USER MANUAL

V1.0

Table of Contents

Need help?

Do you have a question about the MQi GT EVO and is the answer not in the manual?

Questions and answers

Summary of Contents for TMP MQi GT EVO

Page 1 USER MANUAL V1.0...
Page 2: Table Of Contents
CONTENTS General Notice Precautions Safety Notice Downloading the APP Installation Guide Parts Info Attach the Dashboard and Combination Switches SN Code here Operation Guide Battery Use and Maintenance DOs and DON'Ts while Riding Maintenance and Repair The SN Code of your scooter. Storage Method Please see P.4 for detailed information.
Page 3: General Notice
Do not dismantle the scooter on your own. Please contact your dealer for replacement or purchase of original parts. Do not lend your MQi GT EVO to those who can’t operate a scooter for others' safety and WARNING: Failure to follow the instructions herein may lead to serious casualties.
Page 4: Safety Notice
Downloading the APP Safety Notice Using a safety helmet and protective goggles is strongly advised. Functions such as checking battery level, locating, and management can be implemented on the You are advised to take proper training or exercise before using on open roads. electric scooter through the app.
Page 5: Installation Guide
Installation Guide Place the 12V battery in side the battery compartment under the floor board, with Step 1 electrode terminals facing forward. Attach the red positive electrode terminal with red Open the Accessories Box to take the tools. wire, and black positive electrode terminal with black wire. Step 1 Install the rearview mirrors into the mounting holes on dashboard and turn it Mount the metal battery fixture to body with screws provided.
Page 6: Parts Info
Parts Info Right Rearview Combination Left Mirror Switch Combination Switch Taillight Handrail Turn Signal Indicator Saddle Headlight Reflector Right Left Reflector Reflector 12V Battery Side Central compartment Stand Stand...
Page 7: Dashboard And Combination Switches
Dashboard and Combination Switches Riding mode Currently selected riding mode E-SAVE/DYNAMIC/SPORT; Dual battery Displayed when two batteries have the same power; synchronization state Displayed at the time of efficient energy conversion (a Energy-saving state speed of more than 3 km/h delivered per ampere of power output);...
Page 8 Parking and Other Current battery level and battery bar (two battery Real-time power bars respectively represent the levels of two batteries), and the estimated remaining mileage; Air temperature, current weather conditions and temperature; Real-time speed; Zhongshan East 2nd Rd Energy consumption curve, curve of change in energy consumption during riding; Total mileage, total riding distance;...
Page 9 Left-hand Combination Switch Right-hand Combination Switch Cruising Mode Safety Switch Hazard Light (flashing lights) Riding Mode High/Low Beam Scooter Light Adjustment Turn Signal Indicator Start Button Horn Overtaking Light Button Safety Switch Cruising Mode Hazard Light (flashing lights) Push the top button to cut off the power system. Riding Mode Press the button to cruise at current speed.
Page 10: Operation Guide
Operation Guide Front Storage Area Keyhole USB Port Unlocking the anti-theft lock Opening the saddle Insert the spare key into the emergency key Insert the spare key into the emergency key hole, push it inward, and clockwise rotate hole, and counterclockwise rotate to the to the “UNLOCK”...
Page 11 Follow this simple three-step procedure to enjoy How to use the Remote Control a smooth ride. Spare key When the vehicle cannot be powered on, spare key may be used to open the battery compartment/faucet lock. Step 1 A. Press the Start button on the remote control. /Or Start the Unlock Button 1.Press the button to disarm the alarm.
Page 12: Battery Use And Maintenance
Battery Use and Maintenance Check the scooter parts before riding. If there is any abnormality, repair it or seek profession repair service. Battery Level Indicator Check the conditions of the power circuits, lighting circuits, etc; When the Indicator Button is pressed, the Indicator will light up to show the percentage Check whether the front and rear brakes are working properly;...
Page 13 12V battery maintenance: WARNING: The MQi GT EVO battery is NOT a repairable part by the user. In case of 12V battery will consume electricity during long-term storage. It is recommended to battery fault, please contact your dealer. Users dismantling the battery may lead to leakage, connect the main battery for long-term storage to prevent draining the 12V battery.
Page 14 Charging Methods Battery Connector/Charging Port Charging Pot Battery Battery Lock Charging on the Scooter Charging the Battery Open the saddle, open the cover of the Remove the battery from the Battery Cover connector, and plug the charger into scooter. Connect the charger with 12V Battery fixture bracket the charging socket.
Page 15 DO NOT put charger into trunk or tail box while charging. MQi GT EVO battery will lose more capacity in lower temperature conditions. To be more While charging, connect battery with charger before connect with electric supply. After pecific, the usable capacity at -10°C is 70%, 85% at 0°C and 100% at 25°C.
Page 16: Dos And Don'ts While Riding
DOs and DON'Ts while Riding Braking Precautions Adjust the scooter upright before applying brakes. Before Riding If the tyres are locked and the scooter loses steering ability resulting from excessive braking Please check the following details before riding. force, loosen the grip on the braking lever and the tyres will be working again and the scooter will be stabilized.
Page 17: Maintenance And Repair
Maintenance and Repair ATTENTION If the scooter is frequently used in overload, high-speed, bumpy or up/downhill riding Users are advised to have the scooter checked and maintained on a regular basis, even for the conditions, the maintenance cycle should be shortened. scooters that are not used for a long time.
Page 18: Storage Method
Storage Method Regular Maintenance Checklist Brakes Short-term Storage Lights Keep the scooter in flat, steady, well-ventilated and dry area. Regular Safety and Horn Performance Check Charge the battery to 50% full before storage to maximize battery life. Electric Parts Avoid exposure under sunlight and rain to reduce damage or aging. Tyres Long-term Storage Lubrication...
Page 19: Troubleshooting List
Troubleshooting List Troubleshooting List Malfunction Malfunction Causes Troubleshooting Causes Troubleshooting Description Description Dead battery Charge the battery. 1. Dead battery 1. Charge the battery. Sudden stop during No output when 2. Battery not connected 2. Check if it’s properly connected a ride switched on 3.
Page 20 Fault Code List FOC varification Non-original Controller or Restart the bike. Contact your dealer Fault failure communication failure if it does not work. Meaning Causes Troubleshooting Code Battery in overcurrent Battery Stop charging and check if the charger Motor Hall Sensor failure Contact your dealer.
Page 21 Short-circuit between positive Battery Pack 2 not and negative electrodes of Excessive voltage difference Contact your dealer discharging Battery Pack 1 not battery pack or external discharging discharge current exceeding Short-circuit between positive short circuit protection value and negative electrodes of due to external connection Battery Pack 2 not battery pack or external...
Page 22: Technical Parameters
Technical Parameters Charger in short circuit Remove the charger and check the stop charging protection battery circuit Contact your dealer FOC Communication Can not receive Contact your dealer. failure Controller's data Battery Check the Connector is properly BMS can't return data or communication plugged.
Page 23 MQi GT EVO Brake System Combined Braking System[CBS] Motor Rated Power 5000 W Frame 180 mm Minimum Ground Clearance Battery Capacity 72 V 26 Ah*2 Seat Heihgt 816 mm Max.Speed 100 km/h Dimension 1949 x 700 x 1171 mm Product weight...
Page 24: Maintenance Record
Maintenance Record Maintenance Record Date Mileage Date Mileage Notes： Notes： Dealer： Dealer：...
