When inserting smart card into its slot, the chip of smart card must
be faced up. In order to avoid any physical damage to the card or the
smart card slot of the terminal, it is recommended to insert the card
gently. If smart card is successfully detected by the terminal, the icon
of the smart card will be shown on the top of screen.
ICC Operation Process
Before inserting the IC card, please check inside and around the IC
card slot. If there is any suspicious object, please don't insert card
and immediately report to the relevant staff.
Swiping Contactless card
When swiping, please put the contactless card in the sensing area on
the front of the terminal as shown in Figure 5.
Figure 5. Insert smart card
Battery charging
Connecting the terminal to PC with USB cable can charge the battery.
For the first time, please charge the battery before using the terminal.
Charging LED indicator
The charging LED indicator shows,
◊
Solid red when the battery is being charged.
◊
Solid green when the USB cable is connected and the battery is
fully charged.
5
Installation and Usage Tips
1) Do not damage the USB cable. If the USB cable is damaged,
please do not use it any more.
2) Before connecting the USB cable to a power supply such as a
power adapter, please make sure that its supply voltage is
appropriate for the terminal.
3) Do not expose the terminal in sunshine, or in humid, hot, and dusty
environmental conditions.
4) Keep the terminal away from liquid materials.
5) Do not plug any unknown material into any port of the terminal,
since it may cause serious damage to the terminal.
6) If the terminal is malfunctioning, please contact professional POS
technicians.
7) Do not put the terminal in explosive or hazardous area.
FCC Regulations:
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
RF Exposure Information
This device meets the government's requirements for exposure to
radio waves.
This device is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S. Government.
• This device complies with FCC radiation exposure limits set forth
for an uncontrolled environment.
6
