8
Electrical equipment
86A
"The repair procedures given by the manufacturer in this document are based on the
technical specifications current when it was prepared.
The procedures may be modified as a result of changes introduced by the
manufacturer in the production of the various component units and accessories from
which his vehicles are constructed."
MR-453-X79-86A000$TOC.mif
V1
V1
RADIO
Introduction
Role of components
Features
Defect and safe modes
Configuration – Settings
Self-test procedure
Security code recovery procedure
Anti-theft code
Customer complaints
Fault finding chart
Test
© Renault s.a.s. 2009
86A - 2
86A - 3
86A - 4
86A - 5
86A - 6
86A - 7
86A - 8
86A - 10
86A - 12
86A - 13
86A - 27
V1
All rights reserved by Renault s.a.s.
Copying or translating, in part or in full, of this document or use of the service part
reference numbering system is forbidden without the prior written authority of
Renault s.a.s.
Edition Anglaise

Advertisement

loading
Need help?

Need help?

Do you have a question about the Duster and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Renault Duster

Summary of Contents for Renault Duster

  • Page 1 Edition Anglaise "The repair procedures given by the manufacturer in this document are based on the All rights reserved by Renault s.a.s. technical specifications current when it was prepared. Copying or translating, in part or in full, of this document or use of the service part...
  • Page 2 RADIO Introduction 1. SCOPE OF THIS DOCUMENT This document presents the fault finding method applicable to all computers with the following specifications: Vehicle(s): DUSTER Function concerned: Radio R0-08 2. PREREQUISITES FOR FAULT FINDING Documentation type Fault finding procedures (this document): –...
  • Page 3 RADIO Role of components Radio The radio transmits audio signals into the vehicle via the speakers. Aerial The aerial receives radio waves from different stations. Compact disc player The compact disc player reads compact discs and reproduces the music on the radio. Display The display shows various radio information such as the name/frequency of the radio station being listened to, the sound level, as well as various audio settings.
  • Page 4 RADIO Features Functions provided by the radio: – FM - AM reception, – CD player, audio CD or CD/MP3 (depending on the vehicle equipment), – Monochrome display with two backlighting levels (day / night), – Control by satellite control on the steering wheel, –...
  • Page 5 RADIO Defect and safe modes Defect modes: If the 4-digit anti-theft code entered is incorrect, the system locks and the message "CODE" appears on the display. Before trying to enter the code again, wait for the system to come on and unlock itself. Thermal protection A thermal protection is integrated into the CD radio in order to protect the laser diode.
  • Page 6 RADIO Configuration – Settings TUNER CONFIGURATION The radio configuration can be corrected or changed when the anti-theft code is first entered. With the radio off, press buttons 1, 5 and ON simultaneously. This mode allows users to choose the preferred type of tuner. The tuner choices are Europe, United States, Asia, or Arabia.
  • Page 7 RADIO Self-test procedure The radio self-test modes are used to check certain basic functions by pressing a combination of buttons. Reception level fault finding This mode activates fault finding on the radio reception level. With the radio off, press buttons 3, 6, and ON simultaneously. After entering into this mode, the display indicates: –...
  • Page 8 RADIO Security code recovery procedure The pre-code is recovered by removing the radio and noting the four characters on the barcode that follow the letter T (see photo below). MR-453-X79-86A000$070.mif 86A-8...
  • Page 9 There are three ways to recover the radio code (4 digits): 1 – Only the VIN is available: connect to code management on Renault.Net and enter the VIN. The code server gives the original radio code entered in the World Vehicle Database (BVM).
  • Page 10 RADIO Anti-theft code The radio is protected by a four digit code. This code must be entered using the radio keypad every time the battery is disconnected: Enter the digits using buttons 1, 2, 3 and 4, and then confirm with button 6. If the code is entered incorrectly, the radio will be locked (1 minute for the first error, 2 minutes for the second error, 4 minutes for the third error, etc., for a maximum of 32 minutes after each attempt).
  • Page 11 RADIO Anti-theft code THE DISPLAY SHOWS "CODE" OR "0000" Entering the security code. The radio beeps every 2 seconds for 2 minutes then displays CODE. (See anti-theft code recovery Is the radio code known? procedure) Has the 4-digit code been obtained? The radio displays CODE then 0000 Go back to scrambled mode.

  • Page 12: Table Of Contents

    RADIO Customer complaints THE CD DOES NOT EJECT FROM THE PLAYER ALP 1 THE RADIO BEEPS EVERY 2 SECONDS ALP 2 THE RADIO DOES NOT OPERATE WHEN THE ON BUTTON IS PRESSED ALP 3 RADIO RECEPTION FAULTS ALP 4 THE RADIO DOES NOT SWITCH ON AUTOMATICALLY WHEN THE IGNITION IS ALP 5 SWITCHED ON OR GOES OFF AFTER 60 MINUTES LIGHTING DOES NOT CHANGE WHEN THE VEHICLE LIGHTS ARE SWITCHED ON...

