Summary of Contents for CSE Kingfisher PLUS+
- Page 1 Kingfisher PLUS+ Superseded Hardware Reference Manual 7.12...
- Page 2 Document Information Document Control Copyright CSE-Semaphore (Australia) Pty Ltd. ABN 35 006 805 910 Copyright www.cse-semaphore.com/mykingfisher, info.kingfisher@cse-semaphore.com CSE-Semaphore asserts ownership of the intellectual property contained herein and Intellectual Property claims copyright and authorship. CSE-Semaphore has and retains all rights of ownership and use of the material herein in its on-going business.
-
Page 3: Table Of Contents
LM-2 Block Diagram ........................32 LM-2 Connections .........................33 2. RTS, CTS & CD signals active low to 0 V ............34 LNA-6: Line Amplifier Module, Leased Line ..............35 LNA-6 Specifications ........................35 LNA-6 Block Diagram ........................36 Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... - Page 4 Figure: AI-4 Rear Module and Link Location ............61 AI-4 Specifications .........................62 AI-4 Block Diagram ........................63 AI-4 Wiring Diagram ........................63 1.22 AO-2: Analog Current Output, 4 Channel ................64 Figure: AO-2 Rear Module and Link Location ............65 Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page...
- Page 5 PS-21: DC Supply Input 20 to 60 VDC ................83 PS-21 Specifications........................85 PS-21 Module LEDs ........................86 Battery Charging ...........................87 Part Numbers ..........................87 PS-21-C DC input, Auxiliary 24 V converter fitted.......... 87 PS-PS-21 Block Diagram.......................87 PS-21 Wiring Diagram ........................88 Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page...
-
Page 6: Ps-1/Psu-1: Ac Supply Input
This module can be installed in any I/O slot of a 3, 6 or 12 slot backplane in a system. Up to 4 Power Supply modules of any type can be installed in a backplane thus providing redundant and alternative power source configurations. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 7: Battery Charging States
If the temperature is 80 °C or -20 °C (minimum or maximum values) the temperature sensor is assumed to be faulty. An error will be flagged and a temperature of 25 °C will be assumed. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 8: Ps-1/Psu-1 Specifications
Temperature, AC Supply, DC Supply Temperature, AC Supply, DC Supply Status Voltage Supplies and Battery on Voltage Supplies and Battery on Front Indicators Front Bezel Bezel Connector Removable for AC/DC connectors Removable for AC/DC connectors Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 9: Output Characteristics
ISOLAT ED EAR T H (OPT IONAL) OUT PUT T EMP. LED DISPLAY MONIT OR ING SENSOR MODULE 80C51 MICR O R S485 ADC 8 BIT SER IAL BUS CONT R OLLER DR IVER BACKPLANE Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 10: Ps-1/Psu-1 Module Leds
NOTE: The PS-1 is supplied with a battery temperature sensor that must be fitted to the negative (-) terminal of the battery to ensure correct charging operation. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 11: Psu-1 Wiring Diagram
(FOR RADIO OR OTHER DEVICE) TAPE TE MPERA TURE SENSOR TO NEGA TIVE BATTERY TERMINAL. CONNECT BLACK BATTERY STRIPED WIRE OF SENSOR TO TE MP. R- OR B- SENSOR EARTH NEUTRAL 90-250 VAC INPUT SUPPLY ACTIV E Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 12: Wiring Diagram - Dc Supply
PS-1 is wired for a DC supply. PS-1 24 VDC AUX. OUTPUT (OPTIONAL) DC OUTPUT (FOR RADIO OR OTHER DEVICE) 11.8 TO 14.0 VDC SUPPLY (MUST BE ISOLA TED FROM FIELD SUPPLY ) CONNECTED Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 13: Ps-10: Ac Supply Input 90 To 260 Vac & Ps-20: Dc Supply Input 20 To 60 Vdc
4 Power Supply modules of any type can be installed on a backplane thus providing redundant and alternative power source configurations. Part numbers: PS-10-CU, PS-20-CU ‘C’= Auxiliary 24 V DC to DC converter fitted. ‘0’=Not fitted. ‘U’= Power supply monitoring processor fitted. ‘0’=Not fitted. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 14: Ps-10/Ps-20 - Standard Specifications
* The battery voltage is monitored when the input supply is disconnected. While the input supply is connected, the module will measure the regulated voltage and current output of its AC (PS-10) or DC (PS-20) input circuit. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 15: Ps-10-2/Ps-20-2 - 24 V Specifications
