- Page 1 1 valentine’s buildings Bechers drive Aintree racecourse Business Park L9 5ay CF1 L GAS APPLIANCE INSET CONVENTIONAL FLUED GAS FIRE INSTALLATION & USERS INSTRUCTIONS FOR USE WITH NATURAL GAS G20 @ 20 mbar For use in GB and IE THESE INSTRUCTIONS MUST BE LEFT WITH THE USER FOR FUTURE REFERENCE 1 ...
-
Page 2: Table Of Contents
These instructions cover the models listed below as part of the cf1L range 1. Miami 2. Manhattan 3. Boston 4. Chicago 5. Florida The fire tray is the same on all the appliances including the fuel layouts 1. Miami inset conventional flued gas appliance with a convector with rear trim and wall fixing and a front hinged door and trim 2. -
Page 3: Important Notes
17. COMMISIONING THE FIRE 16 18. LOGS LAYOUT 17 19.PEBBLES LAYOUT 19 20. DRIFTWOOD LAYOUT 20 21. LIGHTING THE FIRE 21 22. CHECKING FOR SPILLAGE 21 23. INSTRUCT THE USER 21 24. SERVICE AND MAINTENANCE & SPARE PARTS 22 1: IMPORTANT NOTES This fire should be installed and serviced every 12months in accordance with current gas safety (Installation and uses) regulations by a competent person who is a member of a recognized gas installer’s Organization (e.g. -
Page 4: How To Operate The Appliance
2: HOW TO OPERATE THE APPLIANCE SAFETY: - The fire is fitted with a flame supervision and atmosphere-sensing device (Oxy pilot) that will shut off the gas supply if the pilot light should go out for any reason. It will extinguish the pilot light if the oxygen content in the room falls below a prescribed level. - Page 5 2: HOW TO OPERATE THE APPLIANCE Now turn the Knob ‘A’ as far as it will turn to the maximum flame setting. The main burner will now light at the maximum setting. The fire is now lit so you can close the outer door or replace the trim and operate the fire using the remote control handset.
-
Page 6: Cleaning And Simple Maintenance
2: HOW TO OPERATE THE APPLIANCE Replacing the Batteries in the Receiver Open the fire outer door and you will see a small black Plastic box, this is the Receiver. Carefully slide the cover off the top of the box and replace the 4 Type ‘AA’ batteries making sure they are fitted the correct way around. -
Page 7: User Replaceable Parts
5: user replaceable parts PART NUMBER DESCRIPTION CF1L001 REMOTE HANDSET CFL002 REMOTE RECEIVER CFL003 LOGS CFL004 PEBBLES CFL005 DRIFTWOOD CFL006 TRIMS INSTALLATION INSTRUCTIONS 6: PARTS SUPPLIED BOX CONTENTS 1. Miami Box 1: main fire heat engine / glass door /fuels type instructions and fixings /remote control Box 2: trims and fixing frame 2. -
Page 8: Installation Requirements
7: INSTALLATION REQUIREMENTS In your own interest and that of safety, it is law, that a competent person who is a member of a recognized gas installation organization must install all gas appliances (E.g. Gas safe) In accordance with Current Gas Safety (INSTALLATION AND USE) Regulations. Before installation, ensure that the local distribution conditions (identification of the gas and pressure) and the adjustment of the appliance are compatible. -
Page 9: Technical Data
8: TECHNICAL DATA MODELS MIAMI--MANHATTAN—BOSTON--CHICAGO--FLORIDA GAS TYPE NATURAL GAS ONLY G20 SUPPLY PRESSURE 20mbars CATEGORY 420 STEREOMATIC INJECTOR GAS CONNECTION 8mm COMPRESSION HIGH HEAT INPUT 5.5kW (GROSS) LOW HEAT INPUT 2.9 kW WEIGHT 25 KG 9: DIMENSIONS GENERAL CF1L CF1L CF1L CF1L CF1L... -
Page 10: Contents Of Fixing Kit
10: CONTENTS OF FIXING KITS There are 2 different fixing frame kits for the cf1L appliances due to difference in design, and with the Manhattan and Chicago appliances both being taller be 150mm 1. fixing frame 1 for CF1L: Miami & Manhatton (150mm taller) FIXING FRAME SCREWS AND PLUGS TO INSTALL THE FRAME 10 SELF TAPPING SCREWS... - Page 11 11: APPLIANCE LOCATION Ensure all areas are fully sealed around the fixing frame and level off the hearth The flue should only pull through the diverter and nowhere else THE BOSTON, CHICAGO AND FLORIDA ALL RECEIVE VENTILATION FROM THE BOTTOM OF THE FIXING FRAME ENSURE THIS AIRFLOW IS NOT COVERED IN ANY WAY, AND ALWAYS KEPT CLEAR Showing Boston fixing frame screwed to wall, ensure all sides of frame are sealed using sand and cement or a similar Material and level off the hearth ensuring the flue can only pull through the flue diverter ensuring a good flue pull ...
