- Page 1 JPL Agora User Guide 4K Ultra HD All-In-One Video Sound Bar with Intelligent Zoom...
- Page 2 If you want that we handle the disposal for you, • Do not open the camera housing as doing so you can send the device at your costs to will void the warranty. JPL Telecom Limited. • Never guess or take chances with electrical equipment. General Limitation of Liability The device is not designed, manufactured, or intended for use or resale, in environments that require fail- safe performance, such as in the operation of life-support systems and/or nuclear facilities.
-
Page 3: Table Of Contents
Camera Settings - Remote Control - Button Combination ............12 Re-pairing Settings - Remote Control - Button Combination ..........12 Camera Status Indicator ........................13 Mode Status Indicator ........................13 Trouble Shooting ..........................14 Conditions of Warranty ........................15 JPL Agora... -
Page 4: What's Included
What’s Included Thank you for choosing the JPL Agora Bluetooth Conference Room Video Sound Bar. 4K Video Sound Bar Bluetooth Remote Control - Requires 2 x AAA batteries (Batteries not included) 75.00 Magnetic USB-A to USB-A or USB-C Privacy Cover... -
Page 5: Video Sound Bar - Overview
Video Sound Bar - Overview 4 Microphones Lens Tilt up/down Camera Status Mode Status Indicator 4K glass lens Indicator Fully adjustable mount Speaker Speaker DC-12V LINE USB 2.0 LINE OUT DC 12V LINE IN JPL Agora... -
Page 6: Setting Up Your Video Sound Bar
Setting up your conference room video sound bar 1. Placing your camera - Designed with a fully adjustable mount, the JPL Agora can be placed above a computer monitor, positioned on a desktop, or mounted on a wall or ceiling. -
Page 7: Video Enhancement
External Bluetooth Device Connection If your PC does not support Bluetooth, then you can use the Bluetooth in the JPL Agora to connect an additional Bluetooth device, such as a speakerphone. Once paired to the PC, you can select to use the speakerphone as your preferred audio device. -
Page 8: Technical Information
Sensitivity -26dB Fs Far-field voice pick-up 0-10 metres Horizontal voice pickup Horizontal 180° Communication mode Full duplex Speaker parameters: Speaker Specification 2 x ø40mm x H 28mm Power 3W each Impedance 4Ω Frequency Range 20Hz~20KHz Distortion 5% Max JPL Agora... -
Page 9: Technical Information
DC 12V < 2000mA OS Support Win 2000/XP/Vista/Win 7/ Win 8/Win 10, Win CE with UVC, Linux with UVC (above Linux - 2.6.26) Mac OS X 10.4.8 or later, Android 4.0 with UVC Size L352 x W75 x H80mm Weight 960g JPL Agora... -
Page 10: Bluetooth Remote Control
1. Camera On/Off 2. Mute microphone 13. OK button 3. Direction button 4. Microphone 11. Page up 12. Page down 5. AI zoom & Menu 6. Volume up 8. Increase zoom 7. Volume down 9. Decrease zoom 10. Air Mouse JPL Agora... -
Page 11: Bluetooth Remote Control
For scrolling to next page when viewing multi-page documents 12. Page down [ ] For scrolling to previous page when viewing multi-page documents 13. OK button [ OK ] Long press (5s) [ OK ] button to confirm or reset to standard settings JPL Agora... -
Page 12: Camera Settings - Remote Control - Button Combination
Function Operation Long press (3s), (13) [ OK ] and (11) Page up [ ] together Clear Bluetooth settings Long press (3s), (7) Volume down [ –] and (9) Decrease zoom [ -] Enter Pair Bluetooth mode together JPL Agora... -
Page 13: Camera Status Indicator
] on the remote control to enter into setting mode, press (13) [ OK ] and the flashing light will disappear Purple light flashes 3 times Long press (13) [ OK ] for 3s to 5s to enter RESET JPL Agora... -
Page 14: Trouble Shooting
Press OK button [ OK ] for 3-5s to enter RESET. 4) Microphone is not active a) Check to see if the JPL Agora is set as the default camera in the microphone settings on your PC. b) Check if the microphone has been muted by the remote controller. -
Page 15: Conditions Of Warranty
Manufacturer’s Warranty, the legal warranty for defects only applies to the device’s state when sold. 4. You can only claim against this warranty if you return the faulty device to JPL Telecom Limited or our local general importer or distributor, outside England, at your own cost, with a valid proof of purchase (invoice or till receipt). - Page 16 REGISTERED ADDRESS UK Office: JPL Telecom Limited Units 1 & 2, Church Close Business Park, Church Close, Todber, Sturminster Newton, Dorset, DT10 1JH, England USA Office: JPL Telecom Holdings LLC 445 W Merritt Ave, Merritt Island, FL 32953, USA www.jpltele.com...
