SOGEDIS 2795-ELECTRONIC Manual

Display and control panel

Advertisement

Quick Links

1. It enables the setting value of fridge to be modified and super cool mode to be activated if desired.
Cooler maybe set to 8, 6, 5, 4, 2 °C, SC.
2. It is super cool mode symbol.
3. It is alarm symbol.
4. It is fridge set value screen.
Super Cooling Mode :
• To cool plenty of food
• To cool foods rapidly
How to use;
• Press set button until 'SUPER' led blink.
During this mode:
• Super cool mode can be cancelled by the same operation of selecting.
Demo mode :
This mode will be use for only sales points by salesman to show functions & modes to customer
without operating components as a compressor, fan, motor..Etc
Entering Demo mode:
•Firstly the power is on , with in 1 minute set the temperature to ''SUPER'' and user will push ''SET''
button for 10 seconds , Then appliance will go on "demo function" and Super LED symbol will blink
during the mode.
•All functions can be adjusted to show how they are adjusted to the customer.
Canceling Demo mode:
•For cancelling; Same operation will be used. If user will push SET button for 10 seconds, demo
function will be cancelled.
•When appliance is Demo mode; if plug is removed or there is an electricty breakdown; demo mode
will continue with current settings after user plug into or electricity breakdown finish.
2795-ELECTRONIC
Display and Control Panel
1
NOVEMBER 2016

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2795-ELECTRONIC and is the answer not in the manual?

Questions and answers

Summary of Contents for SOGEDIS 2795-ELECTRONIC

  • Page 1 2795-ELECTRONIC Display and Control Panel 1. It enables the setting value of fridge to be modified and super cool mode to be activated if desired. Cooler maybe set to 8, 6, 5, 4, 2 °C, SC. 2. It is super cool mode symbol.
  • Page 2 2795-ELECTRONIC Display and Control Panel Temperature adjustment and activating SUPER COOLING Mode Initial temperature value for Cooler Setting Indicator is +5 °C. • Press set button once. • When you first push this button, the last value appears on the setting indicator of the cooler.
  • Page 3 2795-ELECTRONIC Fault Codes Sensor short open circuit defect on display USER MODE SERVICE MODE SENSOR TEMPERATURE REACTION REACTION (1) Freezer >+50°C or <-50°C (2) Refrigerator 2 Set Symbol blinks (sensor is short or open) (3) Defrost Short (< 100W) or <-50°C...
  • Page 4 2795-ELECTRONIC Fault Codes Cooling error on display ***NOTE:To prevent the wrong alarms, this alarm status is disabled on following conditions: •During the first 6 hours after the product was firstly connected. •During the defrost period •During the 30 minutes after a defrost •During the first 2 hours that if door was open.
  • Page 5 2795-ELECTRONIC Service Mode Entering service mode: Push SET button continuously for 10 seconds when 8 set symbol active. Appliance will enter service mode 10 sec. later. Canceling service mode: Push SET button continuously for 10 seconds when 8 set symbol active. Appliance will enter service mode 10 sec.
  • Page 6 2795-ELECTRONIC ASSEMBLE & DISASSEMBLE Replacement Turbo Fan Motor 1- First remove the multiflow caps and unscrew the screws (Fig-1) Then pull multiflow cover slightly from the bottom. (Fig-2) Figure-2 Figure-1 2-Remove the fan motor cover. (Fig-3) Unscrew the two screws and remove the fan motor body.
  • Page 7 2795-ELECTRONIC ASSEMBLE & DISASSEMBLE Replacement Sensor 2. Place the bottom-front details of the cover 1. Remove the sensor cover with the to its housing and then place the top cover help of a screwdriver and then detail to the housing by flexing it with a disconnect the sensor connector.
  • Page 8 2795-ELECTRONIC ASSEMBLE & DISASSEMBLE Replacement Led and Led Cover 1. Stick a tape to protect plastic. Insert a flat screwdriver into the gap and remove the cover. (Pic-1) Picture-1 2. Remove the led strip light from its 3. Disconnect the connector and change the housing.
  • Page 9 2795-ELECTRONIC ASSEMBLE & DISASSEMBLE Replacement Top Led and Led Cover Remove the led cover by pulling forward and disconnect the connector. SEPTEMBER 2021...
  • Page 10 2795-ELECTRONIC ASSEMBLE & DISASSEMBLE Replacement Head Panel and Main Board 1. First remove cover by pulling leftward as 2. Remove other cover by pulling backward shown below. from top side of the cover as shown below 3. Unscrew screws marked with red circle at the picture below.
  • Page 11 2795-ELECTRONIC ASSEMBLE & DISASSEMBLE 4. Disassemble snapfits at the area marked with red circle at the picture below . It can be used any suitable tool to disassemble. 5. Unplug socket on the board assembled head panel. NOVEMBER 2016...
  • Page 12 2795-ELECTRONIC ASSEMBLE & DISASSEMBLE 6. To reassemble head panel ; first plug socket mentioned before and then place detail on the head panel to related detail on the cover and then push head panel to place snapfits marked with red circle below.
  • Page 13: Assemble & Disassemble

    2795-ELECTRONIC ASSEMBLE & DISASSEMBLE 7. Then screw head panel with screwdriver and assemble covers and complete head panel assembly. 8. Pull cover backward and remove from housing NOVEMBER 2016...
  • Page 14 2795-ELECTRONIC ASSEMBLE & DISASSEMBLE 9. Then unplug all sockets. 10. To reassemble cover first plug all sockets related place on the board. NOVEMBER 2016...
  • Page 15 2795-ELECTRONIC ASSEMBLE & DISASSEMBLE 11. To reassemble cover pay attention to assemble with right direction. Details on the cover and housing should be matched eachother Cover Housing NOVEMBER 2016...