SENSOR BACKPLANE Ibat CURRENT MONITOR OPTIONAL BATTERY BAT LOW OPTIONAL MONITORING RADIO RADIO PWR TEMP Ibat Isup POWER RS485 ISOLATED VAUX DRIVER MICRO CONTROLLER 24V AUX. DC/DC AUX24 PWR CONVERTER 10 W (OPTIONAL) BACKPLANE Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 16: Ps-10/Ps-20 - Module Leds
The lowest temperature is monitored by the monitoring processor and used by the temperature compensated battery charging (in normal operation the internal temperature sensor will indicate a higher temperature than the external sensor). Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 17: Wiring Diagram - Ac Supply
The battery input of the PS-10 can be used as a DC supply input. PS-10 24 VDC AUX. (OPTIONAL) 13.8 VDC (FOR RADIO OR OTHER DEVICE) 11.8 TO 14.0 VDC SUPPLY (MUST BE ISOLA TED FROM FIELD SUPPLY ) CONNECTED Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 18: Wiring Diagram
20-60 VDC INPUT SUPPLY * + SUPPLY *A NEGATIVE DC INPUT SUPPLY CAN BE USED. CONNECT THE MORE POSITIVE WIRE (eg 0 V) TO +SUPPLY AND CONNECT THE MORE NEGATIVE WIRE (eg -48 V) TO -SUPPLY . Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 19: Psu-2: Dc Supply Input, 18 To 36 Vdc
RTU Startup at 11.8 V Supply Fuse 4 A slow blow internal Monitoring Circuits Battery Current and Voltage, Temperature, DC Supply Status Indicators Supplies and Battery on Front Bezel Connector Removable for DC connectors Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 20: Psu-2 Block Diagram
This module can be installed in any I/O slot of a 3, 6 or 12 slot backplane in a system. Up to 4 Power Supply modules of any type can be installed in a backplane thus providing redundant and alternative power source configurations. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 21: Psu-2 Wiring Diagram
P S U-2 Wiring Dia g ra m 24VDC AUX. OUTPUT BATTERY CLOSE FOR OFF SUPPLY + Vs, DC INPUT SUPPLY SUPPLY - EARTH P S U-2 Outp ut Cha ra c te ris tic s OUTPUT POWER AMBIENT TEMPERATURE (DegC) Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 22: Psu-4: Ac Supply Input, 60 W (Pre 2008)
Monitoring Circuits Status Indicators Connector Screw Terminals Weight 530 gm P S U-4 Blo c k Diag ra m 5V REG FILTER AND DC/DC +12 or +24V RECTIFIER 60 WATT 6 PIN PLUG BACKPLANE Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 23: Psu-4 Mounting And Connection
P S U-4 Mo unting a nd Co nne c tio n P S U-4 Outp ut Cha ra c te ris tic s OUTPUT POWER AMBIENT TEMPERATURE (DegC) Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 24: Cp-1: Standard Processor Module
I/O slot of a 6 or 12 slot backplane in a system. Up to two processor modules can be installed in an RTU system. For example these two may reside anywhere in one, two, three or four backplane systems. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 25: Specifications
I/O Bus Data Rate 250 kbps CM Bus Data Rate 83 kbps Cyclic Redundancy Port 1 and 2 Operating Temperature -20 to 70 °C Storage Temperature -40 to 85 °C Operating Humidity 5 to 98% RH non-condensing Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 26: Block Diagram
Port 1 is at the top for RS232 connections only and Port 2 is below for either RS232 or RS485 connections. CP-1 CP-1 RS232 RS232 RS232 RS232 / RS485 RS485 EARLY MODELS Figure: CP-1 Front Module and Port Identification Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 27: Note: Port 2 Rts And Cts Do Not Function On Rev. C Boards
Line - Line + GREEN / WHITE 1 RJ45 Socket GREEN 2 RJ45 Plug ORANGE / WHITE 3 BLUE 4 BLUE / WHITE 5 ORANGE 6 BROWN / WHITE 7 BROWN 8 87654321 12345678 Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 28: Sbx-2: Mini Processor Unit
LEDs showing status of the serial ports are present on the IO-3 module and reference to this module should be made. This module consumes power from the +5 VDC bus on the backplane. The module can be installed only in slot 2 of a BA-3 backplane in a system. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 29: Sbx-2 Specifications
I/O Bus Data Rate 250 kbps CM Bus Data Rate 83 kbps Cyclic Redundancy Port 1 and 2 Operating Temperature -20 to 70 °C Storage Temperature -40 to 85 °C Operating Humidity 5 to 98% RH non-condensing Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 30: Sbx-2 Block Diagram
