VM600
VM600 AC Drive
User Manual
- 0 -
Verion Code 6.0004.0538-00-VM600-E-V03-202107

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VM600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SAJ VM600

Summary of Contents for SAJ VM600

  • Page 1 VM600 VM600 AC Drive User Manual - 0 - Verion Code 6.0004.0538-00-VM600-E-V03-202107...
  • Page 2 Thank you for choosing VM600 Series AC Drive. This user manual introduces the technical specifications, installation instructions, functions and performance of VM600 Series AC Drive properly. Please read this user manual carefully before carrying out works such as installation, commissioning, maintenance, etc.

  • Page 3: Table Of Contents

    CHAPTER 6 TROUBLESHOOTING & COUNTERMEASURES - 24 ................- 24 - 6.1 F AULTS AND SOLUTIONS 6.2 C ............. - 26 - OMMON FAULTS AND SOLUTIONS CHAPTER 7 CONTECT SAJ ............- 27 - WARRANTY CARD................- 28 - - 2 -...

  • Page 4: Safety Precautions

    VM600 Safety precautions ■ Warning sign DANGER: Indicates that failure to comply with the notice will result in severe personal injure or even death. WARNING: Indicates that failure to comply with the notice will result in moderate personal injury, property damage or equipment damage.
  • Page 5 VM600 ◎Do not use a circuit breaker to control the start and stop of the AC Drive. Otherwise, the AC Drive may be damaged. ◎Since the AC Drive makes the motor running speed from low to high in a short time, please confirm that the motor and equipment are in the allowed running range before running.
  • Page 6 VM600 ◎“ STOP/RESET” key may become invalid as a result of some function setting. It is recommended to install an independent emergency circuit breaker for the AC Drive control system, otherwise, or personal injury may be caused. ◎When the power is on, there may be electricity in the AC Drive’s terminals even if it is in stop mode.

  • Page 7: Chapter 1 Product Information

    VM600 Chapter 1 Product information 1.1 Technical specifications Item Specifications Control mode V/F control Startup torque 0.5Hz/100% Speed range 1：50 Control Speed stability accuracy ± 1% features 1kHz ～ 6kHz； Carrier frequency 60s for 150% of the rated current, 1s for 180% of the rated Overload capacity current.

  • Page 8: Product Nameplate

    ② 2：220VAC； 4：380VAC Voltage grade Voltage grade Power phase S: single ； T: three-phase ③ The input power identification ④ 1R5-1.5kW， Rated power Power range R is the decimal point Table 1-3-1 VM600 series model field comment - 7 -...

  • Page 9: Product Model

    VM600 1.4 Product model Rated Power Input Output Motor G/P power capacity current current AC Drive Model VM600-2SR75 0.75 0.75 VM600-2S1R5 14.2 VM600-2S2R2 VM600-4TR75 0.75 0.75 VM600-4T1R5 VM600-4T2R2 VM600-4T004 10.5 VM600-4T5R5 14.6 VM600-4T7R5 20.5 VM600-4T011 VM600-4T015 Table 1-4-1 Product model table...

  • Page 10: Chapter 2 Installation

    VM600 Chapter 2 Installation 2.1 Overall structural drawing（unit：mm） Figure 2-1-1 Outline dimension diagram Mounting Overall Dimensions Mounting Hole Hole AC Drive Model Diameter VM600-2SR75 VM600-2S1R5 VM600-2S2R2 VM600-4TR75 VM600-4T1R5 VM600-4T2R2 VM600-4T004 VM600-4T5R5 VM600-4T7R5 VM600-4T011 VM600-4T015 Table 2-1-1 outline dimension - 9 -...

  • Page 11: Terminal Connection

    VM600 Terminal connection Power input Out ternimal MCCB terminal Forward Relay output Reverse Fault reseting Multi-speed terminal 1 RS485 communication terminal Analog input terminal RJ45 +10V Figure 2-2-1 Terminal connection - 10 -...
  • Page 12 VM600  Main circuit connection Terminal mark Name Description R、S、T Power supply input terminals Connect to the AC power supply U、V、W AC drive output terminals Connect the three-phase motor. Grounding terminal Must be grounded. Table 2-2-1 Main circuit terminals and function ...

  • Page 13: Chapter 3 Display And Operation

    VM600 Chapter 3 Display and operation 3.1 Keypad You can modify the parameters, monitor the working status and start or stop the AC Drive by operating the keypad, as shown in the following figure. Figure 3-1-1 Keypad diagram 3.2 Description of indicators and keys...

