Summary of Contents for Aegis 4KPROIP-CBS
- Page 1 Quick Start Guide 4KPROIP-CBS All Rights Reserved Version: 4KPROIP-CBS_2019V.12.V1Q...
- Page 2 4KPROIP-CBS Quick Start Guide Table of Contents 1 Network Switch Configuration ............. 2 2 System Installation ..............2 3 Controller Discovery ..............2 4 Entering Licence Key ..............2 5 System Login ................2 6 Controller Configuration .............. 2 7 System Configuration ..............2...
- Page 3 4KPROIP-CBS Quick Start Guide 1 Network Switch Configuration Ensure the network switch is configured correctly before connecting any Encoders or Decoders to it. Netgear M4300 series are pre-configured for Multicast right out of the box, so no configuration is required to correctly operate the system.
- Page 4 4KPROIP-CBS Quick Start Guide 3 Controller Discovery Step 3: Once everything is connected to the configured switch, using the PC browse to the SDVoE Director Controller via its IP address. If no DHCP server is available you can access the SDVoE Director Controller on default 169.254.1.1, or a 3...
- Page 5 4KPROIP-CBS Quick Start Guide 5 System Login Step 5: Once a valid licence key has been entered, a prompt to enter a Username and Password will appear which by default are Username: admin Password: admin. As soon as you login with these details you will be prompted to enter a new password. Enter anything...
- Page 6 4KPROIP-CBS Quick Start Guide 6 Controller Configuration Step 6: Once logged in, the system will require setting the IP address of the SDVoE Director Controller. Select Settings Next select Network Settings from the drop down list. Now the SDVoE Director Controller IP address can be set as required. Either select the DHCP checkbox or manually enter the IP Address along with Subnet and Gateway.
- Page 7 4KPROIP-CBS Quick Start Guide 7 System Configuration Step 7: Now configure the system as a whole including further SDVoE Director Controller configurations and configuring the Encoders and Decoders. Refer to the aegis_4KPROIP-CBS_User_Manual for further details.