-
Page 12: 12. Flues And Builders Opening Requirements
12. FLUES AND BUILDERS OPENING REQUIREMENTS Prior to creating the builders opening the flue must be checked. No restrictor plate or flue damper is permitted. The flue must be swept prior to installation. The flue must be free of any obstructions. The flue must be checked to ensure it only serves the fireplace opening to be used for the fire. The flue must have a positive up-draught and checked as follows before the builders-opening is constructed: Before installing the fire a simple smoke test should be carried out on the flue to check its condition. -
Page 13: Surround Requirements
13: SURROUND REQUIREMENTS Installation into a Suitable Fire Surround and Hearth With Combustible and Non Combustible Shelf Requirements. If the fire is to be installed into a suitable fire surround it must have a fire rating of 150C. The fireplace opening must be at least 60mm above the upper surface of the hearth. The Hearth must be non-combustible and protrude at least 300mm in front of the fire and be at least 1000mm wide. -
Page 14: Ventilation
14: VENTILATION No purpose provided additional ventilation is normally required, however this is subject to the spillage test In the Republic of Ireland (IE) ventilation shall be in accordance with I.S813 Domestic Gas Standards. Any purpose provided ventilation should be checked regularly to ensure that this is free from obstruction. IMPORTANT This appliance is fitted with a spillage monitoring pilot system (ODS) and must not be adjusted, by-passed or put out of Operation by the user or installer. -
Page 15: Installing The Fire
16:INSTALLING THE FIRE Remove the Fixing Frame from the box The Frame can be fitted to the builders opening using the screws And Raul plugs provided If a fire surround is to be used then it is recommended that the Fixing should be inside the builders opening so as to not risk Damaging the fire surround. - Page 16 17:COMMISIONING THE APPLIANCE Remove the customers chosen fuel effect pieces from the pack and check that none are broken or damaged. If Logs has been chosen it will be necessary to leave the Log Support fitted with the 3 Screws see Fig 17:1.if pebbles or driftwood have been chosen it will need removing Making reference to section 17,18 and 19 for placing the fuel effect pieces Fig 17:1 removing log support if driftwood or pebbles is the fuel being installed...
- Page 17 18: LOG LAYOUT Fitting Logs Note all the Log pieces Have numbers on their Base Fit the Large Rear Log Piece No1 Behind the burner as shown in Fig.18: 1 FIG 18:1 Fitting Log No2 Fit Log No2 at the left hand Side ensuring the hole in the base locates On to the metal peg at the front and it rests In the groove in the Rear Log as shown...
- Page 18 18: LOG LAYOUT Fitting ‘V’ Log or No4 Fit ‘V’ Shaped Log No4 Next to the last piece ensuring the hole In the base locates onto the metal peg At the front and it rests around the Branch on the Large Rear Log As shown Fig.
- Page 19 19: PEBBLE LAYOUT The log support bracket must be removed Before the pebbles can be installed by removing 3 self tapping screws and lifting away the Bracket Keep bracket and screws safe if for any reason You may wish to return to the log set up in the Future ...
- Page 20 20: DRIFTWOOD LAYOUT Cf1L driftwood layout spread the granules around the base CENTRE BRANCH LOG SITS BETWEEN TWO WARNING DO NOT BLOCK AIR RELIEF AT AS SHOWN ABOVE FRONT AND BACK OF BURNER PLACE 2 LARGE LOGS CENTRAL TO THE RIGHT TOP BRANCH SITS ON REAR LOG & REAR OF THE FIRE ON FRONT RIGHT BRANCH LOG AS ABOVE DO NOT COVER OVER AIR RELIEF SLOT...
- Page 21 21:LIGHTING THE FIRE Following the instructions on page 4 and turn on the appliance, check the operation of the Handset turning the fire up and down, Leave fire in the full position and carry out spillage test 22:SPILLAGE TEST Close all doors and windows. With the fire operating at High after 5 minutes apply a smoke match at the Diverter Inlet as shown in Fig 21:1.
- Page 22 23: SERVICE AND MAINTENANCE 23:1 General Checks prior to any Servicing or Maintenance. A competent person in line with current GAS SAFE recommendations must service the fire every year. It is recommended that a gas soundness test be conducted before any Servicing. It is also recommended that the operation of the fire be checked prior to any Servicing.
- Page 23 23: SERVICE AND MAINTENANCE Whilst lifting the Assembly at the rear, rotate it towards you and remove it from the Fire taking care not to foul the Side Liners of the fire. All gas-carrying parts are now accessible for servicing or replacement. For refitting follow the above Instructions in reverse order.
- Page 24 Replace the parts in reverse order. For refitting the Fuel Bed components see relevant section Check all faults have been corrected then re-commission the fire, conducting the usual safety checks and specifically gas soundness and spillage tests. Fit new batteries into the Handset and Receiver Finally with the Outer Door Closed ensure the Remote Control Handset operates the fire correctly Changing the injector Follow instructions above to remove fuel and remove 4 screws holding on the aeration bracket...
- Page 25 23: SERVICING AND MAINTENANCE AIR SUPPLY MUST BE KEPT CLEAR ONCE INSTALLATION IS COMPLETE THE TRIM IS FITTED BY PLACING THE TRIM INTO PLACE AND SECURING USING MAGNETS SUPPLIED ON THE APPLIANCE IMPORTANT ENSURE TRIM IS FITTED CORRECT WITH CUT OUT IN THE BOTTOM THIS IS REQUIRED AS THE APPLIANCE REQUIRES ITS AIR FOR SAFE USE UNDER NO CIRCUMSTANCES MUST THIS EVER BE CLOSED OFF...
