealing unit 1-2-5 Oil level gauge and Chapter 2 Installation; Piping 2-1 Location 2-2 Foundation work 2-3 Installation 2-4 Piping work 2-4-1 Main piping 2-4-2 Piping for cooling water 2-5 Fitting V-belt... -
Page 4: Chapter 1 Structure And Function Of Parts
Chapter 1. Structure and function of parts 1-1 General This blower forces inhaled gas by two impellers, which are of cycloidal profile and rotate smoothly in a casing providing predeter- mined clearance therebetween. Mechanism of the blower is arrang- ed n such a way as inhaled gas to be forced is pressurized against the pressure of the gas at the discharging outlet when the inhaled gas reaches the discharging outlet, and the structure is such that oil cannot be mixed to the gas to be discharged. -
Page 5: Bearings
adjusting an adjustable gear. The adjustable gear should not be separated from a gear inner at the time of disassembling the blower with the aim other than adjustment of the gears. Usually, a solid gear is fixed to the drive shaft. 1-2-3 Bearings In compact models, solid ball bearings and roller bearings are used. -
Page 6: Chapter 2 Installation; Piping
Chapter 2. Installation; Piping 2-1 Location (1) The blower should be installed in a building and where is well ighted and gas little dust. When it has to be installed outdoors, enough care should be paid to the motor, V-belt etc. (2) Enough space should be provided around the blower for easy and sure disassembling and re-assembling and satisfactory daily inspection. -
Page 7: Piping Work
(3) Insert the foundation bolts into the predetermined places in the bed and let the bolts hang in the holes for the bolts, with the nut sscrewed at the top of the bolts. Insert metal edges suitably to sup port the bed correctly, as the bed may be distorted. (4) The bed must be set in a horizontal plane and the maximum allo wance is about 0.5mm per lm for the machined surface of the blo- wer. -
Page 8: Fitting V-Belt
2-5 Fitting V-belt (1) The best condition of V-belt is such that the V-belt is fitted as loo- se as possible without causing slip of the belt. As the belt stretch- es much at the early stage of operation,inspect the V-belt as often as possible. -
Page 9: Centering Of Coupling
To obtain the proper tension of the belt, adjust it so that its de dlection=0.016X 1(mm) is between the maximum and the minim- um of the lowd values mentioned in following table when it is per- pendicularly loaded at the middle of span(distance between the contract points of the belt and the pulleys). -
Page 10: Chapter 3 Operation
If a dial gauge is not available, use a key for centering. Good Chapter 3 Operation 3-1 Preparation before operation (1) Remove dust and powder of cement inside and around the blower not to be mixed into oil. (2) Check if the joints of the inhaling and discharging piping are all closed. -
Page 11: Trial Run
(4) Pour lubrication oil up to the upper red line of the oil level gauge. If the oil is not enough, it causes seizure, and, if the oil is too much , the temperature rises thereby causing damage to the gears and other parts. -
Page 12: Cautions For Operating
(5) Watch the indication of and ampere meter during the operation carefully, and, if any disorder is observed, stop the blower instantly , and investigate cause of the trouble. Most common cause is the impeller and the side cover. Those blowers assembled in the ma- nufacturer’s factory are already operated with the object of a dap- tation, but, pay enough attention , if the blower is disassembled and, then, reassembled at the plae of installation. -
Page 13: Chapter 4 Maintenance
Chapter 4 Maintenance 4-1 Maintenance in general (1) Temperature of the casing usually rises substantially during oper- ation in proportion to the ratio of compression due to the heat gen- erated by compression, but, if the temperature rises partially and thepaint on the outer surface is burned, it is due to generation of heat caused b contact between the impeller and the casing or the inhaled foreign substance, In this case, stop operation and inves-... -
Page 14: Disassembling
(2) Checking temperature of the bearing case. The temperature can be checked by a suitable thermometer, but the surface thermometer can be used conveniently for this pur- pose. (3) Checking inhaling and discharging pressure. Normal operation of the blower can be confirmed by checking The inhaling and discharging pressure. - Page 15 (3) Measure the thickness of all packings instantly after disassem- bling. (4) Keep all the disassembled parts from dust. Especially, pay much attention to the bearings. (B) Order of disassembling (1) Remove all the attachments from the blower unit. (2) Draw out the oil from the gear case. Check if the oil contains foreign substances.
-
Page 16: Reassembling
(7) Removing the bearing sleeves and the bearing inner races. Though the bearing sleeves and bearing inner races are fitted Tight to the shaft, do not apply much force, as they can be Removed by heating slightly (under 100 4-4 Reassembling 4-4-1 Cautions for reassembling (1) Check if there is any part damaged during disassembling pro- cess. -
Page 17: Assembling Order 16~17
4-4-3 Assembling order (1) Fix the side cover in the driving side to the casing. (2) Insert the impellers into the casing from the gear side. (3) Mount the bearings together with the bearing case. Confirm the counter marks put when disassembling. Do not forget to put a packing on the back of the bearing case. -
Page 19: Chapter 5 Causes Of And Remedy For Troubles
Chapter 5 Causes of and remedy for troubles Trouble & Symptom Cause Remedy Stuffed filter Replace or clean the filter Increased Check and adjust clearance the clearance Increased loss of Check the difference Insufficient Pressure in the of pressures between blowing piping inlet and outled...
