Summary of Contents for Azon ROTAX
- Page 1 AZON Razor/Conti ROTAX adapter USER MANUAL Technical Documentation azonprinter.com...
- Page 2 The possibilities of digital printing have now been doubled with specially designed rotary adapt- er. Rotax allows printing on a vast range of cylindrical objects with diameter ranging from 41 mm to 127 mm and height up to 279 mm.
- Page 3 AZON ROTAX USER MANUAL Important! Main Rotary Display Please read the First step guide to familiarize yourself with printer parts and functions before setting up Rotary attachment. Print Mode 1.6” 41 mm Minimum Diameter: Auto UV 5” 127 mm Maximum Diameter:...
-
Page 4: Main Parts
AZON ROTAX USER MANUAL Main Parts Cup holder wheel (removable) Set of adjustable passive wheels Rotary Cable Moving platform Connector Stop Width adjust- point ment lock Set of sta- tionary drive wheels Thumb Screw holes Height adjustment knob Page... - Page 5 AZON ROTAX USER MANUAL Perform Nozzle Check To rotate Spit Box first lift it up (green arrow). It has two hooks on both sides which are used to attach to printer construction. Before printing on Rotary, you need to perform Nozzle Check. If nozzle check pattern is not good the print also will not be good.
- Page 6 AZON ROTAX USER MANUAL Rotary needs to be positioned exactly at front printer position (picture 3, Make sure printer is at the back picture 4). position so it is not in the way and it doesn’t hit the Rotary. Attach the Rotary Move printer back.
- Page 7 AZON ROTAX USER MANUAL Plug in rotary cable. When Rotary is connected you will get this screen on LCD Display Touch the Display to continue. Protective Now you will get the main rotary display (picture 10). Rotary Connector is lo-...
- Page 8 SPLITTING NOZZLES ON AZON RIP Now the printer should look something like on picture 12). Azon RIP Software provides option CONFIGURE ROTARY , this option is used to adjust number of nozzles [ decrease or increase ] used while printing on rotax adapter.
- Page 9 There are recommended settings for printing on Azonprinter Rotary type screwdriver required). adapter . Those settings are not the only one to use on rotary , Azon- printer cannot guarantee quality results and stability of machine if print settings are changed by user.
- Page 10 AZON ROTAX USER MANUAL a) Printing on Cylindrical bottle 5) Print the file and calibrate ROTAX. Repeat this process until you get best result. Depending on location of printed file on calibration plexiglass, Put the bottle on ro- move the ROTAX back or forward (examples bellow).
- Page 11 AZON ROTAX USER MANUAL b) Printing on Conical bottle or Cup level a bottle on both sides and make sure printing surface is flat and equally far from print head you can use printer cover. Install the small wheel if you are printing on a cup. Wheel is Move the printer forward so that cover is above highest part of bottle.
- Page 12 AZON ROTAX USER MANUAL When distance form printhead to object is equal across entire objects If you are printing on surface (picture 22) adjust the printhead height (next page). cup, adjust the cup holder. Press the cup holder wheel down (green arrow) and wheel will go up.
-
Page 13: Manual Height Adjustment
AZON ROTAX USER MANUAL Printhead height adjustment Manual height adjustment. For best print results it is suggested that distance between Print- head and object is around 2 mm. If distance is more than 3 mm, you will get a blurry print, and if it is lover than 1,5 mm, you can damage the 1) Check the settings. -
Page 14: Rip Settings
(“Configure Rotary” but- sults. Azon RIP software. ton). ROTAX is calibrated for 32 nozzles. When printing more than 1 layer TIP: If you already have preset for Rotary you can select it and use it (e.g. White + Color) minimum num- (picture below). -
Page 15: Important Notices
-Discharge mode is turned OFF UV Light INTENSITY -Top Cover lowered (for UV light protection) When setting up UV Light intensity, don’t go over 30%. Printing on ROTAX using in- tensity higher than 30 % you risk the Printhead clogging. Page... - Page 16 AZON ROTAX USER MANUAL Removal When you want to remove Rotary, disconnect the cable (unscrew the nut first) and screen bellow will appear. Press the screen and you will be back in normal mode. Now remove the Rotary and put the protection nut on connector. You can safely lover the Printer corresponding to requirements of your next print.