  • Page 14: Chapter 4 Parameter Function

    VM600 Chapter 4 Parameter function “○”: the parameter can be modified in both standby and operating state； “●”: the parameter can’t be modified in operating state； “◎”:the parameter is the actual detected and recorded value which can’t be modified； Note: the communication address is hexadecimal.
  • Page 15 VM600 Parameter Name Setting Range Default Property Address Retentive of digital setting 0：No retentive ● F0.13 000D frequency 1：retentive 0：Run when motor is running ○ F0.14 Fan operating mode 000E 1：Keep run when power on 0：0-10V 1：4-20mA ○ F0.15 AI1 Input Option...
  • Page 16 VM600 Parameter Name Setting Range Default Property Address ● F3.05 Multi-Point Frequency 3 F3.05~F2.02（Motor Rated Frequency） 0305 ● F3.06 Multi-Point Voltage 3 0.0%~100.0% 0306 ○ F4.00 Torque Boost 0.0%～30.0% 4.0% 0400 Cut-off frequency of torque ● F4.01 0.00Hz～F0.05 50.00Hz 0401...
  • Page 17 VM600 Parameter Name Setting Range Default Property Address ○ F5.14 DI1 Disable Delay Time 0.0s～100.0s 0.0s 050E ○ F5.15 DI2 Disable Delay Time 0.0s～100.0s 0.0s 050F 0: No function 1: Forward running (FWD) 2: Reverse running (REV) 3: Three-wire operation control...
  • Page 18 VM600 Parameter Name Setting Range Default Property Address zone User-defined output ○ F6.06 0～65535 0606 comparison value 1 User-defined output ○ F6.07 0～65535 0607 comparison value 2 ○ F6.08 AO1 Output Option 0：Running Frequency（0～F0.05） 0608 1：Set Frequency（0～F0.05） 2：Output Current （0～Double Rated Current of VFD）...
  • Page 19 VM600 Parameter Name Setting Range Default Property Address ○ F8.02 Jog Deceleration Time 0.0s～100.0s 10.0s 0802 ○ F8.03 FWD/REV dead zone time 0.0s～100.0s 0.0s 0803 0：valid ○ F8.04 Reverse control 0804 1：invalid ● F8.05 Reserved 0805 0：Invalid ○ F8.06 Startup Protection Option 0806 1：Valid...
  • Page 20 VM600 Parameter Name Setting Range Default Property Address Acceleration/deceleration 0 ～ 3 time of simple PLC ○ FD.13 0D0D reference 3 0：s（second） Time unit of simple PLC ○ FD.14 1：h（hour） 0D0E running 2：min（minute） The source of multistage 0：Set by FD.00 ○...

  • Page 21: Monitoring Parameters

    VM600 4.2 Monitoring Parameters Parameter Name Minimum Unit Priority Address ◎ D000 D0.00 Running Frequency(Hz) 0.01Hz ◎ D001 D0.01 Set Frequency(Hz) 0.01Hz ◎ D002 D0.02 Bus Voltage(V) 0.1V ◎ D003 D0.03 Output Voltage(V) ◎ D004 D0.04 Output Current(A) 0.01A ◎...

  • Page 22: Error Records

    VM600 4.3 Error Records Parameter Name Range and Description Priority Address No Error:0 Acceleration Over Current：Err02 Deceleration Over Current：Err03 Over Current at constant speed：Err04 Acceleration Over Voltage：Err05 Deceleration Over Voltage：Err06 Over Voltage at constant speed：Err07 Low Voltage error：Err09 ● E0.00...

  • Page 23: Chapter5 Communication Protocol

    VM600 Chapter5 Communication Protocol VM600 Series AC Drive provides RS485 communication interface and supports Modbus communication protocol. Users can achieve centralized control by computer or PLC, set AC Drive operation commands, modify or read function code parameters, read the working state and fault info of the AC Drive.

  • Page 24: Eeprom Addresses Introduction

    VM600 Character Function Address Description Remarks istic Speed 0009：Low Voltage Error 000A：VFD Overload 000B：Motor Overload 000E：IGBT Overheat 000F：External Error 0012：Current Detection Error ： 0015 Parameters Writing/Reading Error 0000：No Error 0001：Password Error 0002：Command Code Error 0003：CRCError Communication 0004：Invalid Address 8001H Error Feedback 0005：Invalid Parameter...

  • Page 25: Chapter 6 Troubleshooting & Countermeasures

    VM600 Chapter 6 Troubleshooting & countermeasures 6.1 Faults and solutions Fault Fault type Reason Solution code 1. The output circuit of AC Drive is grounded or short circuited. 1. Eliminate external faults. 2. The acceleration time is too short. 2. Increase the acceleration time.
  • Page 26 VM600 Fault Fault type Reason Solution code 2. The air filter is blocked. 3. Replace the fan. 3. The fan is damaged. 4. Ask for technical service. 4. The IGBT is damaged. External equipment Err15 External fault signal (DI) triggers 1.

  • Page 27: Common Faults And Solutions

    VM600 6.2 Common faults and solutions Fault Possible causes Solutions 1. The input power of AC Drive is abnormal. No display 1. Check the input power. 2. The control board has a bad at power-on 2. Re-connect the cable. contact with cable that is connected state 3.

  • Page 28: Chapter 7 Contect Saj

    VM600 Chapter 7 Contect SAJ Guangzhou Sanjing Electric Co., Ltd. SAJ Innovation Park, No.9, Lizhishan Road, Science City, Guangzhou High-tech Zone, Guangdong, P.R.China. Postcode：510663 Web.：http：//www.saj-electric.com Technical Support & Service Fax：+86 20 6660 8589 E-mail：service.drive01@saj-electric.com International Sales Tel：+86 20 6660 0069 Fax：+86 20 6660 8589...

  • Page 29: Warranty Card

    VM600 Warranty Card Company name: Company address: Customer info. Contact: Tel.: Fax: Zip code: Product model: SN code: Product Buying date: Fault date: info. Motor power: Application situation: Fault description: Fault info. Signature: Date: - 28 -...
  • Page 30 VM600 Due to continuous improvement of products，technical parameters in this manual are modified without prior notice. - 29 -...
