  • Page 1 G Patch 6222 Manual (Original documentation)
  • Page 2 © Copyright 2021 GÖPEL electronic GmbH. All rights reserved. The software described in this manual as well as the manual itself are supplied under license and may be used or copied only in accordance with the terms of the license. The customer may make one copy of the software for safety purposes.
  • Page 3 Table 1: List of changes to this document Date Editor Comment 2021-04-07 E. Richter 2.0.0 Document created in LaTex 2021-04-30 E. Richter 2.0.1 Variants 6 - 10 added 2022-02-21 E. Richter 2.0.2 Scope of delivery of the connection cable changed to optional...

  • Page 4: Table Of Contents

    Contents 1 Introduction Notes on this document ......... . Intended Use .

  • Page 5: Introduction

    Information that indicates certain aspects or is important for a particular topic or goal. Tip that gives useful hints or recommendations. 1.2 Intended Use G Patch 6222 is a breakout box for easier contacting of a Video Dragon 6222 with your test object. Typical applica- tions are (depending on the variant):. •...

  • Page 6: Emc Protection Measures

    1.5 Liability and Warranty Exclusion The G Patch 6222 box has not been developed, tested or intended for use in safety-related applications. Do not use the device for safety-related systems or vehicle subsystems. The use of such a device within motor vehicles to control the main vehicle functions can be dangerous and lead to malfunction of motor vehicles.

  • Page 7: Supplied Accessories

    (including but not limited to the purchase of replacement goods or services, loss of use, loss of data or profit, breakdowns, injury, or potential death) in any way in the case of improper use of the G Patch 6222.

  • Page 8: Technical Description

    Depending on which Media Interface is used in your Video Dragon 6222 and whether the DUT has Coax or STP con- nectors, there is a corresponding G Patch 6222 box variant. The variant to be used depends on whether Coax or STP is used/required and how many inputs and outputs the Media Interface offers.

  • Page 9: Coax Variant 1

    2.2.2 Coax Variant 1 The G Patch 6222 Coax variant 1 has 3 channels and is connected to the Video Dragon 6222 via HFM (MiniFakra) cable. Each channel has a PowerOverCoax (PoC) filter which works from 3MHz to 3GHz. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 10 GÖPEL electronic GmbH Table 2.3: Connector configuration Coax variant 1 - Video Dragon 6222 side IN 1/2 DUT PWR- DUT PWR+ AMS22B-40MZ5-Z AMS22A-40MZ5-Z Laboratory socket 4mm Table 2.4: Connector configuration Coax variant 1 - DUT side AMS22A-40MZ5-Z G Patch 6222...

  • Page 11: Coax Variant 2

    2.2.3 Coax Variant 2 The G Patch 6222 Coax variant 2 has 4 channels and is connected to the Video Dragon 6222 via HFM (MiniFakra) cable. Each channel has a PowerOverCoax (PoC) filter which works from 3MHz to 3GHz. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 12 Table 2.6: Connector configuration Coax variant 2 - Video Dragon 6222 side OUT 1/2 OUT 3/4 DUT PWR- DUT PWR+ AMS22B-40MZ5-Z Laboratory socket 4mm Table 2.7: Connector configuration Coax variant 2 - DUT side OUT 4 OUT 3 OUT 2 OUT 1 AMS22A-40MZ5-Z G Patch 6222...

  • Page 13: Coax Variante 2.1

    2.2.4 Coax Variante 2.1 The G Patch 6222 Coax variant 2.1 has 4 channels and is connected to the Video Dragon 6222 via HFM (MiniFakra) cable. Each channel has a PowerOverCoax (PoC) filter which works from 3MHz to 3GHz. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 14 Table 2.9: Connector configuration Coax variant 2.1 - Video Dragon 6222 side IN 1/2 IN 3/4 DUT PWR- DUT PWR+ AMS22B-40MZ5-Z Laboratory socket 4mm Table 2.10: Connector configuration Coax variant 2.1 - DUT side IN 4 IN 3 IN 2 IN 1 AMS22A-40MZ5-Z G Patch 6222...

