AllVac Commercial

High and Low Pressure Commercial Refrigerant

Recovery System

Model Numbers: RRGA123E0A0, RRGA123B0A0, RRGA123C0A0,

RRGA123F0A0, RRGA123G0A0, RRGA323E0A0, RRGA323B0A0,

RRGA323C0A0, RRGA323F0A0, RRGA323G0A0

RRGA-SVX01A-EN

Table of Contents

Need help?

Do you have a question about the AllVac Commercial and is the answer not in the manual?

Questions and answers

Summary of Contents for SF AllVac Commercial

Page 1 Installation Operation Maintenance AllVac Commercial High and Low Pressure Commercial Refrigerant Recovery System Model Numbers: RRGA123E0A0, RRGA123B0A0, RRGA123C0A0, RRGA123F0A0, RRGA123G0A0, RRGA323E0A0, RRGA323B0A0, RRGA323C0A0, RRGA323F0A0, RRGA323G0A0 RRGA-SVX01A-EN...
Page 2: Table Of Contents
Table of Contents General Information......... 3 Warnings and Cautions .
Page 3: General Information
General Information Warnings and Cautions Warnings and Cautions appear at appropriate locations throughout this manual. Read these carefully. WARNING CAUTION Indicates a potentially hazardous Indicates a potentially hazardous situation which, if not avoided, situation which, if not avoided, could result in death or serious may result in minor or moderate injury.
Page 4: Specifications
General Information Electrical Power Requirements Recovery Main Components & Controls: • 115VAC, 50/60 Hz, 1-Phase, 20-Amperes Min. CKT 15.0 Amp, Max Fuse 20 Amps Models RRGA123G0A0 & RRGA323G0A0: • Compressor 230/460 VAC, 50/60Hz, 1 Phase Min. CKT 20.0 Amp, Max Fuse 30 Amps. Models RRGA123B0A0 &...
Page 5: Product Description
General Information Product Description RefTec’s AllVac recovery system provides automated recovery of most low & high pressure refrigerants and blends. The unit consists of a 3 or 5-hp compressor with oil separator, disposable liquid & vapor prefilter driers, high capacity air cooled condenser, microprocessor control system, and actuated valving system.
Page 6 General Information Figure 1. AllVac Connections 3/4” RECOVERY CYLINDER PORTS DRIERS 3/4” PORT: 3/4” PORT: VAPOR 20-FT CONDENSER RRGA-SVX01A-EN...
Page 7 General Information Furnished with the AllVac are: • Two -10-ft. and 20-ft. 3/4” hoses equipped with four 3/4” female flare fittings with isolation valves • Two - 3/4”-5/8” flare reducing fittings • Two - 5/8” -1/2” flare reducing fittings • Two - 3/4” female flare unions •...
Page 8 General Information Figure 2. AllVac Schematic RRGA-SVX01A-EN...
Page 9: Operating Procedures
Operation Operating Procedures To ensure your safety as well as others, before attempting to recover an A/C, refrigeration or chiller system, proper and thorough preparation must take place: • Make sure you have a recovery cylinder with a minimum 3/4” male flare vapor port and a minimum 3/4”...
Page 10 Operation An additional feature can be accessed at this time, by pressing the “M” key. This display will show you total compressor run time as well as give you a historical maintenance schedule. In addition, at every 10 hours of cumulative operating run time for the compressor, an automatic message will appear each time you start the AllVac until maintenance is performed.
Page 11 Operation Note 1: If recovery tank side hoses have isolation valves, open them now. 13.“To Evacuate Hoses Press Enter, To Skip Hose Evacuation Press Cancel” if “Enter” is pressed, unit displays “Hose Evacuation in Pro- cess” followed by “Hose Evacuation Complete, Press Enter”. 14.Next “Open Vapor &...
Page 12 Operation Upon pressing “Enter”, AllVac prompts you to perform the following valve manipulations 20-26: Note 3: Close additional liquid access valve at this time, if being used. 20.“Close Access Valves on A/C System Being Recovered” then press”Enter”. 21.“Close Both Hand Valves on AllVac Unit A/C System Side” press “Enter”.
Page 13 Operation Note 4: If additional liquid line is connected for faster liquid recovery, open chiller and recovery tank valves now. When AllVac goes into vapor recovery, close recovery tank side of the hose. 33.AllVac will remain in liquid transfer state until manually switched to vapor transfer as follows: Once all liquid from chiller has been transferred and absolutely no liquid refrigerant is remaining in clear recovery hoses and you are absolutely...
Page 14: Removing Residual Refrigerant
Operation At this point, the microprocessor continues to monitor chiller pressure. Should pressure rise, AllVac restarts to again achieve the user-selected vacuum. 35.Then the display will read “Chiller Vapor Recovery Finished! press Enter”. Upon pressing “Enter”, AllVac prompts you to perform the following valve manipulations 36 - 42: Note 5: Close additional liquid access valve at this time, if being used.
Page 15 Operation Changing Replaceable Cores Make sure you replace filter cores after each recovery job. Simply unscrew used filter assembly and replace. Procedures for Recharging System Using AllVac These procedures provide for the transfer of refrigerant liquid and vapor from a recovery tank to a centrifugal chiller system using the AllVac recovery unit. These procedures are to be used when clean refrigerant is being returned to a chiller without recycling.
