Summary of Contents for Kicker WXRC
- Page 1 WARHORSEREMOTECONTROL WXRC...
- Page 2 That is why all Warhorse amplifiers have been built from day one with the ability to be controlled remotely...and now you have the tool to do so, the WXRC. The WXRC gives you complete access to up to 16 KICKER Warhorse amplifiers and incorporates the latest in microprocessor technology which allows you to group and control each Warhorse amplifier in your system.
-
Page 3: Side View
These controls and their usage will be explained later with more detail in each menu usage section Mounting DIN Mounting Using the supplied hardware you can mount the WXRC into a standard DIN sized opening. Be sure you will have a minimum of 2” (51... - Page 4 Once your holes are drilled you can use the two supplied M3 Now that you have mounted your WXRC Control Head it is time to do some wiring. The first step is to screws to secure the WXRC plug your WXRC Control Head into the WXRC Interface Box.
- Page 5 Network Jack WXRC WXRC Network Cables Now we can run the Network Cables from the WXRC Interface Box to your WX Series amplifiers to create the WXRC Communications Network. Run the supplied 5-meter Network Cable from the Interface Box to the REMOTE IN jack of your first WX Series amplifier.
- Page 6 Here are the descriptions of each menu item, its function and how to operate it. DEFAULT - This menu is displayed when your WXRC is first powered up and operating. If you are in another menu making adjustments, the WXRC will time-out and return to the DEFAULT menu automatically after 3 minutes of no key press activity.
- Page 7 Once the amplifier you want to adjust is selected you will be able to choose from the following items. Some of these functions may not be available depending on if the amplifier is assigned to a Group and what LINK property the group has set. This is described in more detail in the WXRC SETUP menu. GAIN »...
- Page 8 This indicates you are making adjustments in the HI-PASS menu. The KICKER WXRC monitors and prevents any high pass crossover point from being set any closer than 1/3 octave from the low pass crossover point. If you cannot set the high pass crossover where...
- Page 9 When a group is created from the WXRC SETUP menu it can be set as a LINK ON or a LINK OFF group. All of the GROUP ADJ functions are described in this section but what you can adjust for the group will vary based on this setting.
- Page 10 If each amplifier has different gain settings, the WXRC will display the gain level of the highest amplifier in the group . It also monitors and maintains any differences between channels or individual amplifiers that you may have set separately.If you can not adjust a group up or down, then it means the channel differences are being maintained and there is no where to go.
- Page 11 phase M M E E N N U U - Here is where you can adjust the selected group’s polarity output between 0 or 180 degrees. All amplifiers in the group will be adjusted. 0 degree Use the keys to select from ...
- Page 12 M M E E N N U U - Here is where you can set the proper date (Month, Day, Year) that is displayed in the scrolling DEFAULT menu. The WXRC contains a backup battery good for 5 years to maintain this setting even if power is removed from the unit.
- Page 13 At this point you have explored all the settings in the DISPLAY menu. Press the key to return to the WXRC SETUP menu. M M E E N N U U - Here you can create and customize amplifier groups in the WXRC. This is Group Adj ) or separately (...
- Page 14 RELEASE M M E E N N U U - Here you can remove any amplifier(s) from a group it is currently assigned to. Use the keys to select which group you want to release an amplifier(s) from and press the key to select it.
- Page 15 WXRC NAME M M E E N N U U - Here you can change the default name of the WXRC controller ( any 10 character name you want. This is the name that scrolls in the DEFAULT menu.
- Page 16 LOCK CODE M M E E N N U U - Here you can change the default security lock code used for the WXRC Security function. This code is used to unlock the WXRC after it has been locked to prevent un-authorized use.
- Page 17 If your WXRC does not appear to be working, check obvious things first such as blown fuses, poor or incorrect wiring connections, cables and connectors not fully seated, etc. There is a Green LED located on one end of the WXRC Interface Box. This LED indicates the WXRC is receiving power and is turned on.
- Page 18 . . If you have questions about the installation and operation of your new KICKER WXRC Remote Control, see the Authorized KICKER Dealer in your area or contact KICKER Technical Services directly at (405)624-8583.
- Page 19 Manual Contents Features p. 2-4 WXRC Setup Included Components p. 3 ISIS Display p. 3-4 WXRC Setup Menu Display Menu Mounting p. 4-6 Brightness Menu Temp Menu Wiring p. 7-8 Hold Time Menu Screensaver Menu Menu System p. 9-16 Set Date Menu...
- Page 20 ElectronicsLimitedWarranty Kicker warrants this product to be free from defects in material and workmanship under normal use for a period of THREE (3) MONTHS from date of original purchase with receipt. When purchased from an Authorized KICKER Dealer it is warranted for TWO (2) YEARS from date of original purchase with receipt. In all cases you must have the original receipt.
- Page 21 ©2008 Stillwater Designs...