  • Page 13: The Cd Does Not Eject From The Player

    RADIO Fault finding chart ALP 1 The CD does not eject from the player NOTES There is no manual procedure for ejecting a CD if it is stuck in the player. The CD does not eject from the player. Disconnect and reconnect the battery (see MR 451, Mechanical, 80A Battery, Battery: Removal - Refitting). Try again to eject the CD by pressing the radio button.

  • Page 14: The Radio Beeps Every 2 Seconds

    RADIO Fault finding chart ALP 2 The radio beeps every 2 seconds The radio beeps every 2 seconds. Wait 2 minutes and enter the security code of the radio (see anti- theft code). Is the code correct? The radio displays CODE, then 0000. Check the security code and try again.
  • Page 15 RADIO Fault finding chart ALP 3 The radio does not operate when the ON button is pressed Press the ON button of the radio. Check fuse F28 (15 A) on component 1016. Does the display work? Is the fuse sound? (backlighting) Check that the radio volume is not at 0.
  • Page 16 RADIO Fault finding chart ALP 3 CONTINUED 1 Check for earth on connection MT of component 261. If the wiring is faulty and there is a Is the earth correct? repair procedure (see Technical Is the resistance between Note 6015A, Electrical wiring 3 and 5 ohms? repair, Wiring: Precautions for repair), repair the wiring, otherwise...
  • Page 17 RADIO Fault finding chart ALP 3 CONTINUED 2 Check the continuity and insulation of connections 34A to 34H between 261 and 189, 190, 191, 192. Is the continuity and insulation test correct? MR-453-X79-86A000$100.mif 86A-17...

  • Page 18: Radio Reception Faults

    RADIO Fault finding chart ALP 4 Radio reception faults Run the self-test procedure of the aerial (see Self-test procedure) before running this NOTES ALP. Poor radio reception. Does the radio switch itself off Fault external to the radio. intermittently in FM mode? (transmitter synchronisation).
  • Page 19 RADIO Fault finding chart ALP 4 CONTINUED 1 Without moving the vehicle, Is the reception level high compare the level with that of (greater than 55)? a long wave station. Is the level higher? Check whether the poor reception is localised or Check the vehicle aerial.
  • Page 20 RADIO Fault finding chart ALP 4 CONTINUED 2 Check the continuity and insulation of the coaxial Hold the aerial wire near cable. Perform this check at to the radio. the aerial. Are the continuity and If the connection is faulty and Is the result better? insulation correct? there is a repair procedure...

  • Page 21: Switched On Or Goes Off After 60 Minutes

    RADIO Fault finding chart The radio does not switch on automatically when the ignition is ALP 5 switched on or goes off after 60 minutes Check that the system is operating correctly: – Switch to + accessories feed, – Switch on the radio, –...
  • Page 22 RADIO Fault finding chart ALP 6 Lighting does not change when the vehicle lights are switched on The radio lighting does not change when the vehicle lights are switched on. With the lights on, is there a voltage of approximately 12 V on Replace the radio (see MR 451, connection LPD for left-hand drive or LPG for right-hand Mechanical, 86A, Radio,...

  • Page 23: The Cd Is Played In Random Mode

    RADIO Fault finding chart ALP 7 The CD is played in random mode The radio plays the CD, but in a random manner. Check that the CD is in good When playing an audio track, does the CD "jump"? condition. Replace the radio (see MR 451, Mechanical, 86A, Is the CD player configured for random CD playing?

  • Page 24: The Satellite Control Does Not Work

    RADIO Fault finding chart ALP 8 The satellite control does not work The radio works, but the satellite control does not. Reconnect the satellite control and check Is the satellite control correctly connected? that the system operates correctly. Check the resistances of the satellite control using a multimeter by running Test 1 Resistance check of the radio satellite control.

  • Page 25: The Radio Does Not Receive All Stations

    RADIO Fault finding chart ALP 9 The radio does not receive all stations The radio works but does not receive all stations. Check that the radio tuner is correctly configured. Reconfigure the radio tuner Is the tuner operating area correctly configured? (see Configuration –...

  • Page 26: The Mini Jack Does Not Work

    RADIO Fault finding chart ALP 10 The mini jack does not work NOTES Check the correct operation of the mobile device before applying this fault finding chart. Connect a mobile device to the mini jack on the radio front panel. Check that the auxiliary source "AUX"...
  • Page 27 RADIO Test Resistance check of the radio satellite control TEST 1 MR-453-X79-86A000$110.mif 86A-27...
  • Page 28 RADIO Test TEST 1 Resistance check of the radio satellite control The check is carried out using a multimeter in the ohmmeter position between the tracks NOTES of the radio control satellite connector. 34AT 34AU 34AS 34AP MR-453-X79-86A000$110.mif 86A-28...
  • Page 29 RADIO Test TEST 1 CONTINUED Radio control satellite in use Connector tracks Resistance (Ω Ω Ω Ω ) Lower button (5) between 34AU and 34AP < 150 Decrease volume (4) between 34AS and 34AP < 150 Increase volume (3) between 34AT and 34AP <...