Page 16 Operation 2. Evacuate Air from Chiller, AllVac and Hoses. a) Once all lines are connected, open the AllVac valves in the following se- quence: system liquid, system vapor, tank liquid, and tank vapor on AllVac only. b) Connect manifold gauge set and vacuum pump to ports on side of AllVac unit at compressor suction and discharge ports.
Page 17 Operation b) Before proceeding with this procedure, chiller pressure must be at a mini- mum of 15” Hg. of vacuum or greater for R-11 or R-123. The minimum pressure for R113 is 25” Hg. vacuum. If the chiller is not above the mini- mum level, do not proceed with liquid transfer, but repeat procedure 3 above.
Page 18 Operation 5. Evacuating Refrigerant Vapor From Recovery Tank and Hoses (This step removes any liquid or refrigerant vapor in the recovery tank and connecting hoses.) a) Energize chiller condenser and evaporator water pumps. Water should be flowing through both evaporator and condenser during this procedure to reduce the potential for freezing chiller tubes.
Page 19: Calibration
Calibration Procedure Steps: 1. At power up, the AllVac Recovery Unit will display: “AllVac COMMERCIAL RECOVERY UNIT” “HAS POWER (PRESS START)“ 2. At this screen you must press “CANCEL” twice within 5 seconds to enter the CALIBRATION mode.
Page 20: Changing Compressor Fluid
If you press “CANCEL”, a new calibration factor will not be calculated. It will then display the following message and be ready for operation: “ALLVAC COMMERCIAL RECOVERY UNIT” “HAS POWER (PRESS START) “ Changing Compressor Fluid The compressor’s charge of Poly Ester fluid should be regularly replaced...
Page 21 Figure 3. 230/460, 1 Phase Model RRGA-SVX-01A...
Page 22 Figure 4. 230, 1 Phase Model RRGA-SVX-01A...
Page 23 Figure 5. 230/460, 3 Phase Model RRGA-SVX-01A...
Page 24: Display Sequence
90 SECOND WAIT 1:30 LIQUID TRANSFER! SYSTEM LIQUID - - PSI IN PROCESS RECOVERY CYLINDER - - PSI ALLVAC COMMERCIAL RECOVERY UNIT RECOVERY UNIT HAS POWER (PRESS START) CHANGING VALVE SEQUENCE, VAPOR TRANSFER USE MVTO SELECT SCALE OR FLOAT SWITCH...
Page 25 DISPLAY SEQUENCE ALLVAC COMMERCIAL RECOVERY UNIT RECOVERY UNIT HAS POWER (PRESS START) USE MVTO SELECT SCALE OR FLOAT SWITCH SCALE SELECTED USE MVTO SELECT OPERATING VOLTAGE SINGLE CHANGING VALVE SEQUENCE, VAPOR TRANSFER PHASE 230V (THEN PRESS ENTER) 90 SECOND WAIT 1:30...
Page 26: Electrical
Electrical Table 1. Electrical Parts Breakdown Compressor Motors; Dual voltage model: 5HP, 230/460VAC, 50/60Hz,1Ph. 230/460 3ph model: 3HP 230/460VAC, 50/60Hz,1Ph. 230/460 3ph model: 3HP 230/460VAC, 50/60Hz,1Ph. Condenser Fan Motor; 115/230 VAC 50/60Hz High Pressure Switch Pressure transducer Actuator 22-26 VAC/ 2/-32 VDC Male Inlet - 50A, 600V, 1PH, 4W Male Inlet -15A,125V, 1PH, 3W GRD Terminal Block...
Page 27 Electrical Figure 6. Electrical Parts Layout STOP 1 L 1 3 L 2 A2 A2 RRGA-SVX01A-EN...
Page 28: Replacement Parts List
Replacement Parts Table 2. AllVac Replacement Parts List Reference Manufacturer Description Number Motor Actuator Actuated Ball Valve Assembly Pressure Transducer Check Valve Vapor Comp Oil Separator Crankcase Pressure Regulator Suction Accumulator Unit Frame Compressor Drive Motor 230/460 V. 3ph 5hp 1800 Rpm Compressor Drive Motor 230/460 V.
Page 29 Replacement Parts Figure 7. AllVac Replacement Parts Diagram RRGA-SVX01A-EN...
Page 30 Electrical Figure 8. 230/460, 1 Ph, 5 Hp Model, Electrical Controls Component Diagram RRGA-SVX01A-EN...
Page 31 Electrical Figure 9. 230/460, 3 Ph Model, Electrical Controls Component Diagram RRGA-SVX01A-EN...
Page 32 Electrical Figure 10. 230, 1 Ph Model S, Electrical Controls Component Diagram RRGA-SVX01A-EN...
Page 33: Troubleshooting
Troubleshooting Troubleshooting Procedures If functional difficulties are experienced and the preceding maintenance checks do not resolve the problem, refer to the following troubleshooting chart for assistance. Troubleshooting Guide The following guide is provided to assist in analyzing problems that could occur. •...
Page 34 Troubleshooting Pressure differential between sys- Restrictions in recovery lines or Tank needs to have a 3/4” ID valve. tem and recovery tank becomes too tank Many tanks do not have 3/4” valves. high - greater than 50 psig. RefTec provides tanks fitted with properly sized valves for this pur- pose.
Page 35 Troubleshooting Pressure readings appear to be Pressure transducer reading Recalibrate pressure transducers - inaccurate improperly see instructions on Page 11 of this Manual. Replace transducer Pressure transducer failed RRGA-SVX01A-EN...
Page 36 Literature Order Number RRGA-SVX01A-EN File Number SV-CAP-RR-RRGA-SVX-01A-401 Supersedes Stocking Location La Crosse The Trane Company Aftermarket Business Unit Since The Trane Company has a policy of continuous product and product data improvement, it reserves the 3600 Pammel Creek Road right to change design and specifications without notice. Only qualified technicians should perform the La Crosse, WI 54601 installation and servicing of equipment referred to in this publication.