Cable DB9 Male Carrier Detect CD Receive Data RXD Transmit Data TXD Port 1: Data Terminal Ready DTR Port 2: RS485- Signal Ground GND RS485+ Request to Send RTS Clear to Send CTS Do Not Connect Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 31: Lm-2: Line Modem Module, Dual Leased Line 2-Wire
+5 VDC bus on the backplane. The module can be installed in any I/O slot of a 6 or 12 slot backplane and in slot no. 3 of a BA-3 backplane and any slot except slot 1 of a BA-4 backplane. Up to four modem modules can be installed in an RTU system. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 32: Specifications
LM-2 Blo c k Dia g ra m CM BUS RS485 DRIVER 80C51 32 kB 16 MHz DUART V22BIS V22BIS MODEM MODEM PLINE RADIO PLINE RADIO PORT 1 PORT 1 PORT 2 PORT 2 Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 33: Connections
RJ45 Socket GREEN 2 RJ45 Plug RJ45 ORANGE / WHITE 3 BLUE 4 BLUE / WHITE 5 ORANGE 6 BROWN / WHITE 7 BROWN 8 +12 V low power 87654321 12345678 GND (0 V) Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 34: Rts, Cts & Cd Signals Active Low To 0 V
2. RTS, CTS & CD signals active low to 0 V RJ12 Socket Private Line Function LM-2 Ports 1, 2 RJ12 Plug BLUE 1 YELLOW 2 RJ12 Connector GREEN 3 RED 4 BLACK 5 Line - WHITE 6 Line + 654321 123456 Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 35: Lna-6: Line Amplifier Module, Leased Line
Max. Number of Modules Internal Power Consumption 36 mA from +5 VDC bus on backplane Operating Temperature -20 to 70 °C Storage Temperature -40 to 85 °C Operating Humidity 5 to 98% RH non-condensing Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 36: Lna-6 Block Diagram
LNA-6 Co nne c tio ns LNA-6 PLINE RJ12 Socket Function LNA-6 RJ12 Plug BLUE 1 YELLOW 2 RJ12 Connector GREEN 3 RED 4 BLACK 5 Line - WHITE 6 Line + 654321 123456 Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 37: Mc-1: Multi Communications Module
ON when port is receiving Request to send. Set ON to begin transmitting Carrier detect. ON while a communications signal is detected. Processor Watchdog Timer. Set ON when the processor is reset. DR1, DR2, Not used T1, T2 Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 38: Specifications
MC-1 Blo c k Diag ra m CM BUS RS485 FLASH DRIVER 80C188 256 kB 16 MHz 256 kB RESET POWER MANAGEMENT DUART Option port RS232 / RS232 RS485 PORT 3 PORT 1 PORT 2 PLUG-IN OPTION BOARD Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 39: Connections
RJ45 Socket GREEN 2 RJ45 Plug ORANGE / WHITE 3 +12 V Low Power BLUE 4 BLUE / WHITE 5 (requires link) ORANGE 6 BROWN / WHITE 7 BROWN 8 87654321 GND (0 V) 12345678 Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 40: Ba-3: 3 Slot Backplane
+24 V DC), if the standard supply is not fitted. The two lower 10 way pin headers are for the two serial ports of an SBX-2 module, if used. This backplane is designed for surface mounting. Mounting brackets (2 pieces) are supplied for user fitting. Figure: BA-3 Mounting Details Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 41: External Connections
N/C or I/O (RS485) Port 2 only Pin 5 0 V (RS232 and RS485) Pin 6 N/C or +IO (RS485) Port 2 only Pin 7 RTS Request to send Pin 8 CTS Clear to send Pin 9 Pin 10 Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 42: Bax-6: 6 Slot Backplane For Lna-6 Module
A third connector (6 way) on the far right is for the external power supply input (+5 V). This backplane is designed for surface mounting. Mounting brackets (2 pieces) are supplied for user fitting. Figure: Backplane Mounting Details - BAX-6 Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 43: External Connections
Pin 13 0 V - Signal ground Pin 14 CD - Carrier data detect Pin 15 RXA - Receive analog (-10 dBm) NOTE: PTT, CTS and CD are active low referred to 0 V Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 44: Ba-4: 4 Slot Backplane
J13 (in), J15 (out) Inter-rack Harwin Data Sockets PCON Power Control IO Link IO+ CSR Processor Interrupt Comms link CM+ Signal Ground GND GND Signal ground IO link IO- CM- Comms Link Orange SL9 Socket Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... - Page 45 +24 V Aux. Supply Output (optional) 0 V Aux. Supply Output (optional) +12 V To/From Battery 0 V To/From Battery +12 V To Radio 0 V To Radio +12 V Input Supply 0 V Input Supply Earth Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page...
