UDI021
OPERATION GUIDE
▲ This product is suitable for users over 14 years old.
▲ Stay away from the rotating propeller
▲ Read the "important statement and safety guidelines" carefully.
Wasted Lithium-Polymer batteries must not be placed with household
trash. Please contact local environmentalor waste agency or the
supplier of your model or your nearest Li-Po battery recycling center.
Our company's products are improving all the time, design and specifications are subject
Important
to change without notice. All the information in this manual has been carefully checked to
Notice
ensure accuracy, if any printing errors, our company reserve the final interpretation right.
Suitable for sailing in larger waters
https://udirc.com/disclaimer-and-safety-instructions
Li-Po Battery Disposal & Recycling
Note
Advertisement
Table of Contents
Summary of Contents for udir/c UDI021
- Page 1 UDI021 OPERATION GUIDE Suitable for sailing in larger waters Note ▲ This product is suitable for users over 14 years old. ▲ Stay away from the rotating propeller ▲ Read the “important statement and safety guidelines” carefully. https://udirc.com/disclaimer-and-safety-instructions Li-Po Battery Disposal & Recycling Wasted Lithium-Polymer batteries must not be placed with household trash.
- Page 2 Ready before sailing Preparation the boat Cabin outer cover Deck Outer cover lock Tail rudder Hull bottom Spindle tube Outlet Right navigation Tail rudder Bracket Rods Propeller Support bracket Water press pieces Left navigation Power Switch Navigation Lights Cover Battery Compartments Buckle Navigation Lights Head Cover Installation...
-
Page 3: Battery Charge
Battery Charge Battery power is insufficient in the original plant. It must be charged saturated before it can be used. Connect the charging case to the charging input port of the boat battery and then connect the USB output ports. The green indicator light flashes when charging and the green indicator light will keep bright fully charged. - Page 4 4) Put the Li-po battery into the boat battery holder. 5) Properly connected the hull input port the power line of the battery puts on the side of the to the output port of the Boat battery. hull, push the battery to the end and stick to it. 6) Cover the inside and outside of the cabin and lock tightly.
-
Page 5: Transmitter Preparation
Transmitter Preparation Forward Trim Backward Trim Power Indicator Steering Wheel Left Rudder Trim Right Rudder Trim Throttle Trigger Power Switch Forward trim Backward Trim If the boat still moves If the boat still moves backwards when the forward when the throttle trigger is in the throttle trigger is in the middle position, press... -
Page 6: Sailing Operation
Battery installation of transmitter Battery Cover 4×1.5V AA, Alkaline Batteries Bottom of Transmitter Note Direction. Open the transmitter battery cover. Install batteries. Follow the direction of batteries designated in the inside of the battery box. Sailing Operation Frequency Pairing Please make sure the transmitter throttle trigger and Steering wheel to normal. - Page 7 Manipulation method Throttle Throttle Go forward Go backward trigger trigger Throttle trigger Steering wheel Throttle trigger Steering wheel Go forward Turn left Go forward Turn right Low speed High speed Pull the throttle trigger The throttle trigger is back gently and the car pulled to the maximum, will move forward slowly.
-
Page 8: Low Battery Alarm
Low Battery Alarm Boat: When the boat in low battery, the transmitter will beep "di.di.di.." constantly to remind the user to remote back the boat as soon as possible. And the boat speed will slow down to half and the capsize reset function will turn off automatically when the boat in low battery. Transmitter: When the transmitter in low battery, the transmitter will beep "di.di.di. -
Page 9: Parts Replacement
Parts Replacement Replac the steering gear Disassembly： 4) The steering gear Turn off the power of boat is separated from the steering gear arm. Steering gear 3) Unscrew the steering gear arm screws. Tie rod Arm of steering gear 2) Unscrew steering 2) Steering gear gear and fixing screws and then take out fixing... -
Page 10: Troubleshooting Guide
Replacement the Steel Rope Remove: Remove the propeller, unscrew the propeller fastener and steel rope fastener used a hex wrench and then draw out the steel rope. Steel rope fasteners Steel rope Installation: Replace the new steel rope, the installation step is opposite to the removal step. Noted: When the propeller is entangled with debris, the stell rope is easy to burst.Please be sure to avoid debris in the water. -
Page 11: Fcc Note
FCC Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interferencein a residential installation. - Page 12 Manufacturer: SHANTOU CITY CHENGHAI UDIRC TOYS CO., LTD Address: Guangfeng Industrial Zone, Guangyi Street, Chenghai District, Shantou City, Guangdong Province, CN Model: UDI021 MADE IN CHINA...
