S2 eBike Display Manual
Brake Indicator
USB Power On
Light Indicator
Current Speed
Average Speed
Max Speed
Peddle Assist Indicator
Brake Indicator: This icon appears to advise that the brake has been engaged and power to the motor has been
disabled.
USB Power On: Confirms if USB port is powered and ready for use.
Light Indicator: Confirms the lights are turned on and dims the display for night riding.
Current Speed: Real-time actual speed information.
Average Speed: Your average speed for this ride.
Max Speed: Your maximum speed travelled this ride.
Peddle Assist Indicator (PAS): Displays the current level of power assistance, where 0 is neutral and no power and
where 1 - 9 corresponds to power assist level. 1 is low, 9 is high.
Error Warning: The system has detected an error.
Battery Charge Percentage: 100% - The battery is fully charged. 0% indicates the battery is empty and requires
charging.
Battery Charge Level: This level is based on your riding style and optimised by a range algorithm. The display learns
how you ride and provides battery level information based on this data.
Speed preference: KPH or MPH
Mileage display: 'POW' - Power output from the motor. 'Trip' - distance travelled this ride. 'ODO' - odometer, total
accumulated mileage. 'Time' - Time elapsed since the system powered on.
Display Icon Information
1
Error Warning
Battery Charge Percentage
Battery Charge Level
Speed
KPH or MPH
Power | Trip
Odometer | Time
Value

Advertisement

loading
Need help?

Need help?

Do you have a question about the S2 and is the answer not in the manual?

Questions and answers

Summary of Contents for BGB S2

  • Page 1 S2 eBike Display Manual Display Icon Information Error Warning Brake Indicator Battery Charge Percentage USB Power On Light Indicator Battery Charge Level Current Speed Speed Average Speed KPH or MPH Max Speed Power | Trip Odometer | Time Peddle Assist Indicator...

  • Page 2: Keypad Function

    Keypad Function '+' PLUS button '-' MINUS button 'i' MODE button POWER button Power On/Off: Long press the POWER button for about 1 to 3 seconds to turn the system on. Long press the power button for about 1 to 3 seconds to turn the system off. PAS Levels: Pressing the PLUS button or MINUS button will increase or decrease the level of assistance.
  • Page 3 Speed Information: Short pressing the POWER button scrolls through the AVG (Average speed), MAX (maximum speed) and SPEED ( real time speed) AVG (Average speed) MAX (Maximum Speed) SPEED (Real Time Speed) Clear logs: Press the PLUS and MINUS button for 1 second to clear average, max, trip and time data. Walk Mode (6 kph): Press and hold the MINUS button to use walk mode.

  • Page 4: Settings Menu

    0), you cannot enter the setting interface. If you start cycling in the setting interface (the speed indicator is not 0), you will automatically exit the setting. Default BGB Recommended Description Setting Screen brightness 1 through 5 with 1 = DIM 5 = BRIGHTEST.

  • Page 5: Error Code Definition

    Error Code Definition The display can provide error indications for faults. When a fault is detected, the LCD screen displays an 'engine warning type symbol', and the error code “n” and error description are displayed at the speed display position. Please refer to the error code comparison table to determine the corresponding fault.