-
Page 46: Ba-40: 4 Slot Backplane
PCON Power Control J13 (in), J15 (out) Inter-rack Harwin Data Sockets PCON Power Control IO Link IO+ CSR Processor Interrupt Comms link CM+ Signal Ground GND GND Signal ground IO link IO- CM- Comms Link Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 47: Ba-6: 6 Slot Backplane
Early revision backplanes were designed for 24 V only. J13 (in), J15 (out) Inter-rack Harwin Data Sockets PCON Power Control IO Link IO+ CSR Processor Interrupt Comms link CM+ Signal Ground GND GND Signal ground IO link IO- CM- Comms Link Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 48: Ba-12: 12 Slot Backplane
Early revision backplanes were designed for 24 V only. J13 (in), J15 (out) Inter-rack Harwin Data Sockets PCON Power Control IO Link IO+ CSR Processor Interrupt Comms link CM+ Signal Ground GND GND Signal ground IO link IO- CM- Comms Link Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 49: Di-1: 12-24 Volt Ac Or Dc Input, 16 Point
1 mA maximum On response Time 10 ms typical Off response Time 17 ms typical Operating Temperature -20 to 70 °C Storage Temperature -40 to 85 °C Operating Humidity 5 to 98% RH non-condensing Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 50: Wiring Diagram
CH 13 CH x CH 14 POWER CH 15 SUPPLY CH 16 Combined positive and negative power 0 V / Common Chs 9-16 0 V / Common Chs 9-16 supplies POWER SUPPLY CH y Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 51: Di-2: 48 Volt Ac Or Dc Input, 16 Point
2.2 mA maximum On response Time 10 ms maximum Off response Time 17 ms maximum Operating Temperature -20 to 70 °C Storage Temperature -40 to 85 °C Operating Humidity 5 to 98% RH non-condensing Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 52: Wiring Diagram
CH 13 CH x CH 14 POWER CH 15 SUPPLY CH 16 Combined positive and negative power 0 V / Common Chs 9-16 0 V / Common Chs 9-16 supplies POWER SUPPLY CH y Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 53: Di-3: 120 Volt Ac Input, 16 Point
34 ms maximum Operating Temperature -20 to 70 °C Storage Temperature -40 to 85 °C Operating Humidity 5 to 98% RH non-condensing * Number of inputs on is dependent upon ambient temperature as shown below Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 54: Wiring Diagram
CH 12 CH 13 CH 14 CH 15 CH 16 Common For Chs 9-16 Common For Chs 9-16 DI-3 Ou tp ut Cha ra c te ris tic s NUMBER OF INPUTS AMBIENT TEMPERATURE (DegC) Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 55: Di-4: 240 Volt Ac Input, 16 Point
34 ms maximum Operating Temperature -20 to 70 °C Storage Temperature -40 to 85 °C Operating Humidity 5 to 98% RH non-condensing * Number of inputs on is dependent upon ambient temperature as shown below. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 56: Wiring Diagram
CH 12 CH 13 CH 14 CH 15 CH 16 Common For Chs 9-16 Common For Chs 9-16 DI-4 Ou tp ut Cha ra c te ris tic s NUMBER OF INPUTS AMBIENT TEMPERATURE (DegC) Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 57: Tel Rel 001: Dpdt Relay Board For Do-5
(for connection to the DO-5 module) CAUTION! Contacts should be protected with appropriate suppression devices when wired with inductive loads to increase life of relays (please see DO-1 Switching Inductive Loads). Contacts should also be protected with external fusing. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 58: Relay Board - Tel Rel 001 Wiring Diagram
(i.e. DPDT ) Wiring Example NO (a) LOAD When the output External Power channel is set ON, Supply. Note: POWER SUPPLY the load is polarity can be C (a) energised reversed. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 59: Interface Cable - Do-5 To Tel Rel 00X Relay Board
Green/Black Orange/Black Blue/Black Black/White CH10 CH10 Red/White CH11 CH11 Green/White CH12 CH12 Blue/White CH13 CH13 Black/Red CH14 CH14 White/Red CH15 CH15 Orange/Red CH16 CH16 Blue/Red +12 V +12 V Green/Red +12 V +12 V Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 60: Ai-4: Analog Current Input, 8 Channel (Flying Capacitor)
To minimise the capacitive loading and noise, all field connections to the module should be wired using a good grade of twisted, shielded instrumentation cable. The shields can be connected to GND. The GND connection provides access to the backplane (frame ground). Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... - Page 61 This module can be installed in any I/O slot of a 4, 6 or 12 slot backplane in a system. Up to 10 Analog Current Input modules can be installed in a backplane. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page...
