Sena HelloDevice Super SS100 Quick Start Manual

1. Connection

1) Hook up the Ethernet cable to
2) Hook up the RS232 serial cable
3) Hook up the power to the
HelloDevice
4) Confirm the Pow er LED lights up.
Super Series
5) Confirm the Li nk LED lights up
SS100
6) Confirm the Ready LED lights up and then you can use the SS100.
the RJ45 connector of the
HelloDevice SS100 with your
hub or switch.
Figure 1. Connecting Ethernet cable
between HelloDevice SS100 and
your serial device.
(See Table 1 for pin assignments)
Figure 2. Connecting serial device
HelloDevice SS100.
Figure 3. Connecting power
and Act LED is blinking.
Pin RS232
1
1 2 3 4 5
2 Rx
3 Tx
DTR
4
GND
5
6 DSR
6 7 8 9
RTS
7
CTS
8
9
Table1. DB9 Pin assignments

2. Log-in to serial console

1) Connect the RS232 serial cable
between your computer and
the serial port of the
HelloDevice SS100.
2) Slide Data/Console switch
to the Console side.
3) Run a terminal emulation program such as HyperTerminal and s
the serial configuration parameters as follows:
Baud r at e = 9600, Dat a bi t s = 8, Par i t y = None,
St op bi t s = 1, Fl ow cont r ol = None
4) Press ENTER key at the terminal emulation program.
Serial Device
5) Enter the user name and password. Factory default settings of t
user name and password are both adm i n.
W el c om e t o SS- 100 Conf i gur at i on
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Cons ol e#1 ( Ser i al ) : Not Connec t ed [ THI S]
Cons ol e#2 ( Tel net ) : Avai l abl e
Cons ol e#3 ( Tel net ) : Avai l abl e
Cons ol e#4 ( Tel net ) : Avai l abl e
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Pr es s Ent er
Logi n : adm i n
Pas s wor d : * * * * *
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
W el c om e t o SS- 100 c onf i gur at i on page
Cur r ent t i m e : 2002/ 06/ 18 10: 33: 13
Ser i al No. : SS100_02070001
I P m ode : DHCP
RS422 RS485
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Tx- Data-
Cons ol e#1 ( Ser i al ) : Connec t ed [ THI S]
Cons ol e#2 ( Tel net ) : Avai l abl e
Rx-
Cons ol e#3 ( Tel net ) : Avai l abl e
Rx+
Cons ol e#4 ( Tel net ) : Avai l abl e
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Sel ec t m enu
1. I P c onf i gur at i on
2. Ser i al por t c onf i gur at i on
Tx+ Data+
3. SNM P c onf i gur at i on
Figure 4. Connecting console
F/ W REV. : v1. 0. 1
M AC Addr es s : 00- 01- 95- 04- 15-
I P Addr es s : 192. 168. 4. 6
