Page 1
Triple IR Flame Detector U SER MANUA L +61 8 6108 0000 info@gastech.com gastech.com...
Page 2
No part of this publication may be reproduced or transmitted for commercial purposes, such as selling copies of this publication or for providing paid-for support services. The Gastech logo is a trademark of GASTECH AUSTRALIA PTY LTD, registered in the U.S. and other countries.
Built-in-Test (BIT) - Automatic (and manual) self-test of window cleanliness and the overall • operation of the detector. Window heater to avoid condensation and icing. • Tilt mounting bracket for accurate detector positioning. • For more information & technical support: info@gastech.com...
Any detected fault is indicated as shown in Table 4 (in section 4.1). During the “Dirty Window” fault the detection sensitivity is significantly reduced, while “Fault” refers to critical faults which prevent flame detection. For more information & technical support: info@gastech.com...
F-Guard IR3 HD User Manual 76-M-6010-02-02 Product Overview 1 - F -IR3-HD IGURE RONT VIEW OF THE UARD 2 - R -IR3-HD IGURE EAR VIEW OF THE UARD For more information & technical support: info@gastech.com...
3 - T IGURE ILT MOUNT 1.5.2 Weather Cover The weather cover P/N 85-6000-WC-SS- 02protect the detector from extreme weather conditions such as heat, rain and snow 4 - W IGURE EATHER OVER For more information & technical support: info@gastech.com...
• Air pressure source: Clean, dry, and oil-free • Pressure: 2-3 bar /30-45 psi Fitting: 7/16”—20UNF-2A • • Operation temperature: -55°C to +85°C / - 67°F to +185°F 6 - A IGURE HIELD For more information & technical support: info@gastech.com...
Each simulator kit contains a carrying case, simulator, carrying strap, battery charger, user manual, Allen key and a tool for removing the simulator rear cover. 8 - F-Guard-FSIM-IR3 F IGURE LAME IMULATOR RONT For more information & technical support: info@gastech.com...
The nature of the hazards, including materials stored or used and the protected objects • The sensitivity of the detectors If there are any obstructed lines of sight • The field of view of the detectors (See Figure 9 and Figure 10) • For more information & technical support: info@gastech.com...
F-Guard IR3 HD User Manual 76-M-6010-02-02 9 - H IGURE ORIZONTAL IELD OF 10 - V IGURE ERTICAL IELD OF For more information & technical support: info@gastech.com...
Page 14
(paint, oil, etc.) that will burn and may be of the size that should be detected. For more information & technical support: info@gastech.com...
If the equipment is likely to come into contact with corrosive and/or other harsh substances, consult with the relevant technical persons to take suitable precautions to prevent the detector from being adversely affected, thus ensuring that the type of protection is not compromised. For more information & technical support: info@gastech.com...
Mount the tilt mount base (Figure 11: Tilt Mount Base - Plate View) to a solid structure using four suitable fixings through the four 7mm (0.28") diameter holes. Four captive screws with spring washers are provided in the tilt mount. Figure 11: Tilt Mount Base - Plate View For more information & technical support: info@gastech.com...
(Make sure the detector is pointing in the correct direction). The detector is now correctly mounted, aligned and ready for electrical connection. Please refer to section 2.7 for wiring instructions and section 3 for a description of the detector’s configuration settings. For more information & technical support: info@gastech.com...
The terminal compartment at the back is the only part of the housing that should be opened by the user. The detector has 22 screw terminals as shown in the following figure and table: • For more information & technical support: info@gastech.com...
“24 VDC (-)” terminals (2 or 12)”. See 3.11 Manual BIT – Alarm Output Test for more details. RS 485 (+) RS-485 Modbus communication (used by the “Gastech Communicator” software) RS 485 (-) Ethernet TX+...
Detector Controller 24VDC Return 16 – S IGURE CHEME The following drawing shows how to wire the detector to act as a current source non- isolated transmitter (3-wire connection): 24VDC Return Controller Detector For more information & technical support: info@gastech.com...
In alarm conditions, the alarm relay will close the contact and short the loop. With this configuration, the panel does know which detector in the loop caused the alarm or fault. See figure below. 19 - 4 W IGURE ELAY ONNECTION For more information & technical support: info@gastech.com...
For analog video cabling, 75 Ohm - analog video patch cable or shielded twisted pair. Earth/Ground Regime Any earthing regime employed must avoid earth loops. The following information is provided to assist with proper earthing of the detector For more information & technical support: info@gastech.com...
Page 24
To reduce the likelihood of radio frequency interference affecting the • operation of units it is recommended that neither units nor their cabling is installed close to the antennae of high-powered radio, radar or satellite communication equipment. For more information & technical support: info@gastech.com...