-
Page 62: Specifications
No responsibility will be taken by Semaphore for damage caused to boards during modification performed by clients. The circuit board resistors to change are: channels 1 - 8 = R1 – R8. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 63: Block Diagram
POWER CH 5+ CH x- SUPPLY CH 5- CH 6+ 4-wire transmitter CH 6- CH x+ Analog (powered externally) SHIELD CH x- Input CH 7+ POWER CH 7- SUPPLY CH 8+ CH 8- SHIELD Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 64: Ao-2: Analog Current Output, 4 Channel
Earth / Ground rails with metal clamps or similar method is recommended, especially in environments with high electromagnetic noise levels. This module can be installed in any I/O slot of a 4, 6 or 12 slot backplane in a system. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 65: Module Leds
Channel output level < 1% C3, D4 Channel output level > 1% AO-2 Lo a d Curre nt Cha ra c te ris tic s (24 V Ou t) Load Current 80 mA Ambient Temperature (Deg C) Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 66: Specifications
Yes. Module can be swapped while RTU is running. Hot swap will not cause a Warm Start. Outputs will be restored within 2 seconds once module is replaced. Open Loop Detection Not supported. Please see AO-3. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 67: Wiring Diagram
0-20 / 4-20 mA CH x + Analog Current Loop CH x - Load Receiver SHIELD SHIELD CH 2 + CH 2 - SHIELD CH 3+ CH 3 - SHIELD CH 4+ CH 4 - SHIELD Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 68: Rt-1: Analog Rtd Input, 4 Channel
RTD conditioning and ADC circuits. This module can be installed in any I/O slot of a 4, 6 or 12 slot backplane in a system. Up to 10 RTD modules can be installed in a backplane. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 69: Specifications
>70 db from DC to 60 Hz Cross-Channel Rejection >80 db from DC to kHz Operating Temperature -20 to 70 °C Operating Humidity 5 to 98% RH non-condensing Storage Temperature -40 to +85 °C Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 70: Block Diagram
0-20 OR 4-20mA BRIDGE RS485 80C51 MICRO OP TO PT100 DRIVER CONTROLLER ISOLA TION BRIDGE PT100 BRIDGE PT100 RT-1 Wiring Dia g ra m CH 1 SHIELD CH 2 SHIELD CH 3 SHIELD CH 4 SHIELD Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 71: Comms Option S: Serial Option Board
Standard 12345678 Standard GND (0 V) RS 232 Wiring Dia g ra m (Null Mo d e m Ca b le ) Maximum RS232 Wire Length: 15 m. RTU SERIAL RTU SERIAL PORT PORT Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 72: Comms Option Z: 2400 Bps Dial Option Board
CP-10/11/21/30 Port 2 or Port 3 MC-10/11/30/31 Port 2 or Port 3 LP-1/2 Port4 LP-3 Port 3 or Port 4 Original dial circuit board is labelled S2-DOB REV 1.0 and did not have a second soldered-on circuit board. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 73: Modem Board M: 4-Wire Line Option Board
Tx - BLACK 5 WHITE 6 Rx - Rx + 654321 123456 Tx + 4-Wire Line Optio n Bo a rd Wiring Diag ra m s Please see CP-xx Line Option Board wiring diagrams. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 74: Gps Option Board
Number of available satellites Internal Power Consumption 140 mA from +5 VDC Bus on backplane Operating Temperature -20 to 70 °C Storage Temperature -40 to 85 °C Operating Humidity 5 to 98% RH non-condensing Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 75: Do-5: Relay Driver Output, 16 Channel
The outside left edge of the insert is color-coded red to indicate a high-voltage module. Mo d ule LEDs DO-5 State Description Module fault (no power) Normal A1-A16 Digital output OFF (open) Digital output ON (closed) Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 76: Specifications
CH 10 CH 11 CH 12 CH 13 When output is energised, output channel is CH 14 shorted to the 0 V terminal. CH 15 CH 16 +12 V Ou tput +12 V Ou tput Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 77: Ps-11: Ac Supply Input 100 To 240 Vac
10.5 V ± 0.2 V. The PS-11 has battery voltage, battery current, supply current, and internal or external temperature monitoring circuits that enable the processor module to access these as analog and digital points in the system. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... - Page 78 A power supply module can be installed in any I/O slot of a 4, 6 or 12 slot backplane. Two or more power supply modules of any type can be installed on a backplane in any available slots. This provides redundant and alternative power source configurations. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page...