  • Page 15: Stp Variant 1

    2.2.5 STP Variant 1 The G Patch 6222 STP variant 1 is connected to the Video Dragon 6222 via an EPLSP cable (Eye Speed) from Samtec. This variant has 1 input and 1 output channel with 2 lanes each. It also has an Ethernet RJ45 connector for cou- pling and uncoupling MII/Ethernet up to 1GBit/s.
  • Page 16 Pin2 = Channel 1p Pin2 = Channel 0p Pin3 = Channel 0p Pin3 = Channel 1p Pin4 = Channel 1n Pin4 = Channel 0n Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin6 = DUT PWR- Pin6 = DUT PWR- G Patch 6222...

  • Page 17: Stp Variant 2

    2.2.6 STP Variant 2 The G Patch 6222 STP variant 2 is connected to the Video Dragon 6222 via an EPLSP cable (Eye Speed) from Samtec. This variant has 2 input channels with 2 lanes each. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 18 Pin2 = Channel 0p Pin2 = Channel 0p Pin3 = Channel 1n Pin3 = Channel 1n Pin4 = Channel 0n Pin4 = Channel 0n Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin6 = DUT PWR- Pin6 = DUT PWR- G Patch 6222...

  • Page 19: Stp Variant 3

    2.2.7 STP Variant 3 The G Patch 6222 STP variant 3 is connected to the Video Dragon 6222 via an EPLSP cable (Eye Speed) from Samtec. This variant has 2 input and 1 output channel with one lane each. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 20 Pin3 = DUT PWR+ Pin4 = DUT PWR- Pin4 = Channel 1n Pin4 = Channel 0n Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin6 = DUT PWR- Pin6 = DUT PWR- Pin6 = DUT PWR- G Patch 6222...

  • Page 21: Stp Variant 4

    2.2.8 STP Variant 4 The G Patch 6222 STP variant 4 is connected to the Video Dragon 6222 via an EPLSP cable (Eye Speed) from Samtec. This variant has 1 input and 1 output channel with 2 lanes each. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 22 Pin2 = Channel 1p Pin2 = Channel 0p Pin3 = Channel 0p Pin3 = Channel 1p Pin4 = Channel 1n Pin4 = Channel 0n Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin6 = DUT PWR- Pin6 = DUT PWR- G Patch 6222...

  • Page 23: Stp Variant 5

    2.2.9 STP Variant 5 The G Patch 6222 STP variant 5 is connected to the Video Dragon 6222 via an EPLSP cable (Eye Speed) from Samtec. This variant has 1 input and 1 output channel with 2 lanes each. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 24 Pin2 = Channel 1n Pin2 = Channel 0p Pin3 = Channel 0p Pin3 = Channel 1n Pin4 = Channel 1p Pin4 = Channel 0n Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin6 = DUT PWR- Pin6 = DUT PWR- G Patch 6222...

  • Page 25: Stp Variant 6

    2.2.10 STP Variant 6 The G Patch 6222 STP variant 6 is connected to the Video Dragon 6222 via an EPLSP cable (Eye Speed) from Samtec. This variant has 1 input and 1 output channel with one lane each. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 26 Pin2 = Channel 0n Pin2 = Channel 0n Pin3 = DUT PWR+ Pin3 = DUT PWR+ Pin4 = Channel 0p Pin4 = Channel 0p Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin6 = DUT PWR- Pin6 = DUT PWR- G Patch 6222...

  • Page 27: Stp Variant 6.1

    2.2.11 STP Variant 6.1 The G Patch 6222 STP variant 6.1 is connected to the Video Dragon 6222 via an EPLSP cable (Eye Speed) from Samtec. This variant has 1 input channel with one lane. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 28 Laboratory socket 4mm ERI8-019-S-D-RA Table 2.31: Connector configuration STP variant 6.1 - DUT side 99S20D-40MA5-Z Pin1 = DUT PWR- Pin2 = Channel 0n Pin3 = DUT PWR+ Pin4 = Channel 0p Pin5 = DUT PWR+ Pin6 = DUT PWR- G Patch 6222...

