Summary of Contents for Sena Tufftalk M
- Page 1 Tufftalk M Hard Hat Mount Earmuff Quick Start Guide ENGLISH DC Power Charging & Firmware Upgrade Port Left Ear Cup Microphone Status LED (-) Button (+) Button Center Button Mesh Intercom Button 1.1.0...
-
Page 2: Product Features
Product Features Blast your favorite tunes, talk over the intercom with your buddies, ® all through your headset. With built-in Bluetooth capabilities, Audio Multitasking™, HD speakers and a microphone using Advanced Noise Control™, technology has never felt so minimal or freeing. NRR of 24 dB BLUETOOTH 4.1 MESH INTERCOM™... -
Page 3: Getting Started
GUIDE CAN BE DOWNLOADED AT SENAINDUSTRIAL.COM. 2. Update this product for free with the latest firmware to fully enjoy the new advanced features built into this product. Visit senaindustrial.com to see how to update your product. Sena Technologies, Inc. Customer Support: senaindustrial.com... -
Page 4: Installation
Installation Installing the Microphone Replacing the Ear Pads of the Tufftalk M Use your fingers to remove the ear pads and insert the included ear pads. -
Page 5: Sena Device Manager
Sena Utility App By simply pairing your phone with your headset, you can use the Sena Utility App for quicker and easier set up and management. • App Features - Music, FM Radio, Device settings, Quick Start Guide, and User’s Guide. -
Page 6: Button Operation
Button Operation Tapping Double Tapping 1” 5” 10” Press for 1 sec Press and Hold Power On/Off Volume Adjustment 1” Press Battery Check Power On... -
Page 7: Phone, Music
Phone, Music Pairing Press and hold the (+) Button and Center Button for 10 seconds when the Tufftalk M is turned off. Select Sena Tufftalk M Bluetooth Bluetooth Device A Device A 10” Sena Tufftalk M v1.0 Sena Tufftalk M v1.0... -
Page 8: Mobile Phone
Mobile Phone Call Making and Answering Answer 2” Press 3” Press Voice Dial 3” Press Speed Dial 2” Press Reject... - Page 9 Headset B 5” 5” Press Press Intercom Start/End Mesh Intercom On/Off When Mesh Intercom is enabled, the Tufftalk M will automatically connect to nearby Tufftalk M users and allow them to talk to each other by pressing the Mesh Intercom Button.
-
Page 10: Channel Setting
( 1 → 2 → → 8 → 9 → Exit → 1 → Save the channel Bluetooth Device A Sena Tufftalk M v1.0 Device B ..Using the Sena Utility App You can select the channel through the Sena Utility App. - Page 11 Mesh Intercom Group Mesh A Group Mesh™ is a closed network of headsets that allows users to create, leave, join, or rejoin a group intercom conversation without pairing each headset. Group Mesh Mesh Grouping A private group can be made with up to 24 users. Creating a Group Mesh 1.
- Page 12 Joining an Existing Group Mesh 1. Users (A, B) who want to join an Existing Group Mesh and one (C) of the users in the Existing Group Mesh simultaneously press the Mesh Intercom Button for 5 seconds. In Open Mesh Headset C in Existing Group Mesh Headset A...
- Page 13 Mesh Intercom Reset Mesh If a headset in an Open Mesh or Group Mesh resets the Mesh, they will automatically return to Open Mesh (default: channel 1). 8” Press Microphone Mute/Unmute The mute and unmute functions only work if Bluetooth Intercom or Mesh Intercom is on.
-
Page 14: Configuration Menu
Radio Scan Up FM Band Start 1” Press Stop Setting Configuration Menu 10” Press Troubleshooting Factory Reset If you want to restore the headset to factory default settings, use the Factory Reset in the configuration menu. The headset automatically restores the default settings and turns off. Fault Reset If the headset is not working properly for any reason, push the pin-hole reset button located... -
Page 15: Quick Reference
Quick Reference Type Operation Button Command Press the Center Button and the (+) Button Power on for 1 second Basic Function Power off Tap the Center Button and the (+) Button Volume up/down Tap the (+) Button or the (-) Button Answer mobile phone Tap the Center Button call... - Page 16 Quick Reference Type Operation Button Command Mesh Intercom on/off Tap the Mesh Intercom Button Channel setting Double tap the Mesh Intercom Button Mesh Intercom Mesh Grouping Press the Mesh Intercom Button for 5 seconds Reset Mesh Press the Mesh Intercom Button for 8 seconds Press the Center Button for 5 seconds Intercom pairing Tap the Center Button of any one of the two...