-
Page 79: Specifications
When connected the temperature sensor returns 10 mV per ˚Kelvin. (Note 0 ˚Kelvin = -273 ˚C). When functioning correctly, the sensor will provide 2.73 V @ 0 ˚C and 2.93 V @ 20 ˚C etc. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 80: Module Leds
IO Modules List (from the menu Configuration, I/O Modules List). Configure the PS-11 module from the IO Modules List to use a Battery Type of Sealed Lead-Acid. Save the configuration and then download into the RTU. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 81: Battery Charging
COMPENSATION EARTH TEMP. SENSOR SENSOR Ibat CURRENT BACKPLANE OPTIONAL MONITOR BATTERY BAT LOW MONITORING RADIO RADIO TEMP Ibat Isup POWER RS485 ISOLATED 24V VAUX DRIVER MICRO CONTROLLER AUXILIARY DC/DC AUX24 PWR CONVERTER (OPTIONAL) BACKPLANE Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 82: Wiring Diagram - Ac Supply
PS-11 24 VDC AUXILIARY OUTPUT (OPTIONAL) 12 VDC OUTPUT (FOR RADIO OR OTHER DEVICE) 12 VDC SUPPLY (NOMINAL) (MUST BE ISOLATED FROM FIELD SUPPLY) 96 TO 340 VDC SUPPLY (ALTERNATIVE TO USING BATTERY TERMINALS) Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 83: Ps-21: Dc Supply Input 20 To 60 Vdc
10.5 V ± 0.2 V. The PS-21 has battery voltage, battery current, supply current, and internal or external temperature monitoring circuits that enable the processor module to access these as analog and digital points in the system. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... - Page 84 A power supply module can be installed in any I/O slot of a 4, 6 or 12 slot backplane. Up to 4 Power Supply modules of any type can be installed on a backplane thus providing redundant and alternative power source configurations. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page...
-
Page 85: Specifications
When connected the temperature sensor returns 10 mV per ˚Kelvin. (Note 0 ˚Kelvin = -273 ˚C). When functioning correctly, the sensor will provide 2.73 V @ 0 ˚C and 2.93 V @ 20 ˚C etc. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 86: Module Leds
Modules List to use a Battery Type of Sealed Lead-Acid. Save the configuration and then download into the RTU. • If a backup battery is being used, the power supply may also need to be returned to the factory for a firmware upgrade. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 87: Battery Charging
COMPENSATION EARTH TEMP. SENSOR SENSOR Ibat CURRENT BACKPLANE OPTIONAL MONITOR BATTERY BAT LOW MONITORING RADIO RADIO TEMP Ibat Isup POWER RS485 ISOLATED 24V VAUX DRIVER MICRO CONTROLLER AUXILIARY DC/DC AUX24 PWR CONVERTER (OPTIONAL) BACKPLANE Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... -
Page 88: Wiring Diagram
(eg. 0 V) TO + SUPPLY AND CONNECT THE MORE NEGATIVE WIRE (eg. -48 V) TO - SUPPLY. TAPE OR CABLE TIE TEMPERATURE SENSOR TO NEGATIVE BATTERY TERMINAL (OR AS CLOSE AS POSSIBLE). CONNECT BLACK STRIPED WIRE OF SENSOR TO R- OR B- Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page... - Page 89 Acronym for Remote Terminal Unit. Describes a group of processor, communication and IO modules that comprise a device for monitoring and control of equipment in remote locations. TCP/IP Transfer Control Protocol / Internet Protocol. Commonly used for Ethernet communications. Universal Datagram Protocol. Superseded Hardware Manual 7.12 www.cse-semaphore.com/mykingfisher Page...