  • Page 29: Stp Variant 7

    2.2.12 STP Variant 7 The G Patch 6222 STP variant 7 is connected to the Video Dragon 6222 via an EPLSP cable (Eye Speed) from Samtec. This variant has 2 input and 1 output channel with one lane each. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 30 Pin3 = Channel 0n Pin4 = Channel 0p Pin4 = n.c. Pin4 = n.c. Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin6 = DUT PWR- Pin6 = DUT PWR- Pin6 = DUT PWR- G Patch 6222...

  • Page 31: Stp Variant 7.1

    2.2.13 STP Variant 7.1 The G Patch 6222 STP variant 7.1 is connected to the Video Dragon 6222 via an EPLSP cable (Eye Speed) from Samtec. This variant has 2 input and 1 output channel with one lane each. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 32 Pin3 = Channel 0n Pin4 = Channel 0p Pin4 = DUT PWR+ Pin4 = DUT PWR+ Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin6 = DUT PWR- Pin6 = DUT PWR- Pin6 = DUT PWR- G Patch 6222...

  • Page 33: Stp Variant 8

    2.2.14 STP Variant 8 The G Patch 6222 STP variant 8 is connected to the Video Dragon 6222 via an EPLSP cable (Eye Speed) from Samtec. This variant has 2 input and 2 output channels with one lane each. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 34 Pin4 = Channel 2n Pin4 = Channel 0n Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin6 = DUT PWR- Pin6 = DUT PWR- Pin6 = DUT PWR- Pin6 = DUT PWR- G Patch 6222...

  • Page 35: Stp Variant 9

    GÖPEL electronic GmbH 2.2.15 STP Variant 9 The G Patch 6222 STP variant 9 is connected to the Video Dragon 6222 via an EPLSP cable (Eye Speed) from Samtec. This variant has 2 input and 2 output channels with one lane each.
  • Page 36 IN 2 IN 1 E6S201-40MT5-Y Pin1 = Channel 3p Pin1 = Channel 2p Pin1 = Channel 1p Pin1 = Channel 0p Pin2 = Channel 3n Pin2 = Channel 2n Pin2 = Channel 1n Pin2 = Channel 0n G Patch 6222...

  • Page 37: Stp Variant 10

    2.2.16 STP Variant 10 The G Patch 6222 STP variant 10 is connected to the Video Dragon 6222 via an EPLSP cable (Eye Speed) from Samtec. This variant has 2 input and 1 output channel with one lane each. The power supply of the DUT can be established via two 4mm laboratory cables.
  • Page 38 Pin3 = n.c. Pin4 = DUT PWR+ Pin4 = Channel 1p Pin4 = Channel 0p Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin5 = DUT PWR+ Pin6 = DUT PWR- Pin6 = DUT PWR- Pin6 = DUT PWR- G Patch 6222...

  • Page 39: Service And Support

    If the warranty has expired, we will of course also repair your test system in accordance with our general installation and service conditions. If necessary, please contact our support service: GÖPEL electronic GmbH ATS-Support Göschwitzer Str. 58 / 60 D-07745 Jena Tel.: +49-3641-6896-597 E-Mail: ats.support@goepel.com http://www.goepel.com G Patch 6222...

  • Page 40: Disposal

    At the end of the service life of disposable batteries / rechargeable batteries, these must not be disposed of with the normal household waste. Dispose of the disposable batteries / rechargeable batteries at a recycling center for disposable batteries and rechargeable batteries. Please dispose of only discharged disposable batteries / rechargeable batteries. G Patch 6222...
  • Page 41 Safety, STP Variant 1, STP Variant 10, STP Variant 2, STP Variant 3, STP Variant 4, STP Variant 5, STP Variant 6, STP Variant 6.1, STP Variant 7, STP Variant 7.1, STP Variant 8, STP Variant 9, G Patch 6222...