3 Configuration options Some functions of the detector can be configured using an RS-485 modem connected to a computer with the “Gastech communicator” software. For details of how to download the software please contact technical support via email at info@gastech.com.
A process A standard fire is defined as a 1x1 ft (0.1 m ) N-heptane pan fire, with maximum wind speed of 6.5 ft/s (2 m/s). For more information & technical support: info@gastech.com...
Modbus Address The detector can communicate with the Gastech communicator software using a Modbus RTU compatible protocol on RS-485. This protocol allows for a network of detectors to be connected, each with a unique Modbus address. The address of the detector can be set to any value in the range 1–247.
2– Closed when “Aux Relay” is set to “Dirty Window Warning”. 3 – 16mA when “Enable Pre-Alarm 0-20mA” is enabled. 4mA when “Enable Pre-Alarm 0-20mA” is disabled. 4– Closed when “Aux Relay” is set to “pre-alarm”. For more information & technical support: info@gastech.com...
The BIT process runs automatically at startup and periodically during the operation of the detector. The BIT can also be initiated manually by connecting the “Manual BIT” terminal and the “24 VDC (-) “terminal for one second (see Table 1) or by using the Gastech communicator software (connected through RS-485).
Where dust, dirt or moisture accumulates on the window, first clean the window with a soft optical cloth and detergent, and then rinse with a clean soft cloth, cotton swab, or tissue. If contamination continues to be an issue consider using the air shield. For more information & technical support: info@gastech.com...
• Check video wiring and polarity. • Green LED constantly on Wiring or software Check wiring and polarity. • Fault Relay closed. problem Check ONVIF Client software. • No digital Video (through ethernet) For more information & technical support: info@gastech.com...
Refer to the detector warranty statement in section 12. 8 Gastech Communicator Software The Gastech Communicator software can be used to configure and monitor the F-Guard-IR3 flame detector. The software communicates using Modbus over an RS-485 port to the detector. Modbus commands enable the user to configure parameters and monitor the status of the detector.
Maximum 300mA all systems in operation (including window heater) Cable Entries: 2x conduit entries 3/4” NPT or M25, with one entry plugged with a suitably • certified stopper. Wiring: 14-17AWG (2.5-0.35mm • For more information & technical support: info@gastech.com...
Ingress Protection: IP66 & IP68 (2m, 24hr); NEMA 4X & 6P • The FAULT relay will normally be energized and the contact will be closed during normal operation of the detector. The contact will be open at fault condition or low voltage. For more information & technical support: info@gastech.com...
The detector fully complies with EMC directive 2014/30/EU and is protected against interference caused by RFI and EMI. The cables to the detector must be shielded and the detector must be grounded to comply with the EMC directive. For more information & technical support: info@gastech.com...
Pan Size Distance ft (m) Average Response Time (Seconds) N-Heptane 1 x 1 ft 197 (60) 32” plume 148 (45) 1 x 1 ft 148 (45) Methanol 1 x 1 ft 125 (38) For more information & technical support: info@gastech.com...
Page 40
For performance details of models 3, 4 and 5 the following documents are available, on request: Models 3 and 4 - hangar / helideck F101V0023.06. Model 5 - fast response / automotive / spray paint booth applications For more information & technical support: info@gastech.com...
Quartz lamp (500W) non-shielded with 2 (0.5) water drops on sensors Mercury vapor lamp 160Wx3 2 (0.5) Car Exhausts 2 (0.5) Projector led 2 (0.5) Solenoid bell 2 (0.5) Soldering iron 2 (0.5) Electric Drill 2 (0.5) For more information & technical support: info@gastech.com...
“Act of God” which are above and beyond its control. GASTECH AUSTRALIA PTY LTD will, upon receipt of any defective product, transportation prepaid, repair or replace it at its sole discretion if found to have been defective when shipped.
Page 44
The HART protocol implemented in this flame detector corresponds to HART rev. 7.0. It supports HART Universal commands including Common Practice and Device Specific Commands. Contact us Gastech 24 Baretta Rd, Wangara, 6065 Tel: +61 8 6108 0000 Email: info@gastech.com For more information & technical support: info@gastech.com...
Page 45
HEAD OFFICE SYDNEY OFFICE BRISBANE OFFICE 24 Baretta Road Suite G01, 10 Tilley Lane PO Box 349 Wangara WA 6065 Frenchs Forest NSW 2086 Cannon Hill Qld 4170 Phone: +61 8 6108 0000 Phone: +61 2 9451 0054 Phone: +61 7 3160 0901...
