- Page 1 INSTRUCTION AND ASSEMBLY MANUAL POWERKIT GO ADEN GmbH www.aden-sports.com EN | P. 1...
-
Page 2: Table Of Contents
POWERKIT GO —ASSEMBLY INSTRUCTIONS CONTENTS Table of Contents Safety Instructions ............. 4 Bike View and Scope of Delivery ....... 5 Assembly ..............6 Assembly Powerpack Battery........11 Commissioning ............13 Using the Charger ............ 13 Care and Service............. 14 Terms and Conditions ..........15 Contact .............. - Page 3 Please store this manual in a safe place for future reference. If you sell your ADEN Powerkit at a later stage, make sure that the buyer receives this manual. The latest version of the assembly instructions is always available on our website www.aden-sports.com...
-
Page 4: Safety Instructions
POWERKIT GO — ASSEMBLY INSTRUCTIONS Safety Instructions By mounting the ADEN Powerkit Go, the bike turns into a pedelec. It is recommended that you only retrofit bicycles that meet the requirements recommended by us. We also expressly recommend that you only ride with appropriate protective clothing (helmet, gloves and sturdy shoes). -
Page 5: Bike View And Scope Of Delivery
POWERKIT GO — ASSEMBLY INSTRUCTIONS Bike View and Scope of Delivery (Bike ist not included.) Powerkit Go includes: belt ring incl. toothed belt, spoke clamps, drive unit, Powerpack battery incl. mounting plate, charger, thumb lever or twist grip, various small parts. ADEN GmbH www.aden-sports.com... -
Page 6: Assembly
POWERKIT GO — ASSEMBLY INSTRUCTIONS ASSEMBLY Needed tools: » Allen key size 2,5 » Allen key size 3 » Allen key size 4 » Side cutter » Cable tie » Torque wrench 1-10Nm (optional) » Belt Ring ALIGNMENT-TOOL (optional) Assembly Clamp the bike in a work stand or turn it upside down. - Page 7 POWERKIT GO — ASSEMBLY INSTRUCTIONS ASSEMBLY Install rear wheel and belt. The belt is "temporarily" fixed anywhere on the frame. Make sure that the wheel can be turned easily and that no brake cable or anything else is rubbing against the belt ring.
- Page 8 POWERKIT GO — ASSEMBLY INSTRUCTIONS ASSEMBLY The following assembly steps can be carried out independently of the assembly of the belt ring on the rear wheel. We recommend mounting the drive unit on the built-in rear wheel. To assemble the drive unit, the belt is first placed around the drive pinion.
- Page 9 POWERKIT GO — ASSEMBLY INSTRUCTIONS ASSEMBLY Now the motor will be attached to the chain stay using the pre- assembled motor bracket. To do this, turn the drive unit clockwise until the motor holder rests on the chain stay. Now put the belt around the chain stay and insert it into the lower slot of the motor mount.
- Page 10 POWERKIT GO — ASSEMBLY INSTRUCTIONS ASSEMBLY The thumb lever will be mounted in the desired location on the handlebars with an Allen key size 3 and laid down along the frame towards the bottom bracket/drive unit. Assembly-Note: Make sure that a loop has to be laid for the steering angle as with the other lines.
-
Page 11: Assembly Powerpack Battery
An alternative fastening option, if there are no screw-in points, is to use the tensioning straps. These are not included in the scope of delivery of the standard set, but can be ordered from ADEN on request. No holes may be drilled in very light / thin-walled frames and especially frames made of composite materials (carbon frames). - Page 12 POWERKIT GO — ASSEMBLY INSTRUCTIONS COMMISSIONING AND BATTERY USE On some bikes there is the possibility to mount the battery as shown in the picture. If you need an additional battery to double the range, just send us a request.
-
Page 13: Commissioning
The green LED on the charger lights up - Charging completed / battery charged The battery can now be unplugged. For longer storage, it is recommended to have the battery charged to approx. 50%. ADEN GmbH www.aden-sports.com EN | P. 13... -
Page 14: Care And Service
» The belt for wear or damage, » The spoke tension and » all cables for damage In any case, maintain the ADEN Powerkit regularly. If you have any questions we can be reached by phone or email. ADEN GmbH www.aden-sports.com... -
Page 15: Terms And Conditions
Powerkit Go, which complies with the rules for STVO conformity in Germany. or if we are in default for any other reason, the buyer must set us a reasonable grace period in order to effect our performance. -
Page 16: Contact
POWERKIT GO — ASSEMBLY INSTRUCTIONS Contact ADEN GmbH Kranzhaldenstr. 23 · 73249 Wernau · GERMANY Phone: +49 (0) 7153 7036300 00 info@aden-sports.com www.aden-sports.com facebook.com/adensports instagram.com/adensports ADEN GmbH www.aden-sports.com EN | P. 16...
